D2-210 Spectroscopy Module with fiber coupling
option
Spectroscopy
Module
Model No. D2-210
Document Revision: 1
Document Last Updated on 2019/06/25 22:53
Please read Limited Warranty and General
Warnings and Cautions prior to operating the
D2-210. D2-210 website and data sheet.
Description
The D2-210 saturated absorption spectroscopy module provides error signals derived from saturated
absorption spectroscopy of atomic rubidium, cesium, or potassium. It contains a vapor cell, internal
temperature controller, balanced photodetectors, and optics. Temperature control stabilizes the
number density of atoms in the cell, and a balanced photodetection circuit compensates for intensity
drifts giving stable control over the lock point for side locking applications. The photodiode output is
shot-noise limited out to greater than 5 MHz for photocurrents of 50 μA and above. The high
bandwidth of the feedback enables tight solid locking that is immune to vibrations and shock. The
D2-210 is powered by a cable that plugs into the power connectors on any D2 series electronics
module.
The D2-210 is a significant upgrade to the D2-110 incorporating many suggestions from our
customers:
The module is magnetically shielded to allow close placement to the D2-100 DBR laser module.
An adjustable λ/2 waveplate enables the user to control light level pickoff over a wide range of
input power levels.
In addition to rubidium and cesium, the D2-210 can now be configured with potassium.
Ordering options exist for Doppler subtraction and fiber coupling.
Future ordering options will include lock signals derived by DAVLL and Zeeman Modulation
spectroscopy.
Purchase Includes
D2-210 Spectroscopy Module
VPN00463 SMA cable (6ft)
VPN00410 Hirose-to-D Sub 9-pin (shipped under separate line item; specify for use with D2)
VPN00475 Hirose-to-Hirose power cord (shipped under separate line item; specify for use with
ICE)
VPN00367 Adjustment tool
Last update: 2019/06/25 22:53 d2:spectroscopy_module_210 https://www.vescent.com/manuals/doku.php?id=d2:spectroscopy_module_210
https://www.vescent.com/manuals/ Printed on 2019/08/21 02:55
Absolute Maximum Ratings
Note: All modules designed to be operated in laboratory environment
Parameter Rating
Environmental Temperature >15°C and <30°C
Environmental Humidity <60%
Environmental Dew Points <15°C
Tab. 1
Specifications
Value Units
Input Light Level 2< P <1000 mW
Photodiode Amplifier
Transimpedance (signal) 40,000 Ω
Bandwidth (signal) 5 MHz
Noise @ 5 MHz <80 nV /√Hz
Set Temperature ~25 to 65 °C
Temperature Stability <0.1 °C
Beam Height 0.95 inches
Total package Size
(L x W x H) 3.6 x 5 x 1.7 inches
Tab. 2
Powering the D2-210
The D2-210 requires +5 and ±15 VDC and ground to operate. The power input is via a female 6-pin
Hirose connector HR10A-7TR-6SA(73). Depending on your order configuration, you should have
received a power cable with this connector on one end and either the same on the other end
(typically for use with ICE products) or a DB-9 connector (for use with D2-products).
If you are using the DB9-to-Hirose cable, but not a Vescent D2-005 power supply, table 3 below
details which pins on the Hirose require which voltages.
Theory of Operation
2019/08/21 02:55 3/12 Spectroscopy Module
Product Manuals - https://www.vescent.com/manuals/
Fig. 1: Beam path and component map
Last update: 2019/06/25 22:53 d2:spectroscopy_module_210 https://www.vescent.com/manuals/doku.php?id=d2:spectroscopy_module_210
https://www.vescent.com/manuals/ Printed on 2019/08/21 02:55
Fig. 2
Input light passes through an adjustable λ/2 waveplate and polarizing beamsplitter (PBS) that directs
a user-controlled portion of the beam to the vapor cells and detectors. (For the fiber-coupled option
the user will generally input most of the light.) The beam is then passed through a cleanup PBS and
split on a 50:50 non-polarizing beamsplitter (NPBS). One portion is then passed through a reference
vapor cell (Doppler subtraction option) or passed directly to the reference photodiode.
The remaining portion is passed through a fixed λ/2 waveplate and PBS to split off the pump beam
from the probe beam. The pump beam is directed to the Output Optics assembly where it is combined
with the probe beam on a PBS in a counter-propagating configuration. The pump beam is dumped
through the reflection port of the PBS that separated the pump and probe and terminates on the wall
of the housing. The probe is detected on the signal photodiode.
The beam diameters were designed to provide enough photocurrent (~50-100μA) to give shot-noise-
limited performance out to 5 MHz while limiting saturation broadening. For Vescent's DBR lasers, the
bandwidth is useful to provide for tight and stable locking by feedback to injection current.
2019/08/21 02:55 5/12 Spectroscopy Module
Product Manuals - https://www.vescent.com/manuals/
Inputs, Outputs, and Controls
Input Connector (6-pin circular)
Never connect this device to its power supply when the
power supply is switched on and supplying power. Always
turn off the power supply, make connections to the device,
and then re-energize the power supply.
Power and temperature control signals from the D2-series power bus, the ICE-PB1, or other power
supply are made through a 6-pin circular connector (HR10A-7TR-6SA(73)). The pin definitions (pin
numbers are marked on the connectors) are listed below. figure 3 below may be useful.
Fig. 3: Pin numbering on female Hirose 6-pin connector
Hirose
Pin
DB-9 Pin (if
applicable) Input Voltage Max Current
Draw Notes
1 4 and 5 Signal Power
Ground Return path for power rail.
2 8 -7 V to -15 V 100mA See note below.
3 9 +7 V to +15 V 100 mA See note below.
4 6 and 7 +5 V 1.5 A / 2.5 A
2.5 A max with Doppler
subtraction option, 1.5 A max
without.
5 No Connect
6 1 and 2 +5 V Ground Return path for high current
+5V.
Tab. 3
Note: When powering the D2-210 with supplies other than a D2-005, pins 5 and 6 can be placed between 7-15 V. They
need not be symmetric, but both supply rails are always required. See D2-005 manual for pin out on D-Sub 9-pin
connector.
Signal Output (SMA)
Last update: 2019/06/25 22:53 d2:spectroscopy_module_210 https://www.vescent.com/manuals/doku.php?id=d2:spectroscopy_module_210
https://www.vescent.com/manuals/ Printed on 2019/08/21 02:55
The photodiode signal is output through an SMA connector. Connect to ERROR INPUT on the Laser
Servo.
Balance Adj.
Sets the fraction of the Reference photocurrent to be subtracted from Signal. Setting the lockpoint
close to zero Volts will give the best subtraction of relative intensity noise (RIN) on the incoming laser.
Temperature Adj.
10-turn trim pot that sets temperature from 25°C (fully CCW) to 65°C (10 turns CW). The 5-turn point
is approximately 42°C. Note that the vapor cells are heated only, so setting the temperature below
room temperature essentially disables temperature control. The following table gives approximate
temperature settings for the three available alkali options:
Alkali Turns CW Temp
cesium 2 ~30°C
rubidium 4-5 ~40°C
potassium 8-9 ~60°C
Tab. 4
Temperature Loop Gain Adj.
In newer units, there is a middle trimpot for adjusting the gain on the PID temperature loops. Higher
gain (clockwise) will result in faster temperature settling until oscillation occurs.
Temperature Bias Adj.
[Note: this adjustment is only available on older D2-210 models.] For the Doppler subtraction option
this control enables the user to input a small temperature difference between the reference and
signal vapor cells. In the fully CCW position the signal vapor cell heater gets all the current. In the full
CW position the reference cell heater gets twice the current as the signal cell. This adjustment can be
used to place the optimum point for Doppler Subtraction closer to zero Volts.
This adjustment only has an effect with the -DS, Doppler Subtraction option.
Tilt Plate
A polarizing beamsplitter (PBS) is fixed to a ball joint formed by a truncated steel ball held by a
conformal brass ring. Two cone screws clamp the ring against the ball and fix the position of the PBS.
See Alignment Procedure below for instructions on how to align and fix the PBS.
2019/08/21 02:55 7/12 Spectroscopy Module
Product Manuals - https://www.vescent.com/manuals/
Fig. 4: Input beam tilt plate adjustment
λ/2 Waveplate
A waveplate attached to the front plate by magnets can be used to select the splitting fraction of the
Tilt Plate PBS.
Fig. 5: Half wave plate adjuster
Quick Setup Guide
Set the D2-210 in the beam path of the laser so that the beam goes through the center of the1.
input and output holes. Loosely apply the four 1/4-20 mounting screws and washers to affix the
Last update: 2019/06/25 22:53 d2:spectroscopy_module_210 https://www.vescent.com/manuals/doku.php?id=d2:spectroscopy_module_210
https://www.vescent.com/manuals/ Printed on 2019/08/21 02:55
unit to the laser table.
Using the cable provided, connect the 8-pin circular Hirose connector to the D2-210 and2.
connect the D-sub 9-pin connector to a free power connector on the D2-005 or other Vescent
electronics module. If you are using an alternate power supply, refer to the table above for
correct voltage input connections.
Connect the SMA connector to an oscilloscope.3.
If you have the fiber-coupling option, connect a polarization maintaining fiber with FC/APC4.
connector to the input fiber connector. At least 1 mW of optical power should exit the fiber.
Skip to step 9.
Note: When coupling the laser into the fiber, strive to
properly align the laser polarization to the polarization
axis of the PM fiber. Otherwise you will observe
significant temperature and stress induced birefringence
leading to input power fluctuations.
Open the top cover.5.
Block the reference photodiode with a strip of index card.6.
Adjust the light level by rotating the λ/2 waveplate to obtain about -1 V of signal.7.
Shift the D2-210 about the mounting screws to maximize the light level.8.
Set the laser to scan over the alkali transitions. If you observe spectroscopy, try to move the9.
D2-210 to optimize the spectrum.
Tighten the 4 mounting screws.10.
In about 20 min, a green LED should light (visible through the port next to SMA connector)11.
indicating the final temperature has been achieved.
If the spectroscopy does not look similar to the plots shipped with the device, proceed to the12.
Alignment Procedure below.
Use the Balance Adjust control to set the lock point to ground.13.
Aligning the Spectroscopy Module
The spectroscopy module is shipped factory aligned and should not require alignment if ordered with
a matching D2-100-DBR laser or if ordered with the fiber input (-FC) option. If the unit was not aligned
to a laser at the factory, or if it falls out of alignment, the following steps can be used:
Fashion several 1 cm x 3 cm cards from an index card for use as viewing screens.1.
Remove the cover on the Spectroscopy Module.2.
If working with a Vescent D2-100 laser, follow the instructions in the DBR Laser Module section3.
to adjust laser steering so the beam passes through the center of the input and output
apertures on the laser module.
Adjust the λ/2 waveplate on the input face to maximize the light power reflected by the input4.
PBS.
If required, loosen the two 2-56 screws holding the tilt-plate assembly into the spectroscopy5.
module and slide the assembly so that the input beam is centered on the PBS.
Loosen the two cone screws using a 0.050“ Allen wrench. Then tighten the cone screw farthest6.
from the alignment rod until the brass ring just begins to grab. Tighten the second cone screw
similarly. The goal is when moving the PBS with the alignment rod, it moves easily, but with
some resistance.
2019/08/21 02:55 9/12 Spectroscopy Module
Product Manuals - https://www.vescent.com/manuals/
Place the alignment tool so that the indent captures the end of the alignment rod as shown7.
below.
To use the adjuster, gently push down to seat the point as shown above. To adjust the beam1.
right and left, use a small twisting motion. To adjust the beam up and down, use your other
hand to turn the knurled cylinder.
Place a viewing card in the path of the pump beam as shown. Center the beam through the2.
passage.
Move the viewing card to the output port of the pump/probe PBS as shown below. Adjust the1.
beam so that it is centered on the output face of the PBS. At this point, the beams should be
well aligned and overlapped.
Place a viewing card in front of the Reference photodiode as shown below.1.
Last update: 2019/06/25 22:53 d2:spectroscopy_module_210 https://www.vescent.com/manuals/doku.php?id=d2:spectroscopy_module_210
https://www.vescent.com/manuals/ Printed on 2019/08/21 02:55
Adjust the λ/2 waveplate to give approximately 1 Volt at the output SMA (with Reference beam1.
blocked).
Scan the laser until the Doppler broadened transitions are visible. Doppler-free hyperfine2.
transitions should be clearly evident. For 87Rb, the cycling transition should have a depth
between 20 and 50 mV. At this stage, the input PBS can be adjusted to improve the Doppler-
free transitions; however, these adjustments are admittedly challenging. Generally it's best to
repeat the above procedure and make sure the saturation beam dump is well centered on the
output PBS and then check the quality of the spectroscopy. The 2-56 screws holding the input
and output optics assemblies can also be loosened to shift the optics assemblies around to
improve the spectroscopy.
Tighten the cone screw farthest from the alignment rod. Then tighten the last cone screw. The3.
order helps. If the spectroscopy changes then repeat the above alignment steps, but with the
cones screws just a bit tighter.
Unblock the Reference beam and use the Balance Adjust trimpot to set the desired lockpoint to4.
ground.
Replace the cover5.
The following images are representative of spectroscopy for 87Rb with and without Doppler
subtraction. Note that Doppler subtraction (figure 8) has a minimal effect on peak lock signal
generated by dithering the laser (green traces).
Fig. 3: Pin numbering on female Hirose 6-pin connector
Table des matières
Autres manuels Vescent Unité de contrôle
Manuels Unité de contrôle populaires d'autres marques
Festo
Festo Compact Performance CP-FB6-E Manuel de la liste des pièces
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur
JS Automation
JS Automation MPC3034A Manuel utilisateur
JAUDT
JAUDT SW GII 6406 Series Guide rapide
Spektrum
Spektrum Air Module System Manuel utilisateur
BOC Edwards
BOC Edwards Q Series Manuel utilisateur
