Vauxhall VIVARO Manuel utilisateur

VIVARO

©Copyright by Vauxhall Motors Ltd., England.

Reproduction or translation, in whole or in parts,

is not permitted without prior written consent from

Vauxhall Motors Ltd.

All rights as understood under the copyright laws are explicitly

reserved by Vauxhall Motors Ltd.

All information, illustrations and specifications contained in this

manual are based on the latest production information

available at the time of publication.

The right is reserved to make changes at any time without

notice.

Edition: January 2007.

TS 1545-B-07

VIVARO

Operation, Safety and Maintenance

Owner’s Manual

Ofrecido por www.electromanuales.com

VAUXHALL Vivaro

Operation, Safety, Maintenance

Ofrecido por www.electromanuales.com

-2

Data specific to your vehicle

Please enter your vehicle’s data here to keep it easily accessible.

This information is available under the section "Technical data" as well as on the identification plate.

Fuel

Designation

Engine oil

Grade

Viscosity

Tyre inflation pressure

Tyre size with up to 4 persons with full load

Summer tyres Front Rear Front Rear

Winter tyres Front Rear front Rear

Weights

Permissible Gross Vehicle Weight

– ECkerbweight

=Loading

Ofrecido por www.electromanuales.com

-1

Your Vivaro

Your vehicle represents an intelligent

synthesis of advanced technology,

outstanding safety, environmental

compatibility and economy.

It now lies with you to drive your vehicle

safely and to see it performs perfectly. This

Owner's Manual provides you with all the

necessary information to that end.

Make sure your passengers are aware of

the possible risk of accident and injury

which may result from improper use of the

vehicle.

You must always comply with the laws of

the country in which you are travelling.

These could differ from the information in

this Owner’s Manual.

The Owner's Manual should always be kept

in the vehicle: ready to hand in the glove

compartment.

Make use of the Owner's Manual:

zIts "In Brief" section will give you an initial

overview.

zThe table of contents at the start of the

Owner’s Manual and in each individual

chapter will help you find your way.

zIts index will help you find what you

want.

zIt will familiarise you with the

sophisticated technology.

zIt will increase your pleasure in your

vehicle.

zIt will help you to handle your vehicle

expertly.

The Owner’s Manual is designed to be

clearly laid-out and easily understood.

This symbol signifies:

6Continue reading on next page.

3The asterisk signifies equipment not

fitted to all vehicles (model variants,

engine options, models specific to one

country, optional equipment, Genuine

Vauxhall Parts and Accessories).

Yellow arrows in the illustrations serve as

points of reference or indicate some action

to be performed.

Black arrows in the illustrations indicate a

reaction or a second action to be

performed.

Thank you for choosing a Vauxhall. We

wish you many hours of pleasurable

driving.

Your Vauxhall Team

9Warning

9Warning is used to mark text

regarding possible risks of accident or

injury. Failure to follow the instructions

could lead to injury or loss of life. Inform

vehicle passengers accordingly.

Ofrecido por www.electromanuales.com

Contents In brief ......................................................... 2

Instruments .............................................. 20

Keys, doors, bonnet ................................ 37

Seats, interior........................................... 47

Safety systems......................................... 56

Lighting.................................................... 75

Windows.................................................. 79

Heating, ventilation ................................ 81

Tecshift.................................................... 89

Driving hints............................................. 95

Save fuel, protect the environment ....... 97

Fuel consumption, fuel, refuelling.......... 99

Catalytic converter,

exhaust emissions ............................ 102

Drive control systems ........................... 106

Dropside body....................................... 109

Brakes..................................................... 113

Wheels, tyres.......................................... 117

Roof rack, caravan and trailer towing 122

Self-help ................................................ 125

If you have a problem .......................... 142

Service plan, maintenance ................... 144

Vehicle care ........................................... 157

Technical data ..................................... 161

Index....................................................... 174

Commitment to customer

satisfaction:

Our aim: to keep you happy with your

vehicle. All Vauxhall Authorised Repairers

offer first class service at competitive

prices. Experienced, factory-trained

technicians work according to factory

instructions. Your Authorised Repairer can

supply you with GENUINE VAUXHALL-

APPROVED PARTS, which have undergone

stringent quality and precision checks, and

of course useful and attractive

VAUXHALL-APPROVED ACCESSORIES.

Our name is your guarantee!

For details of the

Vauxhall Authorised Repairer Network

please ring this number; 0845 090 2044

Ofrecido por www.electromanuales.com

In brief2

In brief

Key numbers, Code numbers

Remove key number from key.

The key number is given in the vehicle

papers and in the Car Pass 3.

Immobilizer, radio 3: the code numbers are

given in the Car Pass and Radio Pass

respectively.

Do not keep the Car Pass and Radio Pass in

the vehicle.

6Further information - see pages 37, 38.

Unlocking the vehicle:

Direct remote control unit 3

towards vehicle,

press button c,

pull door handle

The doors are unlocked.

To unlock mechanically: insert key and turn

in driver’s door lock and pull door handle.

To lock doors from inside, press central

locking button 3located on the lower

dashboard.

6Door locks - see page 37,

electronic immobilizer - see page 38,

remote control - see page 39,

central locking system - see page 41,

anti-theft locking system - see page 43,

Vauxhall alarm system - see page 43.

Seat adjustment 3:

Pull handle, slide seat,

release handle,

allow seat to audibly latch into

position

Never adjust the driver’s seat whilst driving.

It could move in an uncontrolled manner

when the handle has been pulled.

9Warning

Important: Do not sit nearer than 10

inches (25cm) from the steering wheel, to

permit safe airbag deployment.

Ofrecido por www.electromanuales.com

In brief 3

Adjusting the seat back:

Pull release lever

Move seat back to suit seating position, it

will lock in position when the lever is

released.

Adjusting the lumbar support 3:

Turn handwheel

Adjust lumbar support to suit personal

requirements.

Do not lean on seat backrest whilst

adjusting it.

Adjusting arm rest support 3:

Adjust arm rest support to suit personal

requirements.

zRaise armrest in increments to desired

height.

zTo reposition, fully raise armrest before

lowering.

Ofrecido por www.electromanuales.com

In brief4

Adjusting seat height 3:

Pull lever at side

Lift lever and remove weight from seat to

raise it or press down on seat with body

weight to lower it.

Never adjust the driver’s seat whilst driving.

It could move in an uncontrolled manner

when the lever has been pulled.

6Seat position – see page 47.

Adjusting head restraint height:

hold firmly and adjust height,

then release

6Head restraint position – see page 47,

further information, removal – see page 48.

6Further information - see page 47.

9Warning

Disregard of these instructions may lead

to injuries or endanger life. Vehicle

passengers should be informed

accordingly.

Ofrecido por www.electromanuales.com

In brief 5

Steering wheel adjustment:

Adjust position

Adjust the steering wheel only when the

vehicle is stationary.

Move the unlocking lever upwards, adjust

the wheel to the desired position, then

release the lever.

Push the lever firmly downwards to ensure

that the wheel is locked in position.

6Airbag systems - see page 61.

Fitting seat belt:

Draw seat belt smoothly from

inertia reel, guide over shoulder

and engage in buckle

The belt must not be twisted at any point.

The lap belt must lie snugly against the

body. The backrest must not be tilted back

too far (recommended tilting angle

approx. 25°).

To release belt, press red button on belt

buckle.

6Seat belts – see pages 57 to 59,

airbag systems 3– see page 61,

seat position – see page 47.

Ofrecido por www.electromanuales.com

In brief6

Adjust interior 3 and exterior

mirrors:

Swivel to appropriate position

Move lever on underside of interior mirror

housing to reduce dazzle at night.

6Further information - see page 74.

Electrically adjustable exterior

mirrors 3:

Switch in door panel

Operational with the ignition on or off.

Turn switch to left: switch operates left-

hand mirror.

Turn switch to right: switch operates right-

hand mirror.

Switch in central position: mirror

adjustment is off.

The lower aspherical mirrors are not

adjustable.

Ofrecido por www.electromanuales.com
