VRC801D2

UNIVERSAL 8-IN-1 REMOTE CONTROL WITH BLUE LCD DISPLAY

USER MANUAL

VRC801D2 VELLEMAN

Introduction

To all residents of the European Union

Important environmental information about this product

This symbol on the device or the package indicates that disposal of the device after its

lifecycle could harm the environment. Do not dispose of the unit (or batteries) as

unsorted municipal waste; it should be taken to a specialized company for recycling.

This device should be returned to your distributor or to a local recycling service. Respect the

local environmental rules.

If in doubt, contact your local waste disposal authorities.

Congratulations on purchasing the universal 8 in 1 remote control. The universal 8 in 1 remote

control is able to control almost all makes of TV set(TV), DVD and DVR-players (DVD),

DVB receivers ,(digital) Satellite receivers and Cable receivers(DVB), Video Recorders (VCR),

Tuners (TUNER), cassette decks(TAPE), CD players (CD), Audio amplifiers and other Audio

devices (AUX).

The remote control controls the basic device functions which has been set. It is not intended to

replace all the functions of your original remote control.

Please keep this user manual for future reference.

Device Code Assignment

Bank for Device Initial code Total of codes

TV TV 048 488

488488

488

VCR VCR 075

075075

075 182

182182

182

DVB Satellite, Cable, DVB 413 41

4141

413

DVD DVD,DVR 026 190

190190

190

CD CD 035 124

124124

124

TUNER TUNER 039 114

114114

114

TAPE TAPE 067

067067

067 134

AUX AMP, LD，

，，

，VCD 032 204

204204

204

Total codes: 1849

VRC801D2 VELLEMAN

The Device Key

SET To start the remote control set-up or to display the status on the LCD screen.

LEARN To set the learn functions.

TV VCR DVB CD DVD TUNER TAPE AUX To select the device which you wish to

control.

POWER Switches the device on and off.

0-9 The number keys function just like the number keys on your original remote control.

Works like the enter on your original remote.

AV Works like the TV/Video key on your original TV remote, and TV/SAT key on your

original satellite remote A.B in cable and CD modes.

MENU Functions just like the Menu or OSD (on-screen display) or Memory key on your

original remote control.

Show View function scans all channels for you to have a program quick view.

All off function can turn on or turn off all your devices with one button.

Macro function carries out several successive operations via one button for your home

entertainment centre.

CH±

±±

±Functions just like the Channel Up/Down keys on your original remote control.

VOL±

±±

±To Control the volume, functions just like the Volume Up / Down on your original

remote control.

Key to mute the sound

REW（fast reverse）

PLAY (Controls DVD or CD)

FFWD

REC

STOP(Stops the operation)

PAUSE (Stops the operation and standby mode)

OK EXIT Functions just like the UP，DOWN，LEFT，RIGHT，

OK and EXIT Keys on your original remote control for menu function. During the set up

mode they are only used as a cursor for confirming and exiting remote control programming.

VRC801D2 VELLEMAN

RED YELLOW BLUE GREEN for TV Fast Text.

Television video

TV and text mixed

Teletext mode

Page hold

Direct Set Up (by Brand name and Code)

If you know the brand name of the device, it can be set up directly( direct search on the screen

via brand name and code selection).

1. Switch on the device (e.g. TV, DVD) which you wish to control, if the device is VCR, please

insert a video cassette.

2. Press and hold the SET key on the remote control. Simultaneously press a device key (e.g.

TV, DVD…)

3. Release the pressed keys, the brand name is displayed on the LCD screen.

4. Press UP or DOWN key to select the device brand name (e.g. Your TV set brand: Life)

5. Check whether the keys are functioning correctly (e.g. Power, CH+, CH-, VOL+, VOL-,

Mute). If none of the new remote control keys function correctly or the majority of the keys

do not function correctly, try out another code by pressing

or key until all basic

functions function correctly.

6. Once you are satisfied with the code, simply press OK to save it. Success is displayed on the

LCD screen and the set-up is exited. You can press device key again to exit SET UP or use

UPor DOWN to select another set-up.

Remark:

1. To return to initial status, press the EXIT key or the device key (e.g. TV, or VCR…)

2. When testing key functioning, aim the remote control at the device which you wish to control.

During set-up, the OK

, EXIT keys are only used to set up your new remote control.

These keys can not be used for normal menu functions until you exit set-up.

4. If the device has been locked, it has to be unlocked before you can carry out the set-up.

Set-up by Auto Search

If set-up via brand name and code has been unsuccessful or if you can not find the brand name

on the remote control screen, you can also use the Auto Search function to find the right code

for your device.

VRC801D2 VELLEMAN

1. Switch on the device (e.g. TV, DVD) which you wish to control, if the device is VCR, please

insert a video cassette.

2. Press the SET key on your remote control for more than 3 seconds before releasing it.

3. Press the UP or DOWN keys to select to CODE SETUP in the LCD menu, and press the

OK key.

4. The screen shows the DEV SEARCH in the LCD menu, and press OK key, then press

device key

to select your desired operation device(e.g. TV) and then press OK key to start the

Auto Search.(In this case, you have to aim the remote control directly at the device which

you wish to control)

5. Check whether the device reacts or not. As soon as the device reacts, press any key to stop

the search.

6. Check whether majority of the keys function correctly or not. If the majority of the keys do

not function correctly, please press UP or DOWN key to select another code.

7. Once you are satisfied with the code, simply press OK to save it. Success is displayed on the

LCD screen and the set-up is exited. You can press device key again to exit SET UP or use

UPor DOWN to select another set-up.

Remark:

1. If you did not manage to stop the search when the device reacted, use the UP or DOWN

key to search for the code again.

2. During the automatic search, the OK, EXIT keys are only used to set up

your new remote control. These keys can not be used for normal menu functions until you

exit set-up.

3. Once the remote control has searched all the codes, it stops the search at the first code.

4. If the device has been locked, it has to be unlocked before you can carry out the set-up.

Set-up by Enter Code

1. Switch on the device (e.g. TV, DVD) which you wish to control.

2. At the back of this user manual there is a list of brand names and code numbers for your

device make (e.g. Lifetec 003,010,062).

3. Press the SET key on your remote control for more than 3 seconds before releasing it.

4. Press UP or DOWN keys to select to CODE SETUP in the LCD menu, and press the OK

key.

5. The screen shows the DEV SEARCH in the LCD menu, press the UP or DOWN keys to

select CODE SETUP in the LCD menu, and press OK key.

6. Subsequently press the device key of the device which you wish to control (e.g. TV, DVD…)

and then press OK. Now enter the 3-figure code (eg.003 for Lifetec TV set).

7. Press OK to save the code and Success is displayed on the LCD screen. Press exit twice to

exit set-up mode.

8. Check whether majority of the keys function correctly or not. If the majority of the keys do

not function correctly, please press try another 3-figure code (e.g. 010…) listed under the

same brand name in the code list. Repeat steps 3 to 7 until all basic functions function

VRC801D2 VELLEMAN

correctly. You can press any device key again (e.g. TV) to exit set-up or use UP or DOWN to

select another set-up.

Learning

The learning function is used to extend the pre-programmed code list. The default code list

may provide all required functions, but it is still possible to add a small number of additional

functions for your new remote control. Use the learn key to program commands or the Delete

key to delete programmed commands, or select DeleteDev to delete all the commands for a

single device, or Delete All to delete all the programmed commands of all the devices in the

learning class. Press the Learn key for more than 3 seconds to access the learn mode.

Programming a Command

1. Press the respective device key (e.g. TV) of the device which you wish to carry

out programming

2. Press he SET key for more than 3 seconds, then release it (or Press the Learn key for more

than 3 seconds to access the learn mode).

3. Press the UP and Down key to select Learning in the LCD menu, then press the OK key.

4. Press the UP or DOWN key to select Learn Key in the LCD menu and then press OK.

The Select key is displayed on the LCD screen. If you wish to exit the learning mode, please

Press the device key.

5. Select the (target) key which you wish to program (e.g. Power).Waiting is displayed on the

LCD screen..

6. Aim the IR window of the original remote control at the IR receiver window of your new

remote control (Distance approx. 50mm)

7. Press the original remote control key (e.g. Power) until Success is displayed. If failed is

displayed on the LCD screen, Repeat Steps 4-6.

8. Repeat Steps 4-6 to program other keys.

9. Press a device key (e.g. TV) to exit the learning operation once all the desired commands

have been programmed.

Remark:

A programmed target key can programmed from various source keys more than once.

This remote control only Saves the most recently programmed signal.

VRC801D2 VELLEMAN

2. All usual function keys can be learnt except Show View Macro, Set, Learn,All off .

3. You may not be able to program some codes formats from this remote control.

4. It is possible to program approx. 100keys for 8 devices.

Deleting programmed Key

If you wish to delete a programmed command, proceed as follows:

1. Press the device key (e.g. TV) of the device at which the command is to be deleted.

2. Press the SET key for more than 3 seconds before releasing it.

3. Press the UP or Down key to select Learning in the LCD menu, then press OK key.

4. Press the UP or Down key to select Delete Key in the LCD menu, then press OK key.

5. Press the remote control key which you wish to delete, SURE DELET is displayed on the

LCD Screen, press OK to confirm this query. Success is displayed on the LCD screen.

6. Repeat Step 4-5 to delete the next desired keys.

7. Press a device key (e.g. TV) to exit the deleting operation once all the desired remote

commands have been deleted.

Deleting All the programmed commands for a Device

If you wish to delete all the programmed commands in a device at once and not one after the

other, proceed as follows:

1. Press the device key (e.g. TV) of the device at which the command is to be deleted.

2. Press the SET key for more than 3 seconds before releasing it.

3. Press the UP or Down key to select Learning in the LCD menu, then press OK key.

4. Press the UP or Down key to select Delete DEV in the LCD menu, then press OK key.

5. Select the device which you wish to delete and press OK.

6. SURE DELET is displayed on the LCD screen, press OK key to confirm this query.

SUCCESS is displayed on the LCD screen.

7. Repeat step 5 to delete all the commands of another device key.

8. Press EXIT key to exit the deleting operation.

Remark: It will take about 3 minutes for delete all commands in one device. If the commands are not so

many, we suggest you delete commands one by one.

Deleting All the programmed Keys

If you wish to delete all the programmed commands in the remote control, proceed as follows:

1.Press the SET key for more than 3 seconds before releasing it.

2.Press the UP or DOWN key to select Learning in the LCD menu and then press OK.

3.Press the UP or DOWN key to select Delete All in the LCD menu and then press OK.

4.Sure Delet is displayed on the LCD screen, press OK to confirm this query.

Success is displayed on the LCD screen.

VRC801D2 VELLEMAN

The Macro Function

Setting up macros

Carry out successive operations for your home entertainment centre with the aid of the macro

function.

Set up a macro as follows:

1. Press SET key for more than 3 seconds before releasing it.

2. Press the UP or DOWN key to select Macro in the LCD menu and then press OK.

3. Press the UP or DOWN key to select Macro 1 or Macro 2 or Macro 3 in the LCD menu,

Subsequently press OK.

4. SET UP is displayed on the LCD screen, press OK to confirm.

SELECT KEY is displayed on the LCD screen.

5. You can select the device and function key for a successive operation (e.g. TV + POWER +

MUTE + AV, DVD + PLAY, VCR + RECORD, etc... You wish to switch the TV set on and

the sound off, switch the TV set and input to AV input, to start the DVD to play a disc while

the VCR starts recording at the same time).

6. Press OK to save the setting. Success is displayed on the LCD screen.

7. You can press any device key to exit set-up, or press the EXIT key to switch to the last

status or use the UP or DOWN key to select another set-up.

Remark:

1. A maximum of 10 commands can be set up in a macro.

2. Ensure that all the keys can transmit signals; otherwise, even if you have programmed these

Keys into the macro, the macro will not function correctly. Check key functioning before

setting up the macro by pressing them to see whether the device keys flash or not.

3. Please observe that certain conditions have to be fulfilled if you wish to carry out a macro.

For example, a disc or video cassette has to be inserted into the DVD player or VCR

respectively if you wish to play a DVD or tape a programme with the VCR.

Operate Macro

Press and hold Macro key and 1 key (or 2, 3 key) and then release them. The remote control

will send out a sequent IR commands that you programmed before.

Deleting Macro

1. Press SET key for more than 3 seconds before releasing it.

2. Press the UP or DOWN key to select Macro in the LCD menu and then press OK.

3. Press the UP or DOWN key to select Macro 2 in the LCD menu, and then press OK.

4. Press the UP or Down key to select Delete in the LCD menu and then press OK.

5. Sure Delete is displayed on the LCD screen. Press OK to confirm the deleting operation

VRC801D2 VELLEMAN

and Success is displayed on the LCD screen and you can return to the last status.

6. You can press any device key to exit the deleting operation, or press exit key to return to

the last status or use the UP or DOWN key to select another set-up.

Other Set Up

A. Setting the Clock

It is possible to set the clock of your LCD remote control, the clock will then be displayed on

the screen.

1. Press the SET key for more than 3 seconds before releasing it.

2. Press the UP or DOWN key to select CONFIGURE in the LCD menu, and then press the

OK.

3. Press the UP or DOWN key to select TIME SETUP in the LCD menu, and then press the

OK.

4. Press the or key to move the cursor to select hour or minute or AM/PM, then press

the number key to set hour and minute, and press the or key to select AM or PM.

5. Press OK key to save the setting and SUCCESS is displayed on the LCD screen for 1

second. Subsequently return to the current set up status. You can press any device key to exit

the set up or press exit key to return to the last state.

B. Volume Lock

This function is very handy if you only wish to use one device to control the volume. For

Example, you can use your amplifier as the main volume control and can use this function

to fix the AUX volume and mute key.

Irrespective of the device being used (TV, DVD, VCR, etc.) the remote control volume and

mute keys control the volume and mute of your amplifier.

1. Press the SET key for more than 3 seconds before releasing it.

2. Press the UP or DOWN key to select CONFIGURE in the LCD menu, and then press the

OK.

3. Press the UP or DOWN key to select VOL LOCK in the LCD menu, and then press the OK.

4. Press the device key to select the device which you wish to fix, e.g. AUX.

5. Press the or key to change to the ON or OFF mode.

6. Press OK key to save the setting and SUCCESS is displayed on the LCD screen.

Subsequently return to the current set up status. You can press any device key to exit the

setup or press exit key to return to the last status or use the UP or DOWN key to select

another set-up.

Remark: You can lock one device for volume and mute control at your new remote control. The locked device is automatically

unlocked if you lock another device.

C．

．．

．Locking a Device

Use the device lock function to fix the current device code. The device code cannot be

subsequently changed via brand name and code or automatic search. You can set it to OFF to

Autres manuels pour VRC801D2

Table des matières

Autres manuels Velleman Télécommande

Velleman

Velleman VM130V2SET Instructions d'installation

Velleman

Velleman VM152 Manuel utilisateur

Velleman

Velleman HIGH-Q Manuel utilisateur

Velleman

Velleman MK160 Manuel utilisateur

Velleman

Velleman CAMB29 Manuel utilisateur

Velleman

Velleman CTC1000RC Manuel utilisateur

Velleman

Velleman VM109 Manuel utilisateur

Velleman

Velleman VRC1001 Manuel utilisateur

Velleman

Velleman VM118R Manuel utilisateur

Velleman

Velleman VMBIRTS Manuel utilisateur

Velleman

Velleman VRC801D2 Manuel utilisateur

Velleman

Velleman VM109 Manuel utilisateur

Velleman

Velleman HAMGSM133 Manuel utilisateur

Velleman

Velleman WRS3B Manuel utilisateur

Velleman

Velleman VRC1601D Manuel utilisateur

Velleman

Velleman VM130V2SET Manuel utilisateur

Velleman

Velleman CAMCOLVC8N1 Manuel utilisateur

Velleman

Velleman High-Q Velleman-kit K8023 Manuel utilisateur

Velleman

Velleman VM130T Manuel utilisateur

Velleman

Velleman HAMGSM133 Manuel utilisateur

Velleman

Velleman HQ POWER LEDA03RC Manuel utilisateur

Velleman

Velleman IREXT Manuel utilisateur

Velleman

Velleman High-Q-kit K8051 Manuel utilisateur

Velleman

Velleman VM130 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
