Vaporesso GTX ONE Manuel utilisateur

User Manual

VAPORESSO GTX ONE

1English

Drip Tip

Top Cap

Coil Holder

Air-inlet Ring

MOD

Type-C USB Port

“+” Button

“-” Button

0.69’’ OLED Screen

Power Button

Glass Tube

Thank you for choosing Vaporesso product. Please read this instruction carefully before use to

ensure a perfect experience.

If there is any additional requirement about this product, please consult the local agent or

ENGLISH

EXPLODED VIEW SPECIFICATION

GTX ONE MOD

Dimensions 83.6 x 29.3 x 22.7mm

Resistance Range 0.15-5Ω

Output Power 5-40W

Output Voltage 0-4V

Charging Current DC 5V/2A, Type-C

Display 0.69" OLED Screen

Battery Capacity Built-in 2000mAh

Tank Connection 510 Thread

2English

PACKING LIST

Regular Version:

1 x GTX ONE MOD

1 x GTX TANK 18 (3ml)

1 x GTX 0.8Ω MESH Coil (Pre-installed)

1 x GTX 1.2Ω MESH Coil (In Box)

4 x O-ring

1 x Glass Tube (2ml)

1 x Type-C USB Cable

1 x User Manual

1 x Warranty Card

TPD Version:

1 x GTX ONE MOD

1 x GTX TANK 18 (2ml)

1 x GTX 0.8Ω MESH Coil (Pre-installed)

1 x GTX 1.2Ω MESH Coil (In Box)

4 x O-ring

1 x Glass Tube (2ml)

1 x Type-C USB Cable

1 x User Manual

1 x Warranty Card

GTX TANK 18

Dimensions Φ18 x 48.6mm

Capacity 3ml / 2ml

Coils GTX 0.8Ω MESH Coil (12-20W)

GTX 1.2Ω MESH Coil (7-11W)

3English

USE INSTRUCTIONS

1. Install the Tank

Install the tank to the battery by screwing the 510 thread. Make sure they are rmly connected.

2. Replace the Coil

- Unscrew the thread base from the tank;

- Pull out the used coil in the tank;

- Install a new coil to the tank;

- Reattach the thread base into place.

OPEN

OPEN CLOSE

2 3 4 5 6

4English

3. Fill the E-liquid

- Unscrew the top cap from the tank;

- Fill the e-liquid along the glass tube;

- Reattach the top cap back into place;

- Please wait 5 minutes for the e-liquid

to soak into the coil completely.

4. Adjust the Airow

To adjust the airow volume, please rotate the air-inlet ring on the bottom of the tank.

5. System Operating

(1) Power on/off: press the power button 5 times in 2s.

OPEN CLOSE

1 2 3

5English

(2) Lock/unlock the Buons: press the power button 3 times continuously to lock or unlock the “+” button

and “-” button.

(3) Start Vaping: press and hold the power button to start vaping. For your safety, please do not vape for

more than 10 seconds at a time.

(4) Adjust the Power: press the “+” button or “-” button to adjust the power.

(5) Flip the Screen: press the power button and “+” button simultaneously to ip the screen 180°.

(6) System Seing: press the “+” button and “-” button simultaneously to enter the system setting interface,

which includes VV, VW, SMART VW, and DEFAULT.

VV: select “VV”and press the power button to enter VV mode.

6English

VW: select “VW” and press the power button to enter VW mode.

SMART VW: select “SMART VW” and press the power button to enter ON/OFF setting.

DEFAULT: select “DEFAULT”, “YES” and press the power button to restore the factory setting.

PROTECTIONS

(1) Overtime Protection: the device will stop working if you vape for more than 10 seconds at a time, and

“OVER TIME” will show on the screen.

7English

(2) Low Resistance Protection: when an extremely low resistance is detected, the device will stop working

and show “LOW ATOMIZER” on the screen.

(3) High Resistance Protection: when a high resistance is detected, the device will stop working and show

“HIGH ATOMIZER” on the screen.

(4) No-load Protection: when there is no tank detected, the device will stop working and “CHECK

ATOMIZER” will show on the screen.

(5) Short-circuit Protection: when a short-circuit is detected, the device will stop working and “SHORT

ATOMIZER” will show on the screen.

(6) Low Voltage Protection: when the battery voltage is too low to start vaping, the device can not be

operated and “LOW BATTERY” will show on the screen.

8English

1. Please turn off the device when it is not in use.

2. Do not leave the charging device unattended.

3. Do not drop, throw or abuse your device, which may cause damage.

4. Please use a standard USB output charger with proper charging current and voltage range.

5. Keep away from the water or any ammable gas, liquid .

6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.

7. Do not expose the device to extreme temperature. (Recommended temperature range:

-10~60℃/14~140 ℉while using and -10~45℃/14~113 ℉while storing).

8. EEE Recycling: the product should not be treated as household waste, instead, it should

be handed over to the applicable collection point for the recycling of electrical and

CAUTIONS

(7) Over Discharge Protection: when the battery voltage is extremely low during vaping, the device will

stop working and “LOW POWER” will show on the screen.

(8) Over Charge Protection: the device will stop charging when it is fully charged.

(9) USB Input Protection: when the USB detects an input voltage exceeding the rated voltage, the device

will stop charging.
