Vantec NexStar Manuel utilisateur

User’s Manual 2.5”/3.5” SATA to

USB 3.0 & Wi-Fi

External Hard Drive Dock

PACKAGE CONTENTS

Trademarks

Microsoft, Windows NT/2000/XP/Vista/7/8 are trademarks of Microsoft Corporation.

Apple, the Apple logo, iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App Store

is a service mark of Apple Inc.

iTunes is for legal or rightholder-authorized copying only. Don’t steal music.

Google Play is a trademark of Google Inc.

NexStar is a registered trademark of Vantec Thermal Technologies.

NexStar WiFi Hard Drive Dock

Power Adapter

USB 3.0 Cable

User’s Manual

2.5”/3.5” SATA to USB 3.0 & Wi-Fi Hard Drive Dock

1 2

3 4

TABLE OF CONTENTS

Table of Contents

1. Introduction

2. Features & Specications

3. System Requirements & Media Support

4. Parts Layout

5. Connecting the NexStar

6. NexStar Wireless Operations

6.1 Getting the NexStar Wireless App

6.2 Connecting Using iOS Device

6.3 Connecting Using Android Device

6.4 Connecting Using PC

6.5 Connecting Using Your Mac

7. NexStar Wireless Settings

7.1 Enable Internet Tethering for Your NexStar WiFi

7.2 Enabling SSID Encryption

7.3 Using Apple TV with Your NexStar

7.4 Resetting to Default Settings

8. Warranty

9. Contact

1. INTRODUCTION

The Vantec NexStar® WiFi Hard Drive Dock is a complete

and easy way to access all those les stored away

in your hard drives. Now integrated with Wi-Fi, the

NexStar provides quick access to your data through

your personal Smart Phone or Tablet PC. Whether it is

an iOS or Android™ device, download the NexStar WiFi

App through the App StoreSM and Google Play Store.

In addition, the NexStar WiFi Hard Drive Dock supports

UPnP for seamless device compatibility so bringing you

contents to your home theater has never been easier.

The NexStar allows simultaneous connection up to 3

devices. Simply insert any 2.5” or 3.5” SATA hard drive into

the NexStar and you are ready to browse your les over

the multiple platforms in your arsenal. The NexStar also

contains USB 3.0 for when you need fast direct access to

your data from your computer making it perfect solution

to access any hard drives in seconds.

Introduction

2. FEATURES & SPECIFICATIONS

2.5”/3.5” SATA to USB 3.0 & Wi-Fi Hard Drive Dock

• External Hard Drive Dock for Smart Devices

• Support Upload and Download From External

Storage Through Wi-Fi

• Support Wi-Fi 802.11 b/g/n Transfer

• Support Wi-Fi Security Protection WEP/WPA/

WPA2

• Multiple Users Simultaneous Connection

• Native iOS & Android App Downloadable Via

iTunes & Google Play

• Support PC/Mac Wireless Access Over SMB

• Support USB 3.0 Transfer Rate Up To 5Gbps

• Support SATA I/II/III 2.5” and 3.5” Hard Drives

• Supports UPnP Media Server

Features Specications

Model:

Hard Drive Size:

Internal Interface:

External Interface:

File System:

Wi-Fi Interface:

Power Supply:

Material:

Dimension:

NST-D306WS3

2.5” & 3.5” Hard Drive

SATA I/II/III

USB 3.0 (Backwards compatible with

USB 2.0 & 1.1)

NTFS, FAT32

802.11 b/g/n

Wi-Fi AP Tethering Supported

Wi-Fi Encryption: WEP/WPA/WPA2

Support WPS

150 Mbit Transfer Rate

AC Adapter

Plastic

136 x 83 x 87

Features & Specications

3. SYSTEM REQUIREMENTS & MEDIA SUPPORT

Microsoft Windows XP / Vista / 7 / 8

1. For USB 3.0 speeds, the system must support USB

3.0 specications.

2. For USB 2.0 speeds, the system must support USB

2.0 specications.

Mac OS X 10.6 & higher

1. For USB 3.0 speeds, the system must support USB

3.0 specications.

2. For USB 2.0 speeds, the system must support USB

2.0 specications.

Apple iPhone/iPad/iPod Touch iOS 4.0 & higher

1. Open-In function requires previously installed

Apps to support le.

2. Airplay support requires devices to be under the

NexStar wi- network.

Supported Media Playback

Video: h.264, .mov, .mp4, .mpv, .3gp, .m4v

Photo: .jpg, .jpeg, .png, .gif, .tif, .bmp, .tiff

Audio: AAC, MP3, M4A, AIF, WAV

Document: MS Ofce 97 or higher, .pdf, .rtf

Android Phone Ver. 2.1 & higher

Android Pad Ver. 3.0 & higher

Supported Media Playback

Video: h.264, .mov, .mp4, .mpv, .3gp, .m4v

Photo: .jpg, .png, .gif, .tif, .bmp, .webp

Audio: AAC, MP3, M4A, AIF, WAV

System Requirements & Media Support

4. PARTS LAYOUT

2.5”/3.5” SATA to USB 3.0 & Wi-Fi Hard Drive Dock

Wi-Fi

Activity

HDD

Activity

HDD Eject Button

Power

Port

USB 3.0 Port

Reset

Button

Parts Layout

5. CONNECTING THE NEXSTAR

Using USB to Connect to Your Computer

1. Connect the power adapter to the NexStar.

2. Connect the USB 3.0 cable to the NexStar and attach

the other end to your computer.

Connecting the NexStar

Conecte el adaptador de alimentación al NexStar.

Branchez l’adaptateur d’alimentation sur le NexStar.

Schließen Sie das Netzteil an den NexStar an.

Collegare l’adattatore di corrente a NexStar.

電源アダプターをNexStarに接続します。

将电源变压器连接 NexStar。

將電源變壓器連接 NexStar。

Conecte el cable USB 3.0 al NexStar y a su PC.

Branchez le câble USB 3.0 sur le NexStar et branchez l’autre

extrémité sur votre ordinateur.

Verbinden Sie das USB 3.0-Kabel mit dem NexStar, schließen Sie

das andere Ende an Ihren Computer an.

Attaccare il cavo USB 3.0 a NexStar e l’altra estremità al com-

puter.

USB 3.0 ケーブルをNexStarに接続し、もう一方の端をお使いのコンピュ

ーターに取り付けます。

将USB 3.0 缆线连接 NexStar，再将另一端连接您的电脑。

將 USB 3.0 纜線連接 NexStar，再將另一端連接您的電腦。

Conectar el NexStar a su PC mediante USB

Connecter le NexStar à votre ordinateur via USB

NexStar per USB mit Ihrem Computer verbinden

Collegamento di NexStar al computer usando il

collegamento USB

USB を用いて NexStar をコンピューターに接続する

使用USB将NexStar连接电脑

使用USB將NexStar連接電腦

Reset

3. Insert 2.5” or 3.5” SATA hard drive into the slot.

4. When the eject button is upright, press the power

button to turn on the device.

Connecting the NexStar

Inserte la unidad de disco duro SATA de 2,5” o 3,5” en la

ranura.

Insérez un disque dur SATA 2,5” ou 3,5” dans la fente.

Stecken Sie die 2,5- oder 3,5-Zoll-SATA-Festplatte in den

Steckplatz.

Inserire il disco rigido SATA 2,5” o 3,5” nell’alloggio.

2.5 インチまたは 3.5 インチ SATA ハードドライブをスロットに挿入

します。

将2.5”或3.5”SATA硬碟插入插槽。

將2.5”或3.5”SATA 硬碟插入插槽。

Cuando el botón de expulsión esté recto, presione el botón

de alimentación para encender el dispositivo.

Lorsque le bouton Ejecter est en haut, appuyez sur le bouton

d’alimentation pour allumer l’appareil.

Wenn die Auswurftaste aufrecht ist, drücken Sie die Ein-/Aus-

taste zum Einschalten des Gerätes.

Quando il tasto di espulsione è in posizione verticale, pre-

mere il tasto d’alimentazione per accendere il dispositivo.

イジェクトボタンが立っているとき、電源ボタンを押してデバイスの

電源をオンにします。

当退出按钮向上弹起时，按下电源按钮开启装置电源。

當退出按鈕向上彈起時，按下電源按鈕開啟裝置電源。
