Vaisala MOG100 Manuel utilisateur
M211951EN-B
User Guide
Vaisala Multi-Observation Gateway
MOG100
PUBLISHED BY
Vaisala Oyj
Street address: Vanha Nurmijärventie 21, FI-01670 Vantaa, Finland
Mailing address: P.O. Box 26, FI-00421 Helsinki, Finland
Phone: +358 9 8949 1
Visit our Internet pages at www.vaisala.com.
© Vaisala Oyj 2018
No part of this manual may be
reproduced, published or publicly
displayed in any form or by any
means, electronic or mechanical
(including photocopying), nor
may its contents be modified,
translated, adapted, sold or
disclosed to a third party without
prior written permission of the
copyright holder. Translated
manuals and translated portions
of multilingual documents are
based on the original English
versions. In ambiguous cases, the
English versions are applicable,
not the translations.
The contents of this manual are
subject to change without prior
notice.
Local rules and regulations may
vary and they shall take
precedence over the information
contained in this manual. Vaisala
makes no representations on this
manual’s compliance with the
local rules and regulations
applicable at any given time, and
hereby disclaims any and all
responsibilities related thereto.
This manual does not create any
legally binding obligations for
Vaisala towards customers or end
users. All legally binding
obligations and agreements are
included exclusively in the
applicable supply contract or the
General Conditions of Sale and
General Conditions of Service of
Vaisala.
This product contains software
developed by Vaisala or third
parties. Use of the software is
governed by license terms and
conditions included in the
applicable supply contract or, in
the absence of separate license
terms and conditions, by the
General License Conditions of
Vaisala Group.
This product may contain open
source software (OSS)
components. In the event this
product contains OSS
components, then such OSS is
governed by the terms and
conditions of the applicable OSS
licenses, and you are bound by
the terms and conditions of such
licenses in connection with your
use and distribution of the OSS in
this product. Applicable OSS
licenses are included in the
product itself or provided to you
on any other applicable media,
depending on each individual
product and the product items
delivered to you.
Table of Contents
1. About This Document................................................................................... 3
1.1 Version Information.......................................................................................... 3
1.2 Related Manuals................................................................................................ 3
1.3 Documentation Conventions...........................................................................3
1.4 Trademarks........................................................................................................ 4
2. Product Overview........................................................................................... 5
2.1 Vaisala Multi-Observation Gateway MOG100................................................5
2.2 Safety................................................................................................................. 6
2.2.1 ESD Protection........................................................................................... 7
2.3 Regulatory Compliances.................................................................................. 7
2.3.1 Applicable European Directives...............................................................7
2.3.2 FCC Compliance.........................................................................................8
2.3.3 Ocial Modem Identification...................................................................8
3. Overview to Configuration and Installation.........................................9
4. Configuration.................................................................................................. 10
4.1 Installing SIM Card.......................................................................................... 10
4.2 Installing AQ Tool..............................................................................................11
4.3 Establishing Maintenance Connection..........................................................12
4.4 Configuring Wireless Communication.......................................................... 12
4.5 Registering MOG100 in Beacon View............................................................13
5. Installation........................................................................................................14
5.1 Installing MOG100........................................................................................... 14
5.1.1 Installing Mounting Bracket on 60 ... 100 mm Mast............................. 15
5.1.2 Installing Mounting Bracket on Sensor Support Arm or
35 ... 40 mm Mast..................................................................................... 15
5.1.3 Installing Mounting Bracket on Wall...................................................... 17
5.1.4 Installing MOG100 on Mounting Bracket...............................................17
5.2 Installing AQT400/WXT530......................................................................... 20
5.3 Connecting Cables and Powering................................................................ 20
5.4 Verifying Installation...................................................................................... 22
6. Troubleshooting............................................................................................ 23
6.1 Writing Problem Report................................................................................ 23
7. MOG100 Specifications..............................................................................24
Warranty....................................................................................................................... 27
Technical Support..................................................................................................... 27
Recycling...................................................................................................................... 27
Table of Contents
1
MOG100 User Guide M211951EN-B
2
1. About This Document
1.1 Version Information
This document provides information about the installation and operation of Vaisala Multi-
Observation Gateway MOG100.
Table 1 Document Versions
Document
Code
Date Description
M211951EN-B February 2018 • MOG100 registration instructions updated.
• New 3.5G modem in MOG100.
• Change of UI application names:
• AQ-View changed to Beacon View.
• AQT Configuration Tool changed to AQ Tool.
M211951EN-A February 2017 First version.
1.2 Related Manuals
Table 2 Related Manuals
Document Code Name
M211942EN Vaisala Air Quality Transmitter AQT400 Series User Guide
M212056EN Vaisala Multi-Observation Gateway MOG100 Configuration Guide
M212019EN Vaisala Observation Network Manager NM10 Configuration and Maintenance
Manual
M211840EN Vaisala Weather Transmitter WXT530 Series User Guide
The documentation is available online at www.vaisala.com.
1.3 Documentation Conventions
Warning alerts you to a serious hazard. If you do not read and
follow instructions carefully at this point, there is a risk of injury or even death.
WARNING!
Chapter 1 – About This Document
3
Caution warns you of a potential hazard. If you do not read and
follow instructions carefully at this point, the product could be damaged or
important data could be lost.
CAUTION!
Note highlights important information on using the product.
Tip gives information for using the product more eciently.
Lists tools needed to perform the task.
Indicates that you need to take some notes during the task.
1.4 Trademarks
Vaisalaâis a registered trademark of Vaisala Oyj.
Microsoftâand Windowsâare either registered trademarks or trademarks of Microsoft
Corporation in the United States and other countries.
All other product or company names that may be mentioned in this publication are trade
names, trademarks, or registered trademarks of their respective owners.
MOG100 User Guide M211951EN-B
4
2. Product Overview
2.1 Vaisala Multi-Observation Gateway MOG100
Vaisala Multi-Observation Gateway MOG100 is a gateway and logger device for Vaisala Air
Quality Transmitter AQT400 Series and Vaisala Weather Transmitter WXT530 Series. MOG100
includes the following components:
• GSM module for wireless communication
• Battery regulator for solar panel and battery input
• Memory for data logging and local buering
MOG100 sends the measuring data from the air quality or weather transmitters to Vaisala
Beacon View cloud service, Vaisala Observation Network Manager NM10, and third-party
servers, using the integrated 3.5G (4‑band GSM) cellular modem. MOG100 communicates
using the secure HTTP over TCP/IP protocol (HTTPS).
MOG100 is enclosed in an IP66‑rated weatherproof aluminum casing and can be installed
outdoors. The unit has dedicated connectors for AQT400, WXT530, and for power and
maintenance.
Table 3 MOG100 Options and Accessories
Option Details Order Code
MOG100 unit -
4G/3G/2G GSM antenna - 250327
Mounting kit - ASM211983
Sensor cable, M12/8(F)‑open for power/maintenance 5 m (16 ft 5 in) 223283
Chapter 2 – Product Overview
5
Option Details Order Code
Sensor cable, M12/8(F)‑M12/8(F) for AQT400/WXT536 0.8 m (2 ft 7 in) 248086
1.8 m (5 ft 10 in) 248090
Optional Accessories
Mounting kit for 60 mm (2.36 in) pole mast - APPKP60-SET1/2
Sensor cable, M12/8(F)-M12/8(F) for WXT536 5 m (16 ft 5 in) 248091
2.2 Safety
This product has been tested for safety. Note the following precautions:
Do not substitute parts or modify the system, or install
unsuitable parts in the system.
WARNING!
Do not perform installation or maintenance procedures when
there is a risk of thunderstorm or lightning activity in the area.
WARNING!
Follow the risk assessments you have carried out for the
installation work. To ensure safety, make sure that all work is organized and
planned, and carried out by competent persons.
WARNING!
Follow local and state legislation and regulations on occupational
safety.
WARNING!
Failure to comply with these precautions or with specific
warnings elsewhere in these instructions violates safety standards of design,
manufacture, and intended use of the product. Vaisala assumes no liability for
the customer's failure to comply with these requirements.
WARNING!
If the equipment is used in a manner not specified by Vaisala, the
protection provided by the equipment may be impaired.
WARNING!
MOG100 User Guide M211951EN-B
6
2.2.1 ESD Protection
Electrostatic Discharge (ESD) can damage electronic circuits. Vaisala products are adequately
protected against ESD for their intended use. However, it is possible to damage the product by
delivering electrostatic discharges when touching, removing, or inserting any objects in the
equipment housing.
To avoid delivering high static voltages to the product:
• Handle ESD-sensitive components on a properly grounded and protected ESD workbench
or by grounding yourself to the equipment chassis with a wrist strap and a resistive
connection cord.
• If you are unable to take either precaution, touch a conductive part of the equipment
chassis with your other hand before touching ESD-sensitive components.
• Hold component boards by the edges and avoid touching component contacts.
2.3 Regulatory Compliances
This product complies with the following performance and environmental test standards:
• EN/IEC 61326-1
• EN 55032 Class B
2.3.1 Applicable European Directives
MOG100 is in conformity with the following EC directives:
• RoHS Directive 2011/65/EU
• REACH Directive 2006/121/EU
• EMC Directive 2014/30/EU
• RE Directive 2014/53/EU(*)
* When applicable, the product conforms to the corresponding RED articles:
RF spectrum eciently, Article 3 (2); EMC, Article 3 (1b); Safety, Article 3 (1a)
This product complies with the following test standards:
• IEC/EN 61326-1
• EN 55032 Class B / CISPR 32
Compliance with the following test standards is derived from Telit HE910 cellular module's
declaration of conformity:
• EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
• EN 62311:2008
• EN 301 489-1 V2.1.1, Draft EN 301 489-52 V1.1.0
• Final draft EN 301 489-3 V2.1.1
• EN 300 440 V2.1.1 / EN 301 511 V12.5.1
Chapter 2 – Product Overview
7
• EN 301 908-1 V11.1.1 / EN 301 908-2 V11.1.1
To comply with RE directive one must use only the antenna provided with the product
package.
2.3.2 FCC Compliance
This product contains a transmitter module FCC ID RI7HE910.
MOG100 complies with FCC Chapter 47 Part 15, 22H, 24E and 27. Operating is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
2.3.3 Ocial Modem Identification
This product contains part identified as follows by national authorities:
• FCC ID: RI7HE910
• IC ID: 5131A-HE910
• GITEKI (MIC) ID: 005-100269
• JATE ID: AD12-0318001
MOG100 User Guide M211951EN-B
8
Table des matières
Manuels Porte populaires d'autres marques
LST
LST M500RFE-AS Manuel utilisateur
Kinnex
Kinnex Media Gateway Manuel utilisateur
2N Telekomunikace
2N Telekomunikace 2N StarGate Manuel utilisateur
Mitsubishi Heavy Industries
Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur
ZyXEL Communications
ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur
Telsey
Telsey CPVA 500 - SIP Manuel utilisateur
