Vantec DSH-410C3 Manuel utilisateur
User Manual
DSH-410C3
USB-C MST Docking Station
with PD 60W
Table of Contents
SAFETY INSTRUCTIONS
COPYRIGHT, TRADEMARKS
REGULATORY COMPLIANCE
FCC CONDITIONS
CE, WEEE INFORMATION
INTRODUCTION
FEATURES
PACKAGE CONTENTS
SYSTEM REQUIREMENTS
PRODUCT OVERVIEW
CONNECTION
DISPLAY CONFIGURATION
MULTI-MONITOR CONFIGURATION
EXTEND MODE
MIRROR MODE
SET THE PRIMARY MONITOR
SST MODE, MST MODE
AUDIO CONFIGURATION
SPECIFICATION
TECHNICAL SUPPORT
1
1
2
2
2
3
4
5
5
6
8
9
9
10
11
12
12
13
14
15
Always read the safety instructions carefully:
◆Keep this User’s Manual for future reference
◆Keep this equipment away from humidity
◆If any of the following situation arises, get the
equipment checked by a service technician:
- The equipment has been exposed to moisture.
- The equipment has been dropped and damaged.
- The equipment has obvious sign of breakage.
- The equipment has not been working well or
cannot get it to work according to the User’s Manual.
This document contains proprietary information
protected by copyright. All right are reserved. No part
of this manual may be reproduced by any mechanical,
electronic or other means, in any form, without prior
written permission of the manufacturer.
All trademarks and registered trademarks are the
property of their respective owners or companies.
Safety Instructions
Copyright
Trademarks
1
Before attempting to connect, operate or adjust this
product, please save and read the User’s Manual
completely. The style of the product shown in this
User’s Manual may be dierent from the actual unit
due to various models.
Table of Contents
2
For EU (European Union) member users: According to
the WEEE (Waste electrical and electronic equipment)
Directive, do not dispose of this product as household
waste or commercial waste. Waste electrical and
electronic equipment should be appropriately collected
and recycled as required by practices established
for your country. For information on recycling of this
product, please contact your local authorities, your
household waste disposal service or the shop where
you purchased the product.
WEEE Information
This equipment is in compliance with the requirements of
the following regulations: EN 55 022: CLASS B
CE
This equipment has been tested and found to comply
with Part 15 Class B of the FCC Rules. The operation is
subject to the following two conditions: (1) This device
may not cause harmful interference. (2) This device
must accept any interference received and include
interference that may cause undesired operation.
FCC Conditions
Regulatory Compliance
3
Introduction
The Vantec USB-C MST Docking Station with PD 60W
is designed for extra connectivity demands. With
the USB-C dock, you can extend the connection
of a computer to more USB peripherals, Ethernet
network, the speaker and the microphone via USB-C
interface. It is easy to connect using the reversible
USB-C plug.
Adopting PD Charging technology, upstream
charging function through USB-C interface, you can
charge the connected laptop. With the built-in USB
3.0 ports, the dock enables you to enjoy the super
speed data transmission between USB peripherals.
With the DP or HDMI ports, you can mirror your
primary screen, or extend the content. When
the system supports MST mode, you can display
identical or dierent content on the external
monitors as you wish. Enhanced expansion
capability plus the stylish appearance, this dock
with video is the most versatile accessory that also
complements your home or oce space.
●Incorporates HDMI® technology.
4
◆USB-C Input
- USB Type-C female connector
- Upstream PD powered, supports up to 60W
- Supports VESA USB Type-C DisplayPort Alt mode
◆Downstream Output
- USB 3.0 Type-A female x3
(One port supports BC 1.2 & CDP)
- USB 3.0 Type-C female x1
◆Video output
- Single display, either one video output
• DP output: Supports resolution up to
3840x2160@30Hz
• HDMI output: Supports resolution up to
3840x2160@30Hz
- Dual display
• Supports resolution up to 1920x1200@60Hz
◆Supports audio 2.1 channel
◆Supports Gigabit Ethernet
Features
5
◆USB-C MST PD Dock
◆USB-C Cable
◆Power Adapter
◆User’s Manual
◆PC with USB-C interface supporting VESA
USB Type-C DisplayPort Alt Mode
◆Supported Operating System
- Windows® 10
x1
x1
x1
x1
Package Contents
System Requirements
Front
Product Overview
6
Item Description
1. USB 3.0 Port Connect to USB 3.0 devices
With BC 1.2 charging
2. USB-C Port Connect to USB-C devices
3. Combo Audio Jack Connect to a headset
4. Power Button Switch to power on/o
1
2 4
3
7
Product Overview
Rear
Item Description
5. Power jack Connect to the power adapter
6. USB-C Port Connect to the USB-C port of a
computer
7. DP connector Connect to a DP monitor
8. HDMI connector Connect to a HDMI monitor
9. RJ45 port Connect to an Ethernet
10. USB 3.0 Port (x2) Connect to USB 3.0 devices
6
579
8 10
8
To connect the USB peripherals, Ethernet, speaker, and
microphone, follow the illustrations below to connect
the corresponding connectors.
Connection
