VBOX XTi- 4144 Manuel utilisateur

VBox Android TV Gateway XTi-

4144/4174 - Installation Instructions

Thank you for purchasing the VBox Android

TV Gateway XTi-4144/4174

The revolutionary TV router and PVR

Your VBox TV Gateway connects to an aerial antenna and streams the different Free-To-Air TV and

Radio channels available in your area to all your connected devices across your network

The VBox also records TV and Radio, programs and series, directly to an attached USB storage or

network folder and NAS (SMB/CIFS) for sharing between your devices.

To receive software and news updates we recommend to follow us on Facebook, Twitter and

registering your product in the following link - Product Registration

Installation Guide

Package Contents

Your package includes the following items:

The VBox XTi Android TV Gateway

Bluetooth Voice Remote control

Power adapter

LAN cable

HDMI cable

Additional Required

Equipment for XTi 4134

Wireless broadband Wi-Fi router –802.11n at

5MHz or higher

RF Input

DVB-T/T2/C/ATSC/ISDB-T –Aerial Terrestrial

Antenna, Cable TV, or ISDB-T feed.

Interface device:

oTV set that has HDMI ports

oOr Android® iOS® device, PC / Mac

A Google Account

Connect your Android TV

1. Connect the VBox XTi to your HD Antenna or Aerial

Terrestrial Antenna or Cable TV

2. Connect the network cable from the VBox to your

network router

3. Connect the video cable to the HDMI input

4. To record Live TV programs, connect an external

media recording device- SD Card or USB Hard Drive, or Set

a Network Drive. You can add and set up the media recording

device at any time later.

Setting up

1. Make sure that UPnP is enabled on your network

router (In most routers this feature is enabled by

default)

2. Connect the VBox to your DVB-T/T2 Antenna or DVB-C

Cable TV.

3. If you would like to record, connect a USB Hard Drive

or USB Flash Drive, you can setup recording to a network

storage at a later stage

4. Connect the network cable from the VBox to your

network router

5. Connect the VBox to the power adapter and press the

power button located at on the back panel of the VBox

6. Connect the VBox XTi to the power adapter

Make sure that UPnP is enabled on your network router

(In most routers this feature is enabled by default)

Additional Ways to Set Up

Setting up with your Tablet or Smartphone (Android

and iOS)

1. Run the “VBox Live TV”app.

2. The app will search your network for the VBox device.

3. The app will open the Quick Setup Wizard (Proceed to

Step 1)

Setting up with a PC - Windows

1. From a computer connected to the same router open

Network folder

2. Find the VBox device and press the mouse's right click

button over it to open the WEB page

3. As your device was not configured, the Quick Setup

Wizard page will open (jump to Step 1)

Setting up with a Mac or any other device

1. Find the VBox's IP address, you can see the VBox IP

address from any VBox app or by accessing your router

2. From any WEB browser type the VBox IP address

3. As your device was not configured, the Quick Setup

Wizard page will open (jump to Step 1)

Step 1 - System Configuration

Interface Language - Set the VBox management pages

language

TV Source - Set your TV source DVB-T/T2 for Antenna

reception or DVB-C for Cable TV reception

System Name - Name you TV Gateway

Country - Select your country to automatically set the

appropriate country's settings

Auto Tune - Press the Auto tune to automatically scan

for available channels in your area

Manual Tune - Manually select the frequencies to scan

Step 2 - Scan (Automatic Tune)

The VBox TV Gateway will automatically scan

preselected frequencies available in your country

Scanning - The currently scanned frequency

Available (Green) - Successfully locked frequency that is

available in your area

Cannot Lock (Red) - Unable to lock to that frequency,

this frequency may not be available in your area

In cases when the VBox is unable to lock to any or all

available frequencies in your area, try to adjust or move

your Antenna to a different location

Step 3 - Channel Setup

Select the TV and Radio channels you would like to use,

you can select individual channels, all Free To Air TV

channels, all Pay TV channels, all Radio channels or all

the available channels.

Please note that selecting more than 150 channels may

slow down your player application and program guide

collection

Sort Channels - The channels are automatically sorted

according to your broadcaster’s (LCN) automatic channel

sorting number, where available.

Broadcasters that do not provide LCN data the channels

will be sorted according to their discovery.

Order - You can change the channel order by pressing

the up or down arrows or by pressing on the cycle icon

and selecting the channel location from the drop down

LCN - Channel number is provided automatically by the

broadcaster (LCN) where available, When LCN is not

available the channel will receive channel number higher

than 1000, you can change the channel number to a

more friendly number

Language - There is no need to change this settings,

However you can narrow down the streamed data by

selecting specific language and audio tracks, or enable

Advanced settings to stream Single Program Transport

Stream (SPTS)

Press Next to continue

Step 4 - Recording Setup

You can set recording now or later, recording is available

on a self-powered USB removable Hard Disk Drive or

USB Flash Drive; or to a Network shared Windows folder

or NAS (SMB/CIFS)

USB - Plug your USB device to the VBox USB port located

on the rear panel and wait for few seconds until the

Current status refreshes and the available storage is

displayed, please make sure that your device is

formatted in the supported file system and that it is self-

powered, or connect a self-powered USB hub to the

VBox and connect your device to the hub

Network Wizard - Browse to a Network storage that is

located on the same Domain or Workgroup

Network Manual - Write your network folder path

Press Finish to complete the VBox setup and go to the

Live TV screen

Live TV

Make sure to visit the Apps page for list of supported

applications and devices

You can watch live TV or record program using any of the

below options:

Apple iPad and iPhone - VBox free Live TV app, Kodi, VLC

or any UPnP Player

Android Tablet and phone - VBox free Live TV app, Kodi,

VLC or any UPnP Player

Android Set-Top-Box - VBox Live TV for STB or Kodi

Samsung Smart TV (2013/4 models) - VBox Live TV app

PC - WEB browser (with VLC webplugin) - Firefox,

Internet Explorer, Opera or Kodi

Mac - Safari (with VLC webplugin) or Kodi

Raspberry Pi 2 - OpenELEC (with Kodi 15)

and many more...
