Uplus Lighting BR360 Manuel utilisateur

User manual

BR360

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions………………………………………………………………………………3

Technical Specifications…………………………………………………………………………4

Control Menu ………………………………………………………………………………………4

DMX Channels ……………………………………………………………………………………5-9

Trouble Shooting…………………………………………………………………………………10

Fixture Cleaning………………………………………………………… ………………………10

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also

receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power requirements of the

unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure

that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always by taking its

base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher than this Unit

surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand during its operation. Turn off

the power and allow about 15 minutes for the unit to cool down before replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit by yourself.

Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized

technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself. In

the unlikely event your unit may require service, please contact your nearest dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid

vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is

secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can

hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the touch of

people.

2.Technical Specifications

SPECIFICATIONS:

LED Source: 3*60W Amber LED，36*3W 3535 3IN1 LED，1*40W 4IN1 LED

Input Voltage:AC90-260V 50/60Hz

Power Consumption: 250W

Control Code:DMX512

Control Channel:15/20/26 channels

Powercon:powercon in & out

DMX sockets:3-pin XLR sockets

Dimmer：0-100％linear dimmer

Strobe：25 times/sec

Dimension:490*450*230mm,NW:8.2KGS

3.Control Menu

Menu Operation

On the base of the control panel offers a number of features, such as setting DMX fixture address,

switch the lamp, run the test program, the mode selection.

Show

Instruction

system settings

DMX address

001-512

operating mode

DMX/sound/Self-propelled

Channel

15CH

20CH

26CH

Manual control

mode

000-255 adjustable

speed

000-255 adjustable

strobe

000-255 adjustable

Color

000-255 adjustable

motor

000-255 adjustable

Display control

language

Chinese/English

reverse

Open/close

Software version

01/A

Factory setting

password 138

Red

4.DMX Channels

15 DMX channels

Channel

Function

Value

Description

CH1

X motor

0-255

0-360 degree

CH2

X motor infinite

0-49

0-360 degree rotation, speed from fast to slow, X motor speed

enabled 360 degree rotation

50-152

Clockwise infinite rotation,

speed from fast to slow

153-255

Anti-Clockwise infinite rotation,

speed from slow to fast

CH3

Amber

Master dimmer

0-255

Linear dimmer, from dark to bright

CH4

Strobe

No function

1-255

Strobe,

speed from slow to fast (1HZ-25HZ)

CH5

Amber

0-4

Light off

5-41

Amber 1

42-76

Amber 2

77-112

Amber 3

113-148

Amber 1 + Amber 2

149-184

Amber 1 + Amber 3

185-220

Amber 2 + Amber 3

221-255

Amber 1 + Amber 2 + Amber 3

CH6

3535RGB

Master dimmer

0-255

Linear dimmer, from dark to bright

CH7

Strobe

No function

1-255

Strobe,

speed from slow to fast (1HZ-25HZ)

CH8

3535RGB 1

(Built-in effect running

color)

0-4

Light off

5-41

Red

42-76

Green

77-112

Blue

113-148

Red + Green

149-184

Red + Blue

185-220

Green + Blue

221-255

Red + Green + Blue

CH9

3535RGB 2

(Built-in effect

background)

0-4

Light off

5-41

Red

42-76

Green

77-112

Blue

113-148

Red + Green

149-184

Red + Blue

185-220

Green + Blue

221-255

Red + Green + Blue

CH10

3535RGB 3

0-4

Light off

5-41

Red

42-76

Green

77-112

Blue

113-148

Red + Green

149-184

Red + Blue

185-220

Green + Blue

221-255

Red + Green + Blue

CH11

Beam RGBW

0-4

Light off

5-36

Red

37-48

Green

49-79

Blue

80-111

White

112-144

Red + Green

145-176

Red + Blue

177-208

Green + Blue

209-240

Red + Green + Blue

241-255

Red + Green + Blue + White

CH12

Amber

Macro

0-4

No function

5-85

Built-in effect 1 (from slow to fast)

86-170

Built-in effect 2 (from slow to fast)

171-255

Built-in effect 3 (from slow to fast)

CH13

3535RGB

Macro

0-4

No function

5-45

Built-in effect 1 (from slow to fast)

46-87

Built-in effect 2 (from slow to fast)

88-129

Built-in effect 3 (from slow to fast)

130-171

Built-in effect 4 (from slow to fast)

172-213

Built-in effect 5 (from slow to fast)

214-255

Built-in effect 6 (from slow to fast)

CH14

Beam RGBW

Macro

0-4

No function

5-85

Built-in effect 1 (from slow to fast)

86-170

Built-in effect 2 (from slow to fast)

171-255

Built-in effect 3 (from slow to fast)

CH15

Reset

0-199

No function

200-255

Reset

20 DMX channels

Channel

Function

Value

Description

CH1

X motor

0-255

0-360 degree

CH2

X motor infinite

0-49

0-360 degree rotation, speed from fast to slow, X motor speed

enabled 360 degree rotation

50-152

Clockwise infinite rotation,

speed from fast to slow

153-255

Anti-Clockwise infinite rotation,

speed from slow to fast

CH3

Amber

Master dimmer

0-255

Linear dimmer, from dark to bright

CH4

Strobe

No function

1-255

Strobe,

speed from slow to fast (1HZ-25HZ)

CH5

Amber 1

0-255

Linear dimmer, from dark to bright

CH6

Amber 2

0-255

Linear dimmer, from dark to bright

CH7

Amber 3

0-255

Linear dimmer, from dark to bright

CH8

3535RGB

Master dimmer

0-255

Linear dimmer, from dark to bright

CH9

Strobe

No function

1-255

Strobe,

speed from slow to fast (1HZ-25HZ)

CH10

3535RGB Red

(Built-in effect running

color)

0-255

Linear dimmer, from dark to bright

CH11

3535RGB Green

(Built-in effect

background)

0-255

Linear dimmer, from dark to bright

CH12

3535RGB Blue

0-255

Linear dimmer, from dark to bright

CH13

Beam RGBW Red

0-255

Linear dimmer, from dark to bright

CH14

Beam RGBW Green

0-255

Linear dimmer, from dark to bright

CH15

Beam RGBW Blue

0-255

Linear dimmer, from dark to bright

CH16

Beam RGBW White

0-255

Linear dimmer, from dark to bright

CH17

Amber

Macro

0-4

No function

5-85

Built-in effect 1 (from slow to fast)

86-170

Built-in effect 2 (from slow to fast)

171-255

Built-in effect 3 (from slow to fast)

CH18

3535RGB

Macro

0-4

No function

5-45

Built-in effect 1 (from slow to fast)

46-87

Built-in effect 2 (from slow to fast)

88-129

Built-in effect 3 (from slow to fast)

130-171

Built-in effect 4 (from slow to fast)

CH18

3535RGB

Macro

172-213

Built-in effect 5 (from slow to fast)

214-255

Built-in effect 6 (from slow to fast)

CH19

Beam RGBW

Macro

0-4

No function

5-85

Built-in effect 1 (from slow to fast)

86-170

Built-in effect 2 (from slow to fast)

171-255

Built-in effect 3 (from slow to fast)

CH20

Reset

0-199

No function

200-255

Reset

26 DMX channels

Channel

Function

Value

Description

CH1

X motor

0-255

0-360 degree

CH2

X motor infinite

0-49

0-360 degree rotation, speed from fast to slow, X motor speed

enabled 360 degree rotation

50-152

Clockwise infinite rotation,

speed from fast to slow

153-255

Anti-Clockwise infinite rotation,

speed from slow to fast

CH3

Amber

Master dimmer

0-255

Linear dimmer, from dark to bright

CH4

Strobe

No function

1-255

Strobe,

speed from slow to fast (1HZ-25HZ)

CH5

Amber 1

0-255

Linear dimmer, from dark to bright

CH6

Amber 2

0-255

Linear dimmer, from dark to bright

CH7

Amber 3

0-255

Linear dimmer, from dark to bright

CH8

3535RGB

Master dimmer

0-255

Linear dimmer, from dark to bright

CH9

Strobe

No function

1-255

Strobe,

speed from slow to fast (1HZ-25HZ)

CH10

3535RGB Red 1

(Built-in effect running

color)

0-255

Linear dimmer, from dark to bright

CH11

3535RGB Green 1

(Built-in effect

background)

0-255

Linear dimmer, from dark to bright

CH12

3535RGB Blue 1

0-255

Linear dimmer, from dark to bright

CH13

3535RGB Red 2

0-255

Linear dimmer, from dark to bright

CH14

3535RGB Green 2

0-255

Linear dimmer, from dark to bright

CH15

3535RGB Blue 2

0-255

Linear dimmer, from dark to bright

CH16

3535RGB Red 3

0-255

Linear dimmer, from dark to bright

CH17

3535RGB Green 3

0-255

Linear dimmer, from dark to bright

CH18

3535RGB Blue 3

0-255

Linear dimmer, from dark to bright

CH19

Beam RGBW Red

0-255

Linear dimmer, from dark to bright

CH20

Beam RGBW Green

0-255

Linear dimmer, from dark to bright

CH21

Beam RGBW Blue

0-255

Linear dimmer, from dark to bright

CH22

Beam RGBW White

0-255

Linear dimmer, from dark to bright

CH23

Amber

Macro

0-4

No function

5-85

Built-in effect 1 (from slow to fast)

86-170

Built-in effect 2 (from slow to fast)

171-255

Built-in effect 3 (from slow to fast)

CH24

3535RGB

Macro

0-4

No function

5-45

Built-in effect 1 (from slow to fast)

46-87

Built-in effect 2 (from slow to fast)

88-129

Built-in effect 3 (from slow to fast)

130-171

Built-in effect 4 (from slow to fast)

172-213

Built-in effect 5 (from slow to fast)

214-255

Built-in effect 6 (from slow to fast)

CH25

Beam RGBW

Macro

0-4

No function

5-85

Built-in effect 1 (from slow to fast)

86-170

Built-in effect 2 (from slow to fast)

171-255

Built-in effect 3 (from slow to fast)

CH26

Reset

0-199

No function

200-255

Reset

5.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

6.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

Table des matières

Autres manuels Uplus Lighting Équipement d'éclairage

Uplus Lighting

Uplus Lighting IP 300Z SPOT-WW Manuel utilisateur

Uplus Lighting

Uplus Lighting 250 BEAM Manuel utilisateur

Uplus Lighting

Uplus Lighting IR 1210 PAR Manuel utilisateur

Uplus Lighting

Uplus Lighting 200 MZ-SPOT PR Manuel utilisateur

Uplus Lighting

Uplus Lighting 100SPOT Manuel utilisateur

Uplus Lighting

Uplus Lighting W3725 Manuel utilisateur

Uplus Lighting

Uplus Lighting BL6 Manuel utilisateur

Uplus Lighting

Uplus Lighting 6 EYE RETRO BAR Manuel utilisateur

Uplus Lighting

Uplus Lighting 230 BEAM Manuel utilisateur

Uplus Lighting

Uplus Lighting MIX560 Manuel utilisateur

Uplus Lighting

Uplus Lighting IP-L360 Manuel utilisateur

Uplus Lighting

Uplus Lighting PF350 Manuel utilisateur

Uplus Lighting

Uplus Lighting 460LED BSW Manuel utilisateur

Uplus Lighting

Uplus Lighting BAR 6 LASER Manuel utilisateur

Uplus Lighting

Uplus Lighting LED PROFILE FIX Manuel utilisateur

Uplus Lighting

Uplus Lighting 200 LED BSW Manuel utilisateur

Uplus Lighting

Uplus Lighting MH12X40 PIXEL BAR Manuel utilisateur

Uplus Lighting

Uplus Lighting RETRO 360 Manuel utilisateur

Uplus Lighting

Uplus Lighting 37X15ZWASH Manuel utilisateur

Uplus Lighting

Uplus Lighting 750 BSWF Manuel utilisateur

Uplus Lighting

Uplus Lighting DUAD540 STROBE Manuel utilisateur

Uplus Lighting

Uplus Lighting IP1000 Strobe Manuel utilisateur

Uplus Lighting

Uplus Lighting 400 BLINDER Manuel utilisateur

Uplus Lighting

Uplus Lighting 250 LED BEAM Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
