Verizon Fios-G1500 Manuel utilisateur

Fios Router

USER

GUIDE

CONTENTS

01/

INTRODUCTION

1.0 Package 

Contents

1.1 System 

Requirements

1.2 Features 

1.3 Getting to 

Know Your

Gateway

02/

CONNECTING

YOUR GATEWAY

2.0 Setting Up 

Your Gateway

2.1 Computer 

Network

Conﬁguration

2.2 Main Screen 

03/

WIRELESS SETTINGS

3.0 Overview 

3.1 Wireless Status 

3.2 Basic Security 

Settings

3.3 Advanced 

Security Settings

3.4 Wireless MAC 

Authentication

3.5 802.11 Mode 

3.6 Other Advanced 

Wireless Options

3.7 Guest Wi-Fi 

Settings

04/

CONFIGURING MY

NETWORK SETTINGS

4.0 Accessing My 

Network Settings

4.1 Using My Network 

Settings

TABLE OF CONTENTS

05/

USING NETWORK

CONNECTIONS

5.0 Accessing 

Network

Connections

5.1 Network 

(Home/Oce)

Connection

5.2 Broadband 

Connection

5.3 Wireless 

Access Point

Connection

5.4 Broadband 

Ethernet/Coax

Connection

06/

CONFIGURING

SECURITY SETTINGS

6.0 Firewall 

6.1 Access Control 

6.2 Port Forwarding 

6.3 Port Triggering 

6.4 DMZ Host 

6.5 Remote 

Administration

6.6 Static NAT 

6.7 Security Log 

07/

SETTING PARENTAL

CONTROLS

7.0 Activating 

Parental Controls

7.1 Rule Summary 

7.2 Activating Advanced 

Parental Controls

CONTENTS

08/

CONFIGURING

ADVANCED SETTINGS

8.0 Using Advanced 

Settings

8.1 Utilities 

8.2 DNS Settings 

8.3 Network 

Settings

8.4 Routing 

8.5 Date and Time 

8.6 Conﬁguration 

Settings

09/

MONITORING

YOUR GATEWAY

9.0 Gateway Status 

9.1 Advanced Status 

9.2 System Logging 

9.3 Full Status/System 

wide Monitoring

of Connections

9.4 Trac 

Monitoring

9.5 Bandwidth 

Monitoring

10/

TROUBLESHOOTING

10.0 Troubleshooting 

Tips

10.1 Frequently 

Asked Questions

TABLE OF CONTENTS

11/

SPECIFICATIONS

11.0 General 

Speciﬁcations

11.1 LED Indicators 

11.2 Environmental 

Parameters

12/

NOTICES

12.0 Regulatory 

Compliance

Notices

Package Contents

System Requirements

Features

Getting to Know Your

Gateway

1.0

1.1

1.2

1.3

INTRODUCTION

01/

/ INTRODUCTION

The Verizon Fios Router lets you

transmit and distribute digital

entertainment and information to

multiple devices in your home/oce.

Your Gateway supports networking

using coaxial cables, Ethernet, or Wi-Fi,

making it one of the most versatile and

powerful gateways available.

PACKAGE CONTENTS, SYSTEM

REQUIREMENTS AND FEATURES

1.0/ PACKAGE CONTENT

Your package contains:

• The Fios Router

• Power adapter

• LAN Ethernet cable (yellow)

• WAN Ethernet cable (white)

• Quick Start Guide

1.1/ SYSTEM REQUIREMENTS

System and software requirements are:

• A computer or other network device supporting Wi-Fi or wired

Ethernet

• A web browser, such as Chrome™, Firefox®, Internet Explorer 8®

or higher, or Safari® 5.1 or higher

1.2/ FEATURES

Your Gateway features include:

• Support for multiple networking standards, including

–WAN – Gigabit Ethernet and MoCA 2.0 interfaces

– LAN – 802.11 b/g/n/ac, Gigabit Ethernet and MoCA 2.0

interfaces

• Integrated wired networking with 4-port Ethernet switch and

Coax (MoCA)

/ INTRODUCTION

– Ethernet supports speeds up to 1000 Mbps

– Bonded MoCA 2.0 and 1.1 enabled to support speeds up to

800 Mbps over coaxial cable

• Integrated wireless networking with 802.11b/g/n/ac access point

featuring:

– Enabled 802.11b capable speeds (based on device)

– Enabled 802.11g capable speeds (based on device)

– Enabled 802.11n capable speeds (based on device)

– Enabled 802.11ac capable speeds (based on device)

• Enterprise-level security, including:

– Fully customizable ﬁrewall with Stateful Packet Inspection

(SPI)

– Content ﬁltering with URL-keyword based ﬁltering,

parental controls, and customizable ﬁltering policies per

computer

– Intrusion detection with Denial of Service protection

against IP spooﬁng attacks, scanning attacks, IP fragment

overlap exploit, ping of death, and fragmentation attacks

– Event logging

– MAC address ﬁltering

– Static NAT

FEATURES AND GETTING

TO KNOW YOUR GATEWAY

– Port forwarding

– Port triggering

– Access control

– Advanced wireless protection featuring WPA2/WPA Mixed

Mode, WEP 64/128 bit encryption, and MAC address

ﬁltering

• Options, including:

– DHCP server

– WAN interface auto-detection

– Dynamic DNS

– DNS server

– LAN IP and WAN IP address selection

– MAC address cloning

– IPv6 support

– QoS support (end to end layer 2/3) featuring:

Dierentiated Services (Diserv), 802.1p/q prioritization,

and pass-through of WAN-side DSCPs, Per Hop Behaviors

(PHBs), and queuing to LAN-side devices

– Remote management and secured remote management

using HTTPS

– Static routing

– VPN (VPN pass through only)
