Parent’s Guide

INTRODUCTION

Thank you for purchasing the Kidi Star Dance™ system!

Learn 20 cool dance moves step by step by following the animated

dance trainer. Then, challenge a friend to a dance-off using the bands.

On/Off

Button

Games

Button On/Off

Button

Volume

Button

Home

Button

Music

Button

Left

Button

OK Button

Right

Button

LED

Indicator

microSD

Card Slot

Audio-In

Jack DC Jack

INCLUDED IN THIS PACKAGE

• One Kidi Star Dance™unit

• Two bands (with CR2025 battery pre-installed)

• One audio cable

• One parent’s guide

WARNING:

All packing materials such as tape, plastic sheets, packaging locks,

removable tags, cable ties and packaging screws are not part of this toy,

and should be discarded for your child’s safety.

NOTE: Please keep this parent’s guide as it contains important

information.

ATTENTION :

Pour la sécurité de votre enfant, débarrassez-vous de tous les produits

d’emballage tels que rubans adhésifs, feuilles de plastique, attaches,

étiquettes et vis d’emballage. Ils ne font pas partie du jouet.

NOTE : Il est conseillé de conserver ce guide des parents car il comporte

des informations importantes.

Turn the packaging lock

counterclockwise several times.

Pull out and discard the packaging lock.

Unlock the packaging locks:

GETTING STARTED

BATTERY INSTALLATION

The Kidi Star Dance™ system uses 4

AA batteries or a VTech®6V adapter (sold

separately).

• Make sure the main unit is turned OFF.

• Locate the battery cover on the bottom of

the main unit.

• Use a screwdriver to open the battery

cover.

• Install 4 new AA batteries as illustrated.

(The use of new alkaline batteries

is recommended for maximum

performance).

• Replace the battery cover.

BATTERY NOTICE

• Use new alkaline batteries for maximum performance.

• Use only batteries of the same or equivalent type as recommended.

• Do not mix different types of batteries: alkaline, standard (carbon-zinc)

or rechargeable, or new and used batteries.

• Do not use damaged batteries.

• Insert batteries with the correct polarity.

• Do not short-circuit the battery terminals.

• Remove exhausted batteries from the toy.

• Remove batteries during long periods of non-use.

• Donotdisposeofbatteriesinre.

• Do not charge non-rechargeable batteries.

• Remove rechargeable batteries from the toy before charging (if

removable).

• Rechargeable batteries are only to be charged under adult supervision.

POWER ADAPTER CONNECTION

You may purchase a VTech®3.5mm DC 6V power adapter by visiting

our website at vtechkids.com. Hover over the “Support” option on the

top menu bar and choose “Order Replacement Parts” from the menu

that appears below. Or call our Consumer Services Department at

1-800-521-2010 in the US or 1-877-352-8697 in Canada.

To connect the adapter to the unit, follow the instructions below:

• Make sure the unit is OFF and ensure no batteries remain inside the

unit.

• Locate the 3.5mm DC Jack on the side of the unit.

• Connect a power adapter (not included) into the DC Jack.

• Insert the other end of the power adapter into a wall outlet.

• Turn the unit ON.

TRANSFORMER SAFETY NOTICE

• Using a 3.5mm/1.3mm (positive center) 6V/800mA DC output AC

adaptor is recommended.

• This toy shall only be used with a transformer for toys.

• The transformer is not a toy.

• This toy is not intended for use by children under 3 years old.

• Do not connect the toy to more than the recommended number of

power supplies.

• Never clean a plugged-in toy with liquid.

• Please regularly examine the transformer, checking for damage to the

cord, plug, transformer and other parts. Do not use the transformer if

it is damaged.

MEMORY CARD INSTALLATION

The Kidi Star Dance™ system is compatible with microSD/microSDHC

memory cards up to 32GB.

• Make sure the main unit is in OFF.

• Pull away the rubber covering on the

microSD Card Slot, located on the

side of the unit.

• Insert the memory card (not included)

as illustrated.

• To remove the memory card from the

slot, push the card and it will eject.

Note: To prevent accidental data loss, make sure you have backed up

all important data from your memory card before using it.

WARNING:

The bands with this product contain a button or coin cell

battery. A swallowed button or coin cell battery can cause

internal chemical burns in as little as two hours and lead to

death. Dispose of used batteries immediately. Keep new

and used batteries away from children. If you think batteries

might have been swallowed or placed inside any part of the

body, seek immediate medical attention.

ATTENTION !

Ce jouet contient une pile bouton !L’ingestion d’une pile

bouton peut causer des brûlures internes pouvant provoquer

la mort dans un délai de 2 heures. Jeter les piles usées

immédiatement après les avoir retirées du jouet. Garder les

piles neuves hors d’atteinte des enfants. Si vous remarquez

qu’une pile bouton a été avalée, consultez immédiatement

un médecin.

BAND USAGE

Power On

Press the On/Off Button on the side of the face to turn on the Band.

If you’ve just taken the Bandsoutofthepackagingforthersttime,you

need to remove the battery strip before use.

Power Off

Press and hold the On/Off Button for two seconds.

Auto Power Off

The Bands will automatically power off if unused for a short period of

time.

LED Indicator

The BandLEDwillashperiodicallytoshowitisworking

normally. If the LED ashes twice in succession, the

battery is low and you should replace it soon.

BAND BATTERY INSTALLATION

1. Locate the battery cover on the back of a

Band face and open it with a screwdriver.

2. Remove the battery cover and insert a

CR2025 battery as illustrated.

3. Replace the battery cover and fasten the

screw.

4. Repeat steps 1-3 on the second Band.

BAND BATTERY NOTICE

• Use one CR2025 Lithium coin battery only for each Band. Do not use

rechargeable Lithium ion battery LIR2450. This toy is not compatible

with LIR2450.

• The coin battery used with this product should be kept away from

small children who might still put things in their mouths. If the coin

battery is swallowed, consult a doctor immediately.

• Insert the coin battery with the correct polarity.

• Do not use a damaged coin battery.

• Do not short-circuit the coin battery terminals.

• Remove exhausted coin battery from the product.

• Remove coin battery during long periods of non-use.

• Donotdisposeofcoinbatteryinre.

• Do not charge a non-rechargeable coin battery.

• Rechargeable batteries are to be removed from the toy before being

charged. (if removable)

• Rechargeable batteries are only to be charged under adult supervision.

TO BEGIN USING KIDISTAR DANCE

Power On

Press the On/Off Button to turn on the main unit. If you’ve just taken

the Kidi Star Dance™ system out of its packaging for the rst time,

you need to disable Try-Me mode before playing. Press the OK Button

during the Try-Me movie to exit Try-Me mode.

Band Pairing

After exiting the Try-Me mode, you will be asked to pair

the Bandsbeforeplayingforthersttime.Turnonyour

Bands and press the OK Button to start the pairing

procedure. Shake the Band that you want it to be paired

as BandA rst, and then shake the other Band to be

Band B.

If the main unit cannot recognize the Bands during pairing, power off the

Bands, turn them on and shake again.

NOTE: If for any reason you want to pair only one Band, after Band A is

paired, you can press the OK Button to skip Band B pairing.

Auto Power Off

To preserve battery life, the Kidi Star Dance™ system will automatically

shut down if there is no operation for a short period of time.

Volume Control

Press the Volume Button and press the Left or Right

Buttons to adjust the volume.

NOTE: Audio-in volume is not controlled by the Kidi Star Dance™

system, please use the connected music device to control the audio-in

volume.

ACTIVITIES

Home Menu

1. Dancing Academy

Select a dance move from the menu and follow along

with the dancer to learn it. The icon in the lower-left

showsthemove’sdifculty.

2. Dancing Challenge

Use the moves you learn in Dancing Academy to

dance along to eight original songs. Challenge a

friend and see who knows the moves best!

3. Free Dance

Select a music style and dance along with the music

as the lights follow your moves.

4. Freeze Dance

Select a song to play and follow the funny dance

prompts, just don’t move when the music stops!

5. System Setup

Band Pairing

• Pair the Bands with the main unit

Band A/B SFX

• Set the default sound effect response for Band A/B

Music Playtime

• Set the maximum playtime for music playback. The main unit will

turn off automatically after the time is reached.

Factory Reset

• Reset your Kidi Star Dance™ system to factory settings

Music Menu

1. MP3 Player

PlayMP3lesfromyourmemorycard(notincluded)

or songs from Dancing Challenge when no memory

card is present.

Press the Left or Right Buttons to select a function

icon and press the OK Buttontoconrm.

Play or pause the music

Play previous or next song

Option Menu

• Play All: Play all songs in order

• Repeat All: Loop all songs continuously

• Repeat One: Play the current song on loop

• ShufeAll:Shufeallsongs

• Play Folder: Play all the songs stored in a single folder (not including

sub-folders). Press the Left and Right Buttons to navigate through

folders and press the OK Buttontoselectaleorfolder.Pressthe

Music Button to return to the play screen.

NOTE:

The maximum playtime is 2 hours by default and can be adjusted in

the System Setup Menu.

After the music is playing for 20 seconds, animations

will start playing with light effects. Press the Left or

Right Buttons to choose between 10 different light

effects or turn off the effects. Press the OK Button to

return to the music player.

2. Audio-In Connection

Plug in your own music player to the Audio-In Jack on

the side and watch the lights dance along.

NOTE: Sound from a device using the Audio-In Jack

will play through the Kidi Star Dance™ speakers in any

activity. The audio-in volume is controlled by the volume setting on your

external device.

Game Menu

1. Beat Jam

Shake your Band when the falling icon crosses the line

to play along with the music. Band A controls the left

instrument, and Band B controls the right. Wear them

both or give one to a friend to play together!

2. Music Bubble

Shake your Bands to keep the music aoat. Band

A guides the music bubble to one way, and Band B

pushes it the other way. Try to avoid obstacles as the

levels get harder.

3. Funny Conductor

Take a turn conducting the orchestra by waving your

Band to the beat. Try to wave your hand when the

baton symbol enters the target. Go too slow and the

music will stop, too fast and it will just sound silly.

4. Magic Moves

Select an object and shake your Bands to make some

funny sounds!

5. Motion Challenge

Select a challenge and play with your friend or the

computer. Follow the instructions and perform the

action as quickly as possible within the time limit, and

see who is the winner!

DANCING CHALLENGE SONG LYRICS

The Funky Bear

Verse 1:

Let’s do the funky bear

Join me, do you dare?

Let’s do the funky bear right now,

C’mon I’ll show you how!

Chorus:

Roar, roar like a bear,

Shoutitoutwithsomeair!

Stomp, stomp like a bear,

Try n’ give me a scare!

Swim, swim like a bear,

Let’scatchsomeshtoshare!

Roar, roar like a bear,

Let’s do the funky bear!

Verse 2:

Do you feel it in the air?

It’s the beat of the funky bear

Come on let’s give it a shot,

And show me what you got!

(Chorus)

Our Favorite Song

Verse 1:

I hear the music playing

The beat is loud, I feel amazing

All I wanna do is get up

With my friends now, let’s stand up!

Chorus:

Put your hands up and wave them along,

To our favorite song

Nod your head to the beat,

Let’s dance to our favorite song

Sway side to side, and clap your hands,

To our favorite song

Jump up and down to the beat,

Let’s dance to our favorite song

Verse 2:

Iseethelightsashing

Allovertheoor,it’ssoexciting

All I wanna do is get up

With my friends now, let’s stand up!

(Chorus)

Autres manuels pour KidiStar Dance

Table des matières

Autres manuels V-tech Jouet

V-tech

V-tech Mr. Squawky Talkie Manuel utilisateur

V-tech

V-tech KidiPet Friends Manuel utilisateur

V-tech

V-tech TREE FU TOM Learn & Go Manuel utilisateur

V-tech

V-tech Peppa Pig 518003 Manuel utilisateur

V-tech

V-tech Switch&Go DINOS Manuel utilisateur

V-tech

V-tech GearZooz Instructions de montage

V-tech

V-tech Winnie the Pooh - Play & Learn Laptop Manuel utilisateur

V-tech

V-tech LIGHT & FLIGHT DISCOVERY GLOBE Instructions de montage

V-tech

V-tech MY FIRST KidiSmartwatch Manuel utilisateur

V-tech

V-tech V.Smile Baby: WTP Pooh s Hundred Acre Wood... Manuel utilisateur

V-tech

V-tech Disney Go!Go! SmartWheels Minnie Mouse Around... Instructions de montage

V-tech

V-tech Lil Baker Smart Kitchen Manuel utilisateur

V-tech

V-tech GearBuddies Lion & Mouse Instructions de montage

V-tech

V-tech Wiggle & Jiggle Fishing Fun Instructions de montage

V-tech

V-tech Disney TALK & TRACE CLIPBOARD Manuel utilisateur

V-tech

V-tech Sing & Soar Butterfly Manuel utilisateur

V-tech

V-tech Go! Go! Cory Carson Fire Rescue Freddie Manuel utilisateur

V-tech

V-tech Winnie the Pooh Pop-Up Honey Pot Manuel utilisateur

V-tech

V-tech Drive Time Buggy Manuel utilisateur

V-tech

V-tech Play & Chase Puppy Instructions de montage

V-tech

V-tech 80-078850 - V.Motion Active Learning System Manuel utilisateur

V-tech

V-tech V.Smile: SpiderMan & Friends II Doc Ock s... Manuel utilisateur

V-tech

V-tech Go! Go! Smart Wheels Press & Race SmartPoint... Instructions de montage

V-tech

V-tech Toot-Toot Cory Carson Cory's Stay & Play... Instructions de montage

Manuels Jouet populaires d'autres marques

marklin

marklin 37321 Manuel utilisateur

Canon

Canon PAPER CRAFT Manuel utilisateur

GREAT PLANES

GREAT PLANES Pitts M-12S Manuel utilisateur

NOCH

NOCH 14261 Manuel utilisateur

Hausler

Hausler 450 SE V2 Manuel utilisateur

Dynaflite

Dynaflite Daydream Manuel utilisateur

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuel

Kenner

Kenner Batman 63651 Manuel utilisateur

LEGO

LEGO 8527 Manuel utilisateur

iKarus

iKarus ECO 8 Manuel utilisateur

Multiplex

Multiplex EasyStar II Mode d’emploi

Walkera

Walkera 38 Mode d’emploi

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuel utilisateur

MD MXION SWD Manuel utilisateur

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuel utilisateur

marklin

marklin 39671 Manuel utilisateur

Meccano

Meccano 15103 Manuel utilisateur

LEGO

LEGO TECHNIC 8735 Manuel utilisateur
