Vermont Castings VCS3505 Manuel utilisateur

50002972 7/05 Rev. 5 En

USER’S MANUAL

for

Gas Barbecue Grill

Models

VCS3505, VCS3505BI, VCS4005, VCS5005/5010,

VCS5005BI, VCS6005

CERTIFIED

Page i

FOR YOUR SAFETY

If you smell gas:

• Shut off gas to the appliance;

• Extinguish any open ﬂame;

• Open lid;

• If odor continues, immediately call your gas supplier or ﬁre department.

FOR YOUR SAFETY

Do not store or use gasoline or other ﬂammable vapors and liquids in

the vicinity of this or any other appliance.

An LP cylinder not connected for use shall not be stored in the vicinity

• Always read and understand the WARNINGS and SAFETY INSTRUCTIONS that

are contained in this Manual before attempting to use this Gas Barbecue Grill, to

prevent possible bodily injury or property damage.

• Always keep this Manual in or near the Grill, for convenient future reference.

Warnings

SIGNAL WORDS:

The Signal Words used in this Manual, and their intended meanings, are as follows :

DANGER: Indicates that a failure to observe the safety instructions could result in death or cata-

strophic bodily injury.

WARNING: Indicates that a failure to observe the safety instructions could result in serious bodily

injury.

CAUTION: Indicates that a failure to observe the safety instructions could result in property dam-

age or minor bodily injury.

NOTE: Designates important information relating to the safe use of the Grill.

IMPORTANT WARNINGS:

Since this outdoor cooking appliance is movable, is fueled by natural or propane gas, generates

very high temperatures for cooking and emits carbon monoxide as a by-product of combustion,

prudent precautions must be taken to assure its safe use.

• DANGER: This Grill has been designed for OUTDOOR use only.

Never use this outdoor Grill inside any building, garage, shed or breezeway, or inside any boat,

trailer or recreational vehicle, to prevent a possible ﬁre and to prevent the possibility of carbon

monoxide poisoning or asphyxiation

• DANGER: Exposing an overﬁlled or a disconnected propane cylinder to heat could cause

venting of fuel through the pressure release valve. Since propane vapor is heavier than air it

tends to pool and, if ignited, could produce a violent ﬁre or explosion.

Never install a propane cylinder if it is more than 80% full, as the contents may lack adequate

room for expansion when exposed to heat.

Never store a spare Propane Gas Cylinder in the cylinder compartment of this Grill, because it will

be exposed to high temperatures when the Grill is in use.

This Gas Barbecue Grill will provide you with many hours of pleasure and enjoyment, if it is used

in accordance with the Warnings and Safety Instructions contained in this Manual.

The essential Warnings and Safety Instructions are located throughout the pages of this Manual,

but some of the principal ones have been summarized below for your convenience:

Page ii

Warnings

A. SAFE LOCATIONS FOR USE OF THIS OUTDOOR GRILL

DANGER:

• Never use this outdoor Grill inside any building, garage, shed or breezeway, or inside any boat,

trailer or recreational vehicle, to prevent a possible ﬁre and to prevent the possibility of carbon

monoxide poisoning or asphyxiation.

WARNINGS:

• Always conﬁrm that this Grill is not positioned under a combustible object (e.g., an awning or

umbrella) or in a covered area (e.g., a porch or gazebo) before lighting it, to prevent a possible

ﬁre.

• Always conﬁrm that this Grill is not positioned under the overhang of a house, a garage or

other structure before lighting it. An overhang will serve to deﬂect ﬂare-ups and radiated heat

into the structure itself, which could result in a ﬁre.

• Always conﬁrm that this Grill is positioned

more than 36” (1 m) away from any combusti-

ble materials or surfaces before lighting it, and

that no gasoline or other volatile substances

are stored in the vicinity of this Grill. The

temperature of a grease ﬁre or of the radiated

heat might otherwise be sufﬁcient to ignite

nearby combustibles or volatile substances.

• Always locate this Grill where there will be

ample combustion and ventilation air, but

never position it in the direct path of a strong

wind.

• Never allow the Grill to operate while unat -

tended, to prevent uncontrolled grease ﬁres

from erupting.

Never attempt to move this Grill while it is in

operation or while it is still hot, to prevent possible

personal injury.

• Never store or use gasoline or other ﬂammable

or volatile substances in the vicinity of this Grill or in the vicinity of any other

heat-generating appliance, because of the danger of starting a ﬁre.

• Always conﬁrm that the installation of this Grill conforms with the requirements of all local

Codes or, in the absence of any applicable local Codes, with either the National Fuel Gas Code,

ANSI Z223.1/NFPA54, or CAN/CGA-B149.1, Natural Gas and Propane Installation Code.

Page iii

Warnings

Fig. 1

(

)

(

”

)

(

”

B. SAFE USE OF LP (PROPANE) GAS

DANGER:

• Never install a propane cylinder that is more than 80 % full, as the contents may lack adequate

room for expansion when exposed to heat. Propane vapor may then be vented through the pres-

sure release valve, which could accumulate in a pool and later result in a ﬁre or explosion.

Always instruct your certiﬁed propane fuel supplier to conﬁrm by weight that your cylinder

is not more than 80 % full. An empty cylinder will weigh about 18 lb., while a properly ﬁlled

cylinder should weigh no more than 38 lb.

• Never store a spare Propane Cylinder in the cylinder compartment of this Grill. Exposing a

disconnected cylinder to heat could result in the venting of propane vapor through the pressure

release valve, and the pooled vapor could result in a violent ﬁre. (No hazard is posed by the

connected cylinder if it is not overﬁlled, however, as it tends to refrigerate itself while it is being

used.)

Always conﬁrm that all openings in the cylinder compartment of this Grill are free of any ob-

structions that would restrict the circulation of ventilation air. Good ventilation will prevent the

pooling of leaked propane vapor, which is heavier than air, and which could explode if ignited.

WARNINGS:

• Always consult the Rating Label on the back of the Grill to conﬁrm which fuel must be

used with the Grill. Never operate the Grill with propane gas if it has been conﬁgured

to use natural gas, to prevent hazardous overheating.

• Always conﬁrm that there are no gas leaks before lighting this Grill. Apply a 50/50

solution of liquid soap and water to the gas supply line connectors with a brush or spray

bottle, and watch for bubbles. Never use a match or open ﬂame to test for gas leaks.

• Always visually inspect the gas supply line for fraying, cracking or rodent damage

before each use of this Grill and, if necessary, install a replacement obtained from your

dealer before lighting this Grill.

Always store your spare Propane Gas Cylinders in an outdoor area that is well-ventilated, shady,

cool and removed from any heat source. Always store those cylinders in an upright position.

Never store a spare cylinder in the vicinity of this Grill, or in the vicinity of any other heat-gener-

ating appliance.

C. SAFE USE OF NATURAL GAS

• Always consult the Rating Label on the back of the Grill to conﬁrm which fuel must be used

with the Grill. Never attempt to operate the Grill with natural gas if it has been conﬁgured to

use propane gas, to prevent possible bodily injury.

• Always employ a qualiﬁed service agency to install all necessary gas supply plumbing, for

safety reasons and to assure compliance with all applicable Codes.

Page iv

Warnings

• Always promptly shut off the gas supply and immediately extinguish all ﬂames if you smell gas.

Always seek assistance from your gas supplier or local Fire Department if the gas smell persists,

because of the danger of ﬁre or explosion.

• Always conﬁrm that there are no gas leaks before lighting this Grill. Apply a 50/50 solution of

liquid soap and water to the gas supply line connectors with a brush or spray bottle, and watch

for bubbles. Never use a match or open ﬂame to test for gas leaks.

• Always visually inspect the gas supply line for fraying, cracking or rodent damage before each

use of this Grill and, if necessary, install a replacement before lighting this Grill.

• Never permit a gas supply line to contact any heated surface of this Grill.

D. PREVENTION OF BURNS

• Always keep children and pets under close supervision when using this Grill, and never permit

them to come near the Grill while it is in use, as the exterior surfaces will be very hot.

• Always wear insulated protective mitts when working at the Grill, or when attempting to close

a gas supply valve after cooking has been completed, to prevent possible burns. Always use

insulated pot holders when handling containers of hot food.

• Always wear an insulated protective mitt when adding a smoking agent to a Smoker Box.

• Never store or use gasoline or other ﬂammable or volatile substances in the vicinity of this Grill,

or in the vicinity of any other heat-generating appliance.

E. ELECTRICAL SAFETY

• Always conﬁrm that this Grill has been grounded in accordance with local Codes or, in the

absence of local Codes, with the National Electrical Code, ANSI/NFPA No. 70 or the Canadian

Electrical Code, CSA C22.1, when an external electrical source is being utilized for the Rotis-

serie Motor.

• Always use a grounded three-prong outlet and a three-prong extension cord to energize the Ro-

tisserie Motor. Never alter or remove the grounding prong on the Rotisserie Power Cord, as an

electric shock hazard would then result.

• Never permit an electrical supply cord to contact any heated surface of this Grill.

Safety

Page v

Safety Important Warnings ..................................................... i - v

Clearance Requirements ................................................. ii

Table of Contents ............................................................1

Fuels .................................................................................2

Safety ...............................................................................3

Gas Hookup Hooking Up to the Gas Supply ........................................4

LP Gas Supply Connection ..............................................4

Natural Gas Supply Connection .......................................5

Test for Leaks ...................................................................5

Operation Control Functions .............................................................6

Lighting the Main Burners ...............................................7

Turning the Burners Off ..................................................8

Flare-ups ..........................................................................8

Match Lighting the Main Burner .....................................8

Lighting the Rotisserie Burner .........................................9

Match Lighting the Rotisserie Burner ..............................9

Rotisserie Setup .............................................................10

Lighting the Side Burner ................................................11

Shutting the Side Burner Off .........................................11

Cooking Methods of Cooking ......................................................12

Preparing Food for the Grill .........................................13

Grilling Tips ..................................................................14

Cooking Time Chart .....................................................15

Care & Burners ...........................................................................18

Maintenance Rotisserie Burners ..........................................................19

Side Burners ...................................................................19

Cooking Grids .................................................................19

Drip Tray .......................................................................20

Stainless Steel Panels .....................................................20

Porcelain Enamel Castings ............................................20

Burner Adjustment ..........................................................21

Troubleshooting Guide .......................................................................22

Table of Contents

Page 1

FUELS

WARNING: Never use Natural Gas in a Grill that has been conﬁgured to burn Propane Gas, and never use

Propane Gas in a Grill that has been conﬁgured to use Natural Gas, to avoid possible bodily injury. Always

consult the Rating Label on the back of your Grill to conﬁrm which fuel must be used with the Grill.

WARNING: Use only the pressure regulator and type I propane gas supply coupling and hose that is

originally provided with this appliance or as speciﬁed, (see Fig. 2).

ADDITIONAL WARNINGS:

• Always install a 20 lb. propane cylinder that is equipped with

a type I valve outlet (see Fig. 3), and that has a 12” diameter

and an 18” height. Always use a propane cylinder that has

been constructed and marked in conformance with either the

speciﬁcations for LP Gas Cylinders of the U.S. Department of

Transportation or the speciﬁcations in the National Standard

of Canada, CAN/CSA-B339, Cylinder, Spheres and Tube for

Transportation of Dangerous Goods, as applicable.

• Always conﬁrm that your propane cylinder is equipped with

a shutoff valve terminating in a Type I propane cylinder valve

outlet connection, and that it has been provided with a collar

to protect the cylinder valve.

• Never install a propane cylinder in this Grill unless it is

equipped with a listed Overﬁll Protection Device (OPD).

• Always have a new propane cylinder properly purged of air

by your certiﬁed propane gas dealer. Since a new cylinder is

initially ﬁlled with air, the air must ﬁrst be purged before it is

ﬁlled with propane.

• Always visually inspect the gas supply line for fraying,

cracking or rodent damage before each use of this Grill and,

if necessary, install a replacement obtained from your dealer

prior to lighting this Grill.

Safety

Page 2

Fig. 3

Check hose for breaks or wear

before each use.

Type I Con-

nector

Regulator

Shutoff Valve

Collar

Fig. 2

DANGER:

a) Do not store a spare LP - Gas Cylinder under or near this appliance

b) Never ﬁll the cylinder beyond 80% full; and

c) If the information in a) and b) is not followed exactly, a ﬁre causing death or serious injury may oc-

cur.

WARNING: Always conﬁrm that the openings in the cylinder compartment of the Grill are free of any

obstructions that would restrict the circulation of ventilation air. Good ventilation will prevent any possible

accumulation of leaked propane vapor, which is heavier than air and which could explode if ignited.

NOTE: Always have a certiﬁed propane gas supplier inspect and re-qualify your reﬁllable propane gas

cylinder prior to each reﬁlling, in accordance with DOT or TC requirements for propane cylinders.

ADDITIONAL WARNINGS:

• Always handle propane cylinders with great care, as the contents are under high pressure.

• Always close the propane cylinder valve promptly after each use of the Grill.

• Always store propane cylinders outdoors, in an upright, secure position, out of direct sunlight, away

from living quarters and in a well-ventilated, cool, dry area. NEVER STORE A CYLINDER IN A

BUILDING, GARAGE OR OTHER STRUCTURE OR ENCLOSED AREA.

• Always keep cylinders out of reach of children.

• Always conﬁrm that a valve dust cap has been tightly installed and that the valve itself is fully

closed, whenever a propane cylinder has been disconnected.

• Always transport a propane cylinder in an upright, secure position, after conﬁrming that its valve is

closed.

• Always stabilize a cylinder so that it cannot move, when it is being transported in a car trunk.

• Never transport a propane cylinder in the passenger compartment of a car or truck.

• Never store a Gas Grill indoors, unless the propane cylinder has ﬁrst been disconnected and re-

moved from the Grill.

• Never expose a propane cylinder to any heat source, never apply heat directly to a cylinder and

never store a spare cylinder in the vicinity of this Grill.

• Never paint a propane cylinder a dark color, as this can cause the cylinder and its contents to over-

heat.

• The LP cylinder must be arranged for vapor withdrawal.

Page 3

Safety

Hooking Up to the LP (Propane) Gas

Supply

FOR YOUR SAFETY

1. WARNING: Never store or use gasoline or any

other volatile substance in the vicinity of this

Grill.

2. WARNING: Never store a spare propane cylinder

in the vicinity of this Grill, or in the vicinity of any

other potential heat source.

LP (PROPANE) GAS SUPPLY CONNECTION

1. Always place the propane tank in the tank

locator hole in the bottom pan of the cylinder

compartment.

2. Always conﬁrm that all burner control knobs

are in the OFF position before activating the gas

supply.

3. Always connect the gas supply regulator as

follows:

• Insert the nipple of the valve coupling into

the tank valve and tighten the connection

collar by turning it clockwise with one hand

while holding the regulator with the other (see Fig. 4).

WARNING: Always conduct a leak test before lighting the Grill,

to prevent a possible ﬁre or explosion (see page 5).

Gas Hookup

Page 4

Fig. 5

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Vermont Castings Gril

Vermont Castings

Vermont Castings VM400 Manuel utilisateur

Vermont Castings

Vermont Castings Signature VCS301 Series Manuel utilisateur

Vermont Castings

Vermont Castings VANGUARD XE G54006 Manuel utilisateur

Vermont Castings

Vermont Castings Signature VCS5008 Series Manuel utilisateur

Vermont Castings

Vermont Castings Signature Series Manuel

Vermont Castings

Vermont Castings PIONEER Manuel utilisateur

Vermont Castings

Vermont Castings VCS3008B Series, VCS3008BI Series, VCS4008 Series, VCS5008 Series,... Manuel

Vermont Castings

Vermont Castings Signature VCS4027 Manuel utilisateur

Vermont Castings

Vermont Castings VCT223SSP Manuel

Vermont Castings

Vermont Castings VANGUARD G53901 Manuel utilisateur

Vermont Castings

Vermont Castings CF9050 Manuel utilisateur

Vermont Castings

Vermont Castings Signature VCS5037 Manuel utilisateur

Vermont Castings

Vermont Castings Signature VCS5027 Manuel utilisateur

Vermont Castings

Vermont Castings Signature VCS310 Series Manuel utilisateur

Vermont Castings

Vermont Castings VCS4006 Manuel

Vermont Castings

Vermont Castings Signature VCS301 Series Manuel

Vermont Castings

Vermont Castings Signature VCS310 Series Manuel utilisateur

Vermont Castings

Vermont Castings Signature VCS5017 Manuel utilisateur

Vermont Castings

Vermont Castings CF9030 Manuel utilisateur

Vermont Castings

Vermont Castings Signature VCS4005 Manuel

Vermont Castings

Vermont Castings VANGUARD G53903 Manuel utilisateur

Vermont Castings

Vermont Castings VCS Series Manuel utilisateur

Vermont Castings

Vermont Castings VC750PG1 Instructions d'installation

Vermont Castings

Vermont Castings VCS3506BI Manuel utilisateur

Manuels Gril populaires d'autres marques

Orbegozo

Orbegozo GR 2300 Manuel utilisateur

bora

bora PT11 Manuel utilisateur

Klarstein

Klarstein 10031664 Manuel utilisateur

Garland

Garland MWE3W Manuel utilisateur

Char-Broil

Char-Broil 463722714 Manuel utilisateur

Nexgrill

Nexgrill 720-0830HK Manuel utilisateur

Kenmore

Kenmore 415.16123800 Manuel utilisateur

Camp Chef

Camp Chef PG24CLAU Manuel utilisateur

Tucker Barbecues

Tucker Barbecues GTR Series Instructions de montage

Monogram

Monogram ZGG540NCP1SS Manuel utilisateur

Equipex

Equipex Sodir Savoy Manuel utilisateur

Gaggenau

Gaggenau VR 414 610 Manuel utilisateur

Miele

Miele KM 408-1 Manuel utilisateur

George Foreman

George Foreman GGR50B Manuel utilisateur

AOG

AOG T series Manuel utilisateur

Gorenje

Gorenje TG2000CB Mode d’emploi

Weber

Weber Genesis Silver-B Permamount NG 051701 Manuel utilisateur

Glen

Glen SA 3037 Manuel utilisateur
