Note: This kit must be installed or serviced by a quali ed installer, service agency or the gas
supplier. These instructions are to be used in conjunction with the main installation instructions for
the above listed models.
WARNING: If the information in these instructions is not followed exactly, a re or explosion
may result causing property damage, personal injury or loss of life.
GROUNDING: This power supply must be installed and grounded in accordance with local codes,
or in the absence of local codes, with the current Canadian Electrical Code CSA C.1. or in the
USA the National Electrical Code ANSI/NFPA0 latest edition.
DESCRIPTION OF SYSTEM
The models listed above have been designed to accommodate the installation of an air circulation
fan. Operated by a variable speed control and a thermally actuated switch, the fan is designed to
boost the natural convection through the heater; this may be a desirable feature dependent on the
replace location and room layout. The circulating fan may be installed before the heater installation
or as a retro t at a later date.
OPERATION
The fan is designed for automatic operation using a thermal switch. It will take approximately 10-15
minutes for the appliance to warm up and allow the switch to activate the fan. To operate the fan,
rotate the speed control knob clockwise from OFF to HIGH. Further rotation will control the fan speed,
once the automatic thermal switch has been activated. If the re is turned off, the fan will continue
to operate until the thermal switch cools, unless the speed control is manually turned to the OFF
position.
Should electrical power fail, the heater operation will remain unaffected.
ELECTRICAL REQUIREMENTS
The fan kit requires a power supply of 120 Volts, 1 phase, 60 Hz. Full load current is less than 1
amp.
4000510-04
555CFK CIRCULATING FAN KIT
INSTALLATION and OPERATING INSTRUCTIONS
CSA approved for use only with:
Valor models 530 I, RetroFire RF24 and Madrona MF28
Variable Speed
Control Box
Spade
Terminals
Fan with bracket mounted
Spade
Terminals
Sheet Metal Screws (2)
Thread Cutting Screw (1)
Adhesive Cable Retainer
Thermal Switch
and Lead
6’-0”
Grounded
Plug
Fan Kit Components
FAN KIT COMPONENTS
The complete #555CFK kit contains the following:
Fan & motor unit assembled to fan mounting bracket c/w wiring harness, speed control junction
box, thermal sensor switch and 6’ cord set.
Control box mounting screw and cable retainer.
Unit mounting screws ().
•
•
•
3
PREPARATION
New replace installations
If installing the fan kit in a new application, follow the installation guidelines in the following pages in
conjunction with the installation manual supplied with the replace engine.
Existing replace installations
If installing the fan kit in an existing replace, start with the following steps, refering to the installation
manual supplied with the replace engine.
In a cold replace, remove the trims and front (preceded by the top if 530 free standing stove), the
window, the logs/coals/stones and bricks.
Shut-off the gas supply to the replace and disconnect the gas line from the unit’s valve.
Remove the burner module.
If installing in an insert, insure that the metal base of the replace enclosure is supported. If
the metal base can ex up and down, it may be a source of vibration noise when the fan unit is
installed. Now is the time to correct this.
Install the fan according to the guidelines of the next pages.
TESTING THE FAN UNIT AFTER INSTALLATION
Although the fan and controls are factory tested to ensure proper operation, a check should be
performed after the fan installation, prior to nishing the assembly of the replace.
Before energizing the control box, manually bypass the thermal switch with a jumper either at the
switch or at the spade terminals (be careful not to short out if using a non-insulated jumper). Plug-in
the power cord to energize the control box. Rotate the control knob and check that the fan operates
correctly at all speeds. Once veried, disconnect the power, remove the jumper, and reconnect the
thermal switch wires to the control box terminals.
1.
.
3.
4.
5.
4
INSTALLATION—VALOR MODEL 530 I
At the bottom right hand side of the rebox,
raise the sheet metal tab if not already raised.
Fasten the motor control to the tab with one
screw.
Feed the power cord out through the opening
in the rear left corner of the heater. Tuck wires
in the back corner so they will be behind the
fan unit when installed.
1.
.
3.
Fit the fan unit by placing it into the rear of the
liner box (with the wires running behind) and
secure to the rear wall using the two screws
provided.
Secure the thermally actuated switch to the
side of the rebox using screws.
Use the U shaped self-adhesive cable retainer
to hold the thermal switch wiring to the bottom
of the appliance and away from the fan inlet.
4.
5.
6.
Raise this tab
Fasten blower control to
engine tab using one screw
Run Power Cord
out left hand rear
corner
Route wires in
back corner
behind fan
Thermoswitch
Wire
Fasten Fan to back
of Heater using 2 screws
Thermoswitch
Wire
Clip Thermoswitch wire
to sheet metal bottom
using clip provided
5
Test the fan operation as indicated on page 3
of this manual.
Finish the assembly of the replace as
indicated in the installation manuals provided
with the replace’s engine, front and trim.
.
8.
Control Valve
(GV60) Fan ControlRemote
Receiver
INSTALLATION—VALOR MODEL 530 I
INSTALLATION—RETROFIRE MODEL RF24
Remove the fan mounting bracket and
reinstall in reverse position to the fan
assembly. (The mounting bracket is originally
supplied set up for heater model 530
application).
With the burner module removed, install the
fan unit into the rear convection channel on
heater.
1.
.
Unscrew 3 screws and
remove fan mounting
plate
Flip bracket over and reinstall
using screws through
3 lower holes
Tabs facing forward
Slip Fan Bracket into
Rear Convection Channel
and line up Mounting Holes
Fan Bracket installed
into Convection Channel
6
Fan and Bracket installed
with 2 mounting screws
Line up the screw holes and secure the fan
assembly using screws.
Fasten the fan control box to lower right
hand support leg. (The control box may
alternatively be ipped over and secured to
the left hand support leg if desired.)
3.
4.
Fasten the thermal switch to underside of
burner module using screws.
Test the fan operation as indicated on page 3
of this manual.
Finish the assembly of the replace as
indicated in the installation manuals provided
with the replace’s engine, front and trim.
5.
6.
.
Fasten Fan Control Box
to lower RH Support Leg
using 1 screw
Fasten Thermal Switch to
underside of burner module
using 2 existing screws
INSTALLATION—RETROFIRE MODEL RF24
Remove the mounting plate from the fan and
discard it.
Position the fan in such way that its exhaust is
directed upwards, towards the space between
the inner and the outer walls of the rebox.
Using 3 screws, x the fan to the rebox
bracket.
Fix the fan
control box
bracket
provided to the
control box with
screws.
Fix the bracket
with the control
box attached
to the base of
the stove from
underneath.
1.
.
3.
4.
5.
Fasten Thermal Switch to
underside of burner module
using 2 existing screws
Fan control
box position
Fan control
box bracket
Unscrew 3 screws and
remove fan mounting
plate
Fix the thermoswitch to the underside of the
burner plate, behind the pilot area, with
screws taken from the burner plate.
Test the fan operation as indicated on page 3
of this manual.
Finish the assembly of the replace as
indicated in the installation manuals provided
with the replace’s engine, front and trim.
6.
.
8.
INSTALLATION—MADRONA MODEL MF28
8
MAINTENANCE
This fan does not require any regular maintenance or lubrication; however, periodic cleaning of the
unit compartment to remove household lint will help to maintain peak performance and extend the fan
life.
This space can be accessed by opening the lower door or removing the front. Using a crevice tool on
the end of a vacuum cleaner hose, carefully clean the bottom area of the replace linerbox, paying
particular attention to the area under the burner box base.
Should the fan require additional servicing, it must be done by a qualied gas appliance service
person.
Over time, it may be useful to clean the fan blades themselves for dust accumulation. To do this, it is
necessary to remove the burner assembly. This must be done by a qualied gas appliance service
person.
WIRING DIAGRAM
Warning- Electrical Grounding Instructions
This appliance is equipped with a three-prong (grounded) plug for your protection against shock
hazard and must only be plugged directly into a properly grounded three-prong receptacle. Do not
cut or remove the grounded prong from this plug. Alternatively, it may be hard wired by a qualied
electrical installer.
MODEL 555CFK - OPTIONAL BLOWER KIT
MILES INDUSTRIES LTD.
BLOWER
THERMO
SENSOR
POWER CORD
OFF-ON SWITCH
SPEED CONTROL
Electrical Schematic
555CFK
9
PLEASE LEAVE INSTALLATION AND OPERATING INSTRUCTIONS
WITH THE HOMEOWNER.
LIMITED WARRANTY POLICY
Miles Industries Ltd. warrants all components of the model 555CFK Circulating Fan Kit for a period of
one year from the date of purchase against defects in materials or workmanship. This warranty covers
only the cost of defective parts and applies only to the original consumer purchaser. The replacement of
defective parts by Miles Industries Ltd. will be without charge during the warranty period. This warranty
does not extend to (1) components damaged by accident, neglect, misuse, abuse, alteration, and
negligence of others, including the installation thereof by unqualied installers () the costs of removal,
reinstallation or transportation of defective parts or (3) incidental or consequential damages.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING THE WARRANTY OF MERCHANTABILITY OF FITNESS FOR PURPOSE
AND OF ALL OTHER OBLIGATIONS OR LIABILITIES. MILES INDUSTRIES LTD. DOES NOT
ASSUME, NOR HAS IT AUTHORIZED ANY PERSON INCLUDING ITS SALES REPRESENTATIVES
TO ASSUME FOR IT, ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THE SALE
OR USE OF THE MODEL 555CFK CIRCULATING FAN KIT.
A qualied installer, in accordance with the instructions supplied must install the model 555CFK
Circulating Fan Kit. The defective components should be returned at your expense to the dealer from
where the product was purchased or authorized service agent. The sales invoice evidencing proof
of purchase and date of purchase must accompany any components returned for warranty repair/
replacement. Miles Industries Ltd. reserves the right to repair and return any defective component.
Manufactured and distributed in Canada and USA by
Miles Industries Ltd.
190–55 Dollarton Hwy.,North Vancouver, BC, Canada VH 3B1
Tel. 604-984-3496 Fax 604-984-046
www.valorreplaces.com
© 006, Miles Industries Ltd. All rights reserved.
10
Note : Ce kit doit être installé et entretenu par un installateur quali é, une agence de service
certi ée ou un fournisseur de gaz. Ces instructions doivent être utilisées conjointement avec les
instructions d’installation des modèles mentionnés ci-haut.
MISE EN GARDE : Si les instructions fournies dans le présent guide ne sont pas suivies à la
lettre, un feu ou une explosion pourraient résulter et causer des dommages matériels, des
blessures ou la mort.
MISE À LA TERRE : La prise de courant utilisée pour brancher cet appareil doit être installée et
mise à la terre conformément aux codes locaux et, en l’absence de codes locaux, elle doit être
conforme à la version courante du Code canadien de l’électricité CSA C.1 ou, aux États-Unis, à la
version courante du National Electrical Code ANSI/NFPA 0.
DESCRIPTION DU SYSTÈME
Les modèles de foyers 530 de Valor, RetroFire et Madrona de Miles Fireplaces ont été conçus pour
permettre l’installation facultative d’un ventilateur de circulation d’air. Avec son contrôleur de vitesse
variables et son interrupteur thermique, ce ventilateur est conçu pour augmenter la convection na-
turelle du foyer; cette option peut être désirable selon l’emplacement du foyer. Le ventilateur peut être
installé au moment de l’installation du foyer ou à une date ultérieure.
FONCTIONNEMENT
Ce ventilateur est conçu pour fonctionner automatiquement avec un interrupteur thermique. Il faudra
approximativement 10 à 15 minutes pour réchauffer l’appareil et permettre à l’interrupteur d’actionner
le ventilateur. Pour faire fonctionner le ventilateur, tournez le bouton de la boîte de contrôle dans le
sens horaire de OFF à HIGH. Lorsque l’interrupteur thermique est actionné, continuez à tourner le
bouton pour contrôler la vitesse. Si le foyer est éteint, le ventilateur continuera de fonctionner jusqu’à
ce que l’interrupteur thermique refroidisse. Le ventilateur peut être aussi éteint en tournant le bouton
de contrôle à la position OFF.
En cas de panne d’électricité, le fonctionnement du foyer ne sera pas affecté.
EXIGENCES ÉLECTRIQUES
Le ventilateur doit être branché dans une prise de courant de 120 Volts, 1 phase, 60 Hz. L’intensité
de la charge pleine est de moins de 1 ampère.
VENTILATEUR POUR CIRCULATION D’AIR 555CFK
GUIDE D’INSTALLATION ET D’OPÉRATION
Homologué par la CSA pour usage exclusif avec les modèles
530 de Valor, RetroFire RF24 et Madrona MF28 de Miles Fireplaces
Autres manuels pour 555CFK
1
Table des matières
Langues :
Autres manuels Valor Accessoires de cheminée
Valor
Valor 720SWK-M Manuel utilisateur
Valor
Valor HeatShift LDK Series Manuel utilisateur
Valor
Valor 757 Manuel utilisateur
Valor
Valor G3 Series Manuel utilisateur
Valor
Valor H6 Series Manuel utilisateur
Valor
Valor 1135TSBE Three Sided Trim with Edgemont... Manuel utilisateur
Valor
Valor 751LTK Manuel utilisateur
Valor
Valor L2 1700K Manuel utilisateur
Valor
Valor LEGEND G3 Series Manuel utilisateur
Valor
Valor PORTRAIT BSK539-549-550 Manuel utilisateur
Valor
Valor LX2 Series Manuel utilisateur
Valor
Valor LEGEND G3 Series Manuel utilisateur
Valor
Valor MADRONA Series Manuel utilisateur
Valor
Valor H3 Series Manuel utilisateur
Valor
Valor LT2 2700K Manuel utilisateur
Valor
Valor LINEAR SERIES Manuel utilisateur
Valor
Valor 614CVI Manuel utilisateur
Valor
Valor 725RTB Black Manuel utilisateur
Valor
Valor L1 Series Manuel utilisateur
Valor
Valor ZERO CLEARANCE KIT Manuel utilisateur
Manuels Accessoires de cheminée populaires d'autres marques
Town & Country Fireplaces
Town & Country Fireplaces 22150051 Manuel utilisateur
Travis Industries
Travis Industries 33 DVI Manuel utilisateur
Superior
Superior ASD3628-TI Manuel utilisateur
pleasant hearth
pleasant hearth OFP28WG Manuel utilisateur
IHP
IHP Astria Series Manuel utilisateur
Firegear
Firegear FG-H-2110SS Manuel utilisateur
Nibe
Nibe Contura C i31 Manuel utilisateur
kozy heat
kozy heat KZK-052 Manuel utilisateur
SimpliFire
SimpliFire SF-WM36 Manuel utilisateur
Bluegrass Living
Bluegrass Living BC18NR Guide de démarrage rapide
pleasant hearth
pleasant hearth IRIS SCROLL Manuel utilisateur
Cooke
Cooke Glass Wind Guard Manuel utilisateur
