Urmet domus Miro Mode d’emploi

DS 1139-004 LBT 20347

Mod.

1139

CITOFONO VIVAVOCE IP

IP HAND-FREE DOOR PHONE

INTERPHONE MAINS-LIBRES IP

INTERFONO MANOS LIBRES IP

SPRECHANLAGE MIT FREISPRECHSYSTEM IP

IP HANDSFREE DEURTELEFOON

Sch./Ref.1139/3

LIBRETTO UTENTE

USER HANDBOOK

NOTICE UTILISATEUR

MANUAL DEL USUARIO

BENUTZERHANDBUCH

GEBRUIKSHANDLEIDING

DS1139-004

ENGLISH

INDEX

1. DESCRIPTION OF COMPONENTS............................................................................................................ 7

1.1. INDICATOR LEDS ............................................................................................................................. 8

1.2. BUTTON FUNCTIONS ...................................................................................................................... 8

2. FEATURES ................................................................................................................................................. 8

2.1. CALL RECEPTION ............................................................................................................................ 8

2.2. ANSWERING THE CALL ................................................................................................................... 9

2.3. DOOR OPENER DURING CALL........................................................................................................ 9

2.4. FLOOR CALL..................................................................................................................................... 9

2.5. CALLING THE SWITCHBOARD ........................................................................................................ 9

2.6. INTERCOM CALL ............................................................................................................................. 9

2.7. CALL TONE SELECTION .................................................................................................................. 9

2.8. ADJUSTING THE CALL VOLUME................................................................................................... 10

2.9. PANIC ALARM ................................................................................................................................ 10

2.10. AUTOMATIC DOOR OPENER......................................................................................................... 10

3. USER DATA RESET.................................................................................................................................. 11

4. REBOOTING THE DEVICE ....................................................................................................................... 11

The Ref. 1139/3 is an IP device dedicated exclusively to the IPerVoice system.

1. DESCRIPTION OF COMPONENTS

1. Microphone

2. Button see button function table

3. Button see button function table

4. Button to connect to Yokis devices

5. Button to connect to Yokis devices

6. Multicolour indicator LED

7. Call and conversation speaker

8. Button to switch on audio or end the current conversation

9. Green LED under the button

10. Door opener button

11. Green LED under the button

8DS1139-004

1.1. INDICATOR LEDS

The functions of the components listed in the paragraph above are shown in detail below.

6. Multicolour indicator LED

FUNCTIONS

Slowly blinking yellow: programming state on

Fast green blinking: conﬁrm pressing of the buttons or

Slow red blinking: ringer mute

Slow green blinking: automatic door opener active

9. Green LED under the button

On steady: call in progress

On blinking: conversation ongoing

11. Green LED under the button

on blinking (max. 3 seconds): door opener conﬁrmation after pressing button

1.2. BUTTON FUNCTIONS

State

Button

STAND-BY

WAITING

FOR

PICK-UP

(RECEIVING

CALL)

DURING

AUDIO

OPERATION

IN STAND-BY

AND ONLY

AFTER PRESSING

BUTTON

STATE OF

PROGRAMMING(1)

(ONLY WITH DOOR PHONE

IN STAND-BY)

Open

pedestrian

door

Open

pedestrian

door

Open

pedestrian

door

Open pedestrian

door

Connect / disconnect the automatic door

opening system

--- Audio

activation

End of current

conversation ---

Call volume adjustment for door and ﬂoor

level calls (the possible volume adjustments

are, in this order, LOW, HIGH, MUTE)

Special

function(2)

Special

function(2)

Special

function(2)

Call to switchboard

or intercom(2)

Call source selection (from main calling

station, from secondary calling station, to

ﬂoor, intercom, from switchboard)

Garage

door opener

or special

function(2)

Garage

door opener

or special

function(2)

Garage

door opener

or special

function(2)

Call to switchboard

or intercom(2) Call tone selection

(1) To enter and exit programming state, hold button pressed for longer than 5 seconds. Three fast

beeps will be heard and the yellow LED will blink slowly to indicate that programming mode is selected.

Programming mode will shut down in all cases after the 10 minute timeout (two long beeps will be

heard).

(2) If conﬁgured in front-end beforehand.

2. FEATURES

2.1. CALL RECEPTION

The user’s apartment station will ring with the programmed tone when a call is received according to the

source of the call:

main calling station

secondary calling station

ﬂoor call

intercom call

•

DS1139-004

switchboard.

Green LED under button then lights up.

2.2. ANSWERING THE CALL

Pressing the button, the green LED under the button will start blinking; a conversation with the caller is

established at this point. By pressing again the button , the communication is closed.

2.3. DOOR OPENER DURING CALL

With the door phone in stand-by condition(3) or during call reception(3) (received from the calling station) or

in audio mode (with the calling station), the pedestrian gate or the garage gate can be opened by pressing

buttons or respectively.

(3) According to how the door opener is programmed: free or secret.

2.4. FLOOR CALL

If a ﬂoor call is received, the door phone will play the ring tone chosen by the user.

The function is only available if a button was connected to the “FC” terminals.

2.5. CALLING THE SWITCHBOARD

The user can call the switchboard, if this function has been conﬁgured in IPerVoice server, using one of the

two programmable calling buttons ( and ) present on the door phone.

To perform the call, follow this procedure: with the door phone in “STAND-BY” condition brieﬂy press button

, and then press the calling button associated to the “Call to switchboard” function. Communication will

be established if the switchboard picks up before the timeout. Otherwise, the door phone will be turned off

and will ring as normal when the switchboard calls back. After replying, the green LED under the button will

start blinking; a conversation is established at this point.

2.6. INTERCOM CALL

The function is activated by programming a call button on the door phone in the IPerVoice server. Proceed

as follows to make the call: press button and then press the required call button ( or ); then wait for the

called apartment to reply. Upon the reply, the green LED under the button will start blinking; a conversation

with the called party is established at this point.

2.7. CALL TONE SELECTION

Five call tones are available for selection on apartment stations of the IPerVoice system, one for each calling

source.

The tones can be programmed by following the simple sequence below.

1. enter programming mode by holding button pressed for longer than 5 seconds; the yellow LED will

blink slowly to indicate that programming mode has been selected and the door phone will beep 3

times;

2. press button again for the number of times corresponding to the number of the call source for which

you want to change the call tone according to the following table:

Number of presses of the button Call source

1 From main calling station

2 From secondary calling station

3 Floor call

4 Intercom call

5 From switchboard

•

10 DS1139-004

After one second, the multicolour LED (6) will blink red for the number of times the button was

pressed in sign of conﬁrmation and then will start blinking with yellow light again.

3. press the button to scroll the 5 available ring tones; the multicolour LED (6) blinks red to conﬁrm the

selection;

4. after having made the selection, the user can:

select a different call source for which to change the call tone, by repeating the operation from step 2,

close programming mode by holding button pressed for longer than 5 seconds; in all cases, after

10 minutes the device exits programming state and the changed parameters are saved (two long

beeps are heard).

2.8. ADJUSTING THE CALL VOLUME

Proceed as follows to adjust the call volume (from calling station and to ﬂoor):

1. enter programming mode by holding button pressed for longer than 5 seconds; the yellow LED will

blink slowly to indicate that programming mode has been selected and the door phone will beep 3

times;

2. pressing the button will generate a conﬁrmation beep at the new set call volume (the volume changes

according to the sequence LOW, HIGH, MUTE);

3. close programming mode by holding button pressed for longer than 5 seconds; in all cases, after 10

minutes the device exits programming state and the changed parameters are saved (two long beeps are

heard).

2.9. PANIC ALARM

The “Panic Alarm” signal can only be activated if a button was connected to the “PANIC” terminals.

When the button is pressed, the door phone emits the ﬂoor call (even if the door phone was in

mute mode).

IMPORTANT The following requirements are needed for the panic alarm function:

the system has a switchboard

the system was conﬁgured appropriately (for more information see the IPerVoice handbook on the

www.urmet.com website);

the switchboard is manned;

the switchboard operator is instructed on what to do if a panic alarm is received.

2.10. AUTOMATIC DOOR OPENER

To activate the automatic door opener service:

1. enter programming mode by holding button pressed for longer than 5 seconds; the yellow LED will

blink slowly to indicate that programming mode has been selected and the door phone will beep 3

times;

2. press the button :

• if the function was active, the multicolour LED (6) blinks(4) with green light;

• if the function was deactivated, the multicolour LED (6) is off;

3. close programming mode by holding button pressed for longer than 5 seconds; in all cases, after 10

minutes the device exits programming state and the changed parameters are saved (two long beeps are

heard).

(4) Only after having exited programming mode.

–

•

DS1139-004

3. USER DATA RESET

To restore default parameters of the device after entering programming mode, hold button pressed for

longer than 5 seconds, hold buttons and pressed for longer than 5 seconds. The device will

generate 2 long beeps and reboot.

The user data reset operation is irreversible.

4. REBOOTING THE DEVICE

Rebooting is used to reboot the device. The operation cannot be undone.

To reboot, the door phone must be in stand-by mode. Hold the button pressed for at least 7 seconds.

DS 1139-004 LBT 20347

Area tecnica

servizio clienti +39 011.23.39.810

http://www.urmet.com

e-mail: [email protected]

MADE IN CHINA

URMET S.p.A.

10154 TORINO (ITALY)

VIA BOLOGNA 188/C

Telef. +39 011.24.00.000 (RIC. AUT.)

Fax +39 011.24.00.300 - 323

DS 1139-003 LBT 20317

Mod.

1139

CITOFONO VIVAVOCE IP

IP HAND-FREE DOOR PHONE

INTERPHONE MAINS-LIBRES IP

INTERFONO MANOS LIBRES IP

SPRECHANLAGE MIT FREISPRECHSYSTEM IP

IP HANDSFREE DEURTELEFOON

Sch./Ref.1139/3

LIBRETTO DI INSTALLAZIONE

INSTALLATION HANDBOOK

NOTICE D’INSTALLATION

MANUAL DE INSTALACIÓN

INSTALLATIONSANLEITUNG

INSTALLATIEHANDLEIDING

6DS1139-003

ENGLISH

The Ref. 1139/3 is an IP device dedicated exclusively to the IPerVoice system.

For trouble-free operation, the device requires a LAN/POE-type connection.

DESCRIPTION OF COMPONENTS

1. IPerVoice LAN connector with POE power supply (DOORPHONE POE PORT)

2. 12-way connector for connecting the door phone to optional devices for obtaining the following

functions:

• panic alarm

• call repetition

• ﬂoor call

• Yokis device activation.

WIRE DESCRIPTION FOR SYSTEM CONNECTIONS

Colour Name Description

Yellow PANIC Panic alarm

Green X1 Button

Blue GT Button common and

White Y1 Button

Grey - Not used

Colour Name Description

Grey - Not used

Brown S- Call repetition

Orange S+

Purple FC Floor call

DS1139-003

WIRING INSTRUCTIONS

RJ45 Ethernet Cable

The IPerVoice system has been designed to work with the EIA/TIA 568B standard.

Plug the cable into one of the RJ45 connectors with the Urmet logo.

Insert the wire in its guide, according to the provided colour code (Standard T568B).

Wire

No. Cable colour

1 White-Orange

2 Orange

3 White-Green

4 Blue

Wire

No. Cable colour

5 White-Blue

6 Green

7 White-Brown

8 Brown

Grey sheath

Cut the cables so that they protrude from the guide by about 5 mm, insert the guide in its plug and crimp

with the specially provided tool.

Plug

~ 5 mm

Make sure that the grey sheath stays inside the plug.

This type of connection will NOT guarantee double insulation.

INSTALLATION

WITH FLUSH-MOUNTED CASING MOD. 503

Install ﬂush-mounting box at the height indicated in the drawing below.

Fix the bracket to the mounting box.

Box Mod. 503

Metal bracket

1,55 m

n° 2 M3,5 x 19 mm

included

Connect.

Fix the door phone to the bracket.

•

Table des matières

Autres manuels urmet domus Système d'interphone

urmet domus

urmet domus IPERCOM 1761 Manuel utilisateur

urmet domus

urmet domus signo 1140 Manuel utilisateur

urmet domus

urmet domus 1051 Manuel utilisateur

urmet domus

urmet domus 1083/40 Manuel utilisateur

urmet domus

urmet domus 2voice 1760/15 Manuel utilisateur

urmet domus

urmet domus 1060/601 Manuel d'utilisation et d'installation

urmet domus

urmet domus 2VOICE 1760 Manuel d'installation et d'exploitation

urmet domus

urmet domus modo 1719 Mode d’emploi

urmet domus

urmet domus 2VOICE 1760 Manuel d'installation et d'exploitation

urmet domus

urmet domus 1148 Series Instructions de montage

urmet domus

urmet domus 1155/22 Manuel utilisateur

urmet domus

urmet domus II Series Manuel utilisateur

urmet domus

urmet domus VOG 5 Manuel du système

urmet domus

urmet domus 1760 Manuel d'installation et d'exploitation

urmet domus

urmet domus VOG 7 1760/31 Manuel utilisateur

urmet domus

urmet domus 1717 Manuel utilisateur

urmet domus

urmet domus IPercom VOG7 1761 Manuel d'installation et d'exploitation

urmet domus

urmet domus 2 Voice Mikra Plus 1784 Guide de démarrage rapide

urmet domus

urmet domus 1784/4 Manuel utilisateur

urmet domus

urmet domus IPerCom VOG 7 1761 Series Manuel d'installation et d'exploitation

urmet domus

urmet domus VOG 1760 Manuel d'installation et d'exploitation

urmet domus

urmet domus IPerCom Manuel

urmet domus

urmet domus 1723/96 Manuel d'installation et d'exploitation

urmet domus

urmet domus alpha 1168/45 Manuel utilisateur

Manuels Système d'interphone populaires d'autres marques

Bticino

Bticino LINEA 3000 Manuel utilisateur

MSI

MSI MSI-140 Manuel utilisateur

golmar

golmar Stadio Plus Manuel utilisateur

CyberData

CyberData 011211 series Manuel

Vidos

Vidos duo M1021 Manuel utilisateur

Vimar

Vimar ELVOX 7539/E Manuel utilisateur

SSS Siedle

SSS Siedle BTSV 850-03 Manuel utilisateur

Dahua

Dahua VTO Series Manuel utilisateur

Elvox

Elvox 5651 Manuel utilisateur

Videx

Videx VIDEOKIT Series Manuel utilisateur

Rocom

Rocom Doortello Business FW T2.05W2.04 Manuel utilisateur

Viking

Viking E-35-EWP Manuel utilisateur

Safeguard Supply

Safeguard Supply LRA-EX1000 Manuel utilisateur

SSS Siedle

SSS Siedle BFCV 850 Series Manuel utilisateur

GRD

GRD MAX V2 Manuel utilisateur

Alecto

Alecto ADI-250 Manuel utilisateur

Aiphone

Aiphone IE-8MD Manuel utilisateur

Perel

Perel EDB4 Manuel utilisateur

urmet domus Miro Mode d’emploi

Manuels Système d'interphone populaires d'autres marques
