V-tech i94x Manuel utilisateur
Electronic Emission Notices
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC ules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with instructions contained in this manual, may cause harmful interference
to radio and television communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- EO IENT O ELOCATE THE ECEIVING ANTENNA
- INC EASE THE SEPA ATION BETWEEN THE EQUIPMENT AND THE ECEIVE
- CONNECT THE EQUIPMENT INTO AN OUTLET ON A CI CUIT DIFFE ENT F OM
THAT OF THE ECEIVE
- CONSULT THE DEALE O AN EXPE IENCED AUDIO/TELEVISION TECHNICIAN
NOTE: Connecting this device to peripheral devices that do not comply with Class B
requirements, or using an unshielded peripheral data cable, could also result in
harmful interference to radio or television reception.
The user is cautioned that any changes or modifications not expressly approved
by the party responsible for compliance could void the users authority to operate
this equipment.
To ensure that the use of this product does not contribute to interference, it is
necessary to use shielded I/O cables.
Copyright
This manual is copyrighted with all rights reserved. No portion of this manual may be
copied or reproduced by any means.
While every precaution has been taken in the preparation of this manual, no responsibility
for errors or omissions is assumed. Neither is any liability assumed for damages resulting
from the use of the information contained herein.
Trademarks
All brand names, logos and registered trademarks mentioned are property of their
respective owners.
Technical eference Booklet
TABLE OF CONTENTS
HARDWARE CONFIGURATION .................................................................... 4
Key Features .................................................................................................. 4
MOTHERBOARD LAYOUT ............................................................................ 7
REAR PANEL ................................................................................................ 9
AUDIO CONFIGURATION .............................................................................. 12
SPEAKER CONFIGURATION ........................................................................ 12
Method 1: Using the 4/6 surround audio output of the
back panel only ...................................................................................... 12
Method 2: Using S-Bracket connectors ................................................. 14
CONNECTORS ............................................................................................. 16
Floppy Disk Drive Connector - CN3 ...................................................... 16
Hard Disk Connectors - CN1 ................................................................ 16
S-Bracket (SPDIF) /CEN/LFE/Surround Output Connector -
J19 for AC97 only (optional) ............................................................................... 17
SPDIF Header - J29 for HD Audio (optional)........................................ 18
Fan Power Connectors - CPUFAN/SYSFAN (optional) ........................ 19
CD-IN Connector - J30 (optional) .......................................................... 20
Power LED - D64, D65 (optional)..................................................................20
Serial ATA Hard Disk Connectors -
SATA-1/SATA-2/SATA-3/SATA-4 (optional) ............................................... 21
Front Panel Audio Header - FP-S1 ........................................................ 23
IEEE 1394 Connector:CN9/CN10 (optional)...............................................24
USB Connectors - FP-U1/FP-U2 (optional) .......................................... 25
Front Panel Header - FP1 ...................................................................... 26
JUMPER SETTING ....................................................................................... 27
CMOS Clear - JP1 .................................................................................. 27
SLOTS ......................................................................................................... 2
CPU INSTALLATION .................................................................................... 29
INSTALL DDRII DIMMS ............................................................................... 32
!
CrossFire Setup .......................................................................................... 33
Installing Driver ...................................................................................... 33
BIOS SETUP ................................................................................................ 35
About the Setup Utility ............................................................................ 35
The Standard Configuration .................................................................. 35
Entering the Setup Utility........................................................................ 35
Main Menu .............................................................................................. 36
Standard CMOS Features ................................................................ 37
Advanced BIOS Features.................................................................. 38
Advanced Chipset Features ............................................................. 38
Integrated Peripherals ...................................................................... 38
Power Management Setup ............................................................... 38
PNP/PCI Configurations ................................................................... 38
PC Health Status .............................................................................. 38
Frequency/Voltage Control ............................................................... 38
Set Supervisor/User Password ........................................................ 39
Save & Exit Setup .............................................................................. 39
Exit Without Saving ........................................................................... 39
Flash Update Procedure .................................................................. 40
REALTEK HD AUDIO DRIVER SETUP ........................................................... 41
Getting Started..................................................................................................4 1
Sound Effect ........................................................................................... 41
Environment Simulation ........................................................................ 41
Equalizer Selection ................................................................................ 42
Frequently Used Equalizer Setting ........................................................ 42
Karaoke Mode ........................................................................................ 42
Mixer ....................................................................................................... 43
Playback control ............................................................................... 43
ecording control ............................................................................. 44
Audio I/O ........................................................................................... 45
Speaker Configuration ..................................................................... 46
Global Connector Settings............................................................... 47
S/PDIF .............................................................................................. 48
Speaker Calibration ......................................................................... 48
Microphone....................................................................................... 49
Noise Suppression.......................................................................... 49
Beam Forming ................................................................................. 49
Acoustic Echo Cancellation ............................................................. 49
Audio Demo ..................................................................................... 50
Information ....................................................................................... 50
APPENDIX .................................................................................................... 51
......
"
Technical eference Booklet
HARDWARE CONFIGURATION
Key Features :
Chipset
Intel® 945P/945PL Chipset.
Processor
Supports Intel® Celeron® , Pentium® 4, Pentium® D, CoreTM 2 Duo
processors in the LGA775 -pin package (with 0. V~1.6V voltage).
Supports 64-bit PSB (Processor System Bus) frequency of 533MHz/
800MHz (133MHz/200MHz bus clock).
Supports Hyper-Threading Technology.
Supports 64bit PSB frequency of 1066MHz (266MHz bus clock) (only for
945P).
VRD 11.0 (Voltage Regulator Modules) Onboard
Flexible motherboard design with onboard V D11.0, easy to upgrade
with future Intel® Celeron, Pentium® 4, Pentium® D, CoreTM 2 Duo
processors.
0.03125V to 1.600V in 6.25mV steps for V M11.0.
System Memory
A total of two 240 pin DD II SD AM sockets.
Dual-channel (128 bits wide) DD II memory interface.
Supports 128Mb, 256Mb, 512Mb,1G technologies implemented
as X8, X16 devices.
Supports DD II533.
Supports DD II667 (only for 945P).
Support for Non-ECC memory only.
Maximum memory size: 4GB.
Onboard I/O
_One onboard PCI fast IDE port supporting up to 2 ATA, ATA2 , Ultra
ATA33/66/100 IDE HDDs, CD- OMs, ZIP drives and LS-120 drives
as boot drive.
_One ECP/EPP parallel port.
_One floppy port which supports two FDD of 1.44MB, 2.88MB capacity.
_Six/eight USB ports.
_PS/2 keyboard support.
_PS/2 mouse support.
_One Front Panel Sound Connector.
_Infrared (IrDA) support via a header.
Two 16550 Compatible UA T serial port.
#
Plug-and-Play
Supports Plug and Play specification 1.1.
Plug and Play for Windows®2000 as well as Windows®XP.
Fully steerable PCI interrupts.
Onboard Realtek RT 100C/RT 110S LAN (optional)
Integrated 10/100/1000 (only T8110S LAN) transceiver.
Supports Full Duplex flow control (IEEE802.3x)
Fully compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab.
Transmit/ eceive FIFO (8K/64K) support.
PCI Express Graphics interface (optional)
_One 16-lane (X16 port) PCI Express graphics port, fully compliant
with the PCI Express Base Specification revision 1.0a.
_A base PCI Express frequency of 2.5GB/s only.
_PCI Express support and Enhanced Addressing Mechanism.
Onboard AC97 Sound (optional)
Integrated AC97 controller with standard AC97 Codec.
Direct Sound and Sound Blaster compatible.
Full-Duplex 16-bit record and play back.
PnP and APM 1.2 support.
Windows® 2000/XP ready.
Line-in, Line-out, Mic-in.
Supports AC97 codes for six sound channel output.
Onboard IEEE1 94 (optional)
Compliant with 1394 OHCI specifications v1.0 and v1.1.
Integrated 400Mbit 2 port PHY.
System BIOS
PnP, APM, ATAPI for Windows® 2000/XP.
Full support of ACPI & DMI.
Auto detects and supports LBA harddisks with capacities over 160GB.
Easy to upgrade BIOS by end-user.
Onboard HD Audio Sound (optional)
Integrated ealtek HD Audio controller.
Full Direct Sound and Sound Blaster compatible.
Full-Duplex 4 24-bit two-channel DACs and 3 stereo 20-bit ADCs.
PnP and APM 1.2 support.
Windows® 2000/XP ready.
Line-in, Line-out, Mic-in, SPDIF-in, SPDIF-out.
Supports HD Audio codec for eight channel sound output.
$
Technical eference Booklet
Static electricity can harm delicate components of the motherboard.
To prevent damage caused by static electricity, discharge the static
electricity from your body before you touch any of the computers
electronic components.
Expanded USB Support
Includes 4 UHCI host controllers, increasing the number of external
ports to eight.
Includes 1 EHCI USB2.0 Host Controller that supports all six/eight ports
(Bandwidth shared between the eight ports).
Power Management
Supports SMM, APM and ACPI.
Break switch for instant suspend/resume on system operations.
Energy star Green PC compliant.
Hardware monitoring circuit provides voltage, temperature, fan speed,
etc. monitoring (optional).
Supports suspend-to- AM (ST ) (optional).
External Modem ing-in Wake-up support.
Integrated Serial ATA host Controller
Independent DMA operation on four ports (optional).
Data transfer rates of 300Mb/s.
AID feature support (optional).
Expansion Slots
1 PCI Express X16 slot.
_1 PCI Express X4 slots (Support PCI Express VGA card).
_3 PCI bus slots - ver. 2.1 compliant (optional).
%
NOTE :
1) Be sure to check the HDD cable orientation in order to match the colored strip to the pin 1 end
of the connector.
2) When you start up the system, please wait for 5 seconds after you power on AC.
3) Adding a metal spaced plate to the back of the Socket 775 is not recommended as this will short
motherboard components and damage the system.
MOTHERBOARD LAYOUT (for HD Audio only)
The following diagram shows the relative positions of the jumpers, connectors,
major components and memory banks on the motherboard.
PKE;;9$Wsgoix
J
S
\
G
S
R
R
V
I
Q
S
Z
I
&
Technical eference Booklet
NOTE :
1) Be sure to check the HDD cable orientation in order to match the colored strip to the pin 1 end
of the connector.
2) When you start up the system, please wait for 5 seconds after you power on AC.
3) Adding a metal spaced plate to the back of the Socket 775 is not recommended as this will short
motherboard components and damage the system.
MOTHERBOARD LAYOUT (for AC97 Sound only)
The following diagram shows the relative positions of the jumpers, connectors,
major components and memory banks on the motherboard.
PKE;;9$Wsgoix
J
S
\
G
S
R
R
V
I
Q
S
Z
I
'
REAR PANEL
The back panel (for HD Audio) provides the following connectors:
The back panel (for AC97 Audio) provides the following connectors:
Technical eference Booklet
PIN SIGNAL DESC IPTION
1 VCC +5V/5VSB (optional)
2 -Data 0 Negative Data Channel 0
3 +Data0 Positive Data Channel 0
4 GND Ground
5 VCC +5V/5VSB (optional)
6 -Data 1 Negative Data Channel 1
7 +Data 1 Positive Data Channel 1
8 GND Ground
Mouse Connector
The motherboard provides a standard PS/2® mouse mini DIN connector for
attaching a PS/2® mouse. You can plug a PS/2® mouse directly into this
connector.
Keyboard Connector
The motherboard provides a standard PS/2® keyboard mini DIN connector for
attaching a PS/2® keyboard. You can plug a PS/2® keyboard directly into this
connector.
USB 2.0 Connector
The motherboard provides a UHCI (Universal Host Controller Interface)
Universal Serial Bus root for attaching USB devices such as keyboard, mouse
or other USB-compatible devices. You can plug the USB device directly into the
connector.
USB 2.0 Connector DescriptionUSB 2.0 Connector
Table des matières
Autres manuels V-tech Carte mère
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
