Fios Router

USER

GUIDE

CONTENTS

01 /

INTRODUCTION

 Package Contents 

 System Requirements 

 Features 

 Getting to Know Your

Fios Router 

02 /

CONNECTING YOUR FIOS

ROUTER

 Setting up Your Fios

Router 

 Expanding Wi-Fi

coverage 

 Computer Network

Conﬁguration 

 Main Screen 

03 /

WIFI SETTINGS

 Overview 

 Wi-Fi Status 

 Basic Settings 

 Advanced Settings 

 Channel Settings 

 Guest Network 

04 /

CONFIGURING NETWORK

SETTINGS

 Accessing Network

Settings 

 Using Network

Settings 

TABLE OF CONTENTS

05 /

USING NETWORK

CONNECTIONS

 Accessing Network

Connections 

 Network (Home/Oce)

Connection 

 Wi-Fi Access Point

Connection 

 Ethernet Connection 

 Broadband Connection

(Ethernet/Coax) 

06 /

SETTING PARENTAL

CONTROLS

 Activating Parental

Controls 

 Rule Summary 

07 /

CONFIGURING SECURITY

SETTINGS

 Firewall 

 Access Control 

 Port Forwarding 

 Port Triggering 

 DMZ Host 

 Static NAT 

 IPv Pinholes 

08 /

CONFIGURING ADVANCED

SETTINGS

 Using Advanced

Settings 

 Utilities 

 Network Settings 

 Date And Time 

 DNS Settings 

 Monitoring 

 System Settings 

CONTENTS

09 /

TROUBLESHOOTING

 Troubleshooting

Tips 

 Frequently Asked

Questions 

10 /

SPECIFICATIONS

 General

Speciﬁcations 

 LED Indicators 

 Environmental

Parameters 

11 /

NOTICES

 Regulatory Compliance

Notices 

01 /

INTRODUCTION

1.0 Package Contents

1.1 System Requirements

1.2 Features

1.3 Getting to Know Your

Fios Router

 / INTRODUCTION

Verizon Fios Router lets you transmit

and distribute digital entertainment and

information to multiple devices in your

ofﬁce.

Your Fios Router supports networking

using coaxial cables, Ethernet, or Wi-Fi,

making it one of the most versatile and

powerful routers available.

PACKAGE CONTENTS

./ PACKAGE CONTENTS

Your package contains:

• Fios Router

• Power adapter

• Ethernet cable, three meters (white)

• OSS (Open Source Software) insert guide

./ SYSTEM REQUIREMENTS

System and software requirements are:

• A computer or other network device supporting Wi-Fi or wired

Ethernet

• A web browser, such as Chrome™, Firefox®, Internet Explorer 8®

or higher, or Safari® 5.1 or higher

./ FEATURES

Your Fios Router features include:

• Support for multiple networking standards, including

– WAN – Gigabit Ethernet and MoCA 1.1 interfaces

– LAN – 802.11 a/b/g/n/ac/ax, Gigabit Ethernet and MoCA 2.5

interfaces

• Integrated wired networking with 4-port Ethernet switch and

Coax (MoCA)

– Ethernet supports speeds up to 1000 Mbps

PACKAGE CONTENTS, SYSTEM

REQUIREMENTS AND FEATURES

 / INTRODUCTION

– MoCA 2.5 LAN enabled to support speeds up to 2500 Mbps

over coaxial cable

– MoCA 1.1 WAN enabled to support speeds up to 100 Mbps

over coaxial cable

• One USB 3.0 port

• IoT - Bluetooth

• Integrated Wi-Fi networking with 802.11a/b/g/n/ac/ax access

point featuring:

– backward compatible to 802.11a/b/g/n/ac

– 2.4 GHz 11ax 4x4

– two 5 GHz 11ax 4x4

• Enterprise-level security, including:

– Fully customizable ﬁrewall with Stateful Packet Inspection

(SPI)

– Content ﬁltering with URL-keyword based ﬁltering, parental

controls, and customizable ﬁltering policies per computer

– Intrusion detection with Denial of Service protection against

IP spooﬁng attacks, scanning attacks, IP fragment overlap

exploit, ping of death, and fragmentation attacks

– Virtual server functionality; providing protected access to

internet services such as web, FTP, email, and telnet

– DMZ (demilitarized zone) host support of a network security

neutral zone between a private network and the internet

– Event logging

FEATURES

– Static NAT

– Port forwarding

– Port triggering

– Access control

– Advanced Wi-Fi protection featuring WPA2 & WPA3 Modes

and MAC address ﬁltering

– Wi-Fi Multimedia (WMM) for Wi-Fi QoS (quality-of-service)

• Compatible with Wi-Fi Mesh system

• Dual-stack network conﬁguration of IPv4 and IPv6

• DHCP server

• WAN interface auto-detection

• Dynamic DNS

• DNS server

• LAN IP and WAN IP address selection

• MAC address cloning

• QoS support (end to end layer 2/3) featuring: Dierentiated

Services (Diserv), 802.1p/q prioritization, and pass-through of

WAN-side DSCPs, Per Hop Behaviors (PHBs), and queuing to

LAN-side devices

• Secure remote management using HTTPS or My Fios app

• Static routing

• VPN (VPN pass through only)

• IGMP

• Daylight savings time support

 / INTRODUCTION

./ GETTING TO KNOW YOUR FIOS ROUTER

1.3a/ FRONT PANEL

The front panel’s uniﬁed button allows quick access to the Wi-Fi

Protected Setup (WPS) feature and pairing mode.

The Router Status LED will be solid

white when your Fios Router is turned

on, connected to the internet, and

functioning normally.

Router Status LED

Condition Status LED Color Fios Router

Normal WHITE Normal operation (solid)

Router is booting (fast blink)

BLUE Pairing mode (slow blink)

Pairing successful (solid)

GREEN Wi-Fi has been turned o (solid)

Issue(s) YELLOW No internet connection (solid)

RED Hardware/System failure detected (solid)

Overheating (fast blink)

Pairing Failure (slow blink)

Power OFF Power o

The WPS button is used to initiate Wi-Fi Protected Setup. This is an

easy way to add WPS capable devices to your Wi-Fi network. To

activate the WPS function, press and hold the uniﬁed button located

on the front of your Fios Router for more than two seconds. When

WPS is initiated from your router, the Router Status LED slowly

ﬂashes blue for up to two minutes, allowing time to complete the
