Uplus Lighting IP MATRIX 5 Manuel utilisateur

User manual

IP MATRIX 5

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions………………………………………………………………………………3-4

Technical Specifications……………………………………………………………………………4

Control Menu …………………………………………………………………………………………4

DMX Channels ………………………………………………………………………………………5-7

Trouble Shooting……………………………………………………………………………………8

Fixture Cleaning………………………………………………………… …………………………8

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Input Voltage:AC90-240V,50/60Hz

Power Consumption:100W

Light Source:5pcs 15W RGBW 4in1 LED

Each LED can be controlled individual

Lamp life:50000hrs

Beam Angle: 30 ゜

Display :Digital display

Control Mode:DDMX, auto, RDM

DMX Channel:6/7/21/30 DMX Channels

Dimmer:0-100% smooth linear adjustment

Strobe:High speed strobe effect with 1-25 flashes per second

IP Rate:IP65

Strobe: 0-30Hz

Each light can link to work

Dimension:580*160*120MM (L*W*H)

Net weight：5.4Kg

3.Control Menu

Display:

DMX display

Function

DMX addr

DMX address setting

001

chan Mod

DMX channel mode option:6/7/21/30

06CH

workMod

work mode: DMX,auto

DMX512

AutoSP

Auto mode speed setting

M/S mod

master/slave setting, set Master for master unit, set SLAVE for DMX and slave

unit

Slave

Dimm mod

Dimmer mode setting: normal mode, delay mode

normal

Runtime

total working time

0000

Versin

software version

V0.01

4.DMX Channels

DMX Channels(6 channels)

Channel

Function

Value 0-255

instruction

LED 1 dimmer

0-255

LED 1 dimmer 0-100%

LED 2 dimmer

0-255

LED 2 dimmer 0-100%

LED 3 dimmer

0-255

LED 3 dimmer 0-100%

LED 4 dimmer

0-255

LED 4 dimmer 0-100%

LED 5 dimmer

0-255

LED 5 dimmer 0-100%

Color

1-17

red

18-34

green

35-51

blue

52-68

white

69-85

red+green

86-102

red+blue

103-119

red+white

120-136

green+blue

color

137-153

green+white

154-170

blue+white

171-187

red+green+blue

188-204

red+green+white

205-221

red+blue+white

222-238

green+blue+white

239-255

red+green+blue+white

DMX Channels(7 channels)

Channel

Function

Value 0-255

instruction

master dimmer

0-255

master dimmer 0-100%

red

0-255

red dimmer 0-100%

green

0-255

green dimmer 0-100%

blue

0-255

blue dimmer 0-100%

white

0-255

white dimmer 0-100%

strobe

0-255

strobe 0-100%

color marco

0-7

no effect

8-255

color Marco, each 6 value for one color marco

DMX Channels(21 channels)

Channel

Function

Value 0-255

instruction

master dimmer

0-255

LED 1 red dimmer

0-255

LED 1 red dimmer 0-100%

LED 1 green dimmer

0-255

LED 1 green dimmer 0-100%

LED 1 blue dimmer

0-255

LED 1 blue dimmer 0-100%

LED 1 white dimmer

0-255

LED 1 white dimmer 0-100%

LED 2 red dimmer

0-255

LED 2 red dimmer 0-100%

LED 2 green dimmer

0-255

LED 2 green dimmer 0-100%

LED 2 blue dimmer

0-255

LED 2 blue dimmer 0-100%

LED 2 white dimmer

0-255

LED 2 white dimmer 0-100%

LED 3 red dimmer

0-255

LED 3 red dimmer 0-100%

LED 3 green dimmer

0-255

LED 3 green dimmer 0-100%

LED 3 blue dimmer

0-255

LED 3 blue dimmer 0-100%

LED 3 white dimmer

0-255

LED 3 white dimmer 0-100%

LED 4 red dimmer

0-255

LED 4 red dimmer 0-100%

LED 4 green dimmer

0-255

LED 4 green dimmer 0-100%

LED 4 blue dimmer

0-255

LED 4 blue dimmer 0-100%

LED 4 white dimmer

0-255

LED 4 white dimmer 0-100%

LED 5 red dimmer

0-255

LED 5 red dimmer 0-100%

LED 5 green dimmer

0-255

LED 5 green dimmer 0-100%

LED 5 blue dimmer

0-255

LED 5 blue dimmer 0-100%

LED 5 white dimmer

0-255

LED 5 white dimmer 0-100%

DMX Channels(30 channels)

Channel

Function

Value 0-255

instruction

LED 1 master dimmer

0-255

LED 1 master dimmer 0-100%

LED 1 red dimmer

0-255

LED 1 red dimmer 0-100%

LED 1 green dimmer

0-255

LED 1 green dimmer 0-100%

LED 1 blue dimmer

0-255

LED 1 blue dimmer 0-100%

LED 1 white dimmer

0-255

LED 1 white dimmer 0-100%

LED 1 strobe

0-255

LED 1 strobe

LED 2 master dimmer

0-255

LED 2 master dimmer 0-100%

LED 2 red dimmer

0-255

LED 2 red dimmer 0-100%

LED 2 green dimmer

0-255

LED 2 green dimmer 0-100%

LED 2 blue dimmer

0-255

LED 2 blue dimmer 0-100%

LED 2 white dimmer

0-255

LED 2 white dimmer 0-100%

LED 2 strobe

0-255

LED 2 strobe

LED 3 master dimmer

0-255

LED 3 master dimmer 0-100%

LED 3 red dimmer

0-255

LED 3 red dimmer 0-100%

LED 3 green dimmer

0-255

LED 3 green dimmer 0-100%

LED 3 blue dimmer

0-255

LED 3 blue dimmer 0-100%

LED 3 white dimmer

0-255

LED 3 white dimmer 0-100%

LED 3 strobe

0-255

LED 3 strobe

LED 4 master dimmer

0-255

LED 4 master dimmer 0-100%

LED 4 red dimmer

0-255

LED 4 red dimmer 0-100%

LED 4 green dimmer

0-255

LED 4 green dimmer 0-100%

LED 4 blue dimmer

0-255

LED 4 blue dimmer 0-100%

LED 4 white dimmer

0-255

LED 4 white dimmer 0-100%

LED 4 strobe

0-255

LED 4 strobe

LED 5 master dimmer

0-255

LED 5 master dimmer 0-100%

LED 5 red dimmer

0-255

LED 5 red dimmer 0-100%

LED 5 green dimmer

0-255

LED 5 green dimmer 0-100%

LED 5 blue dimmer

0-255

LED 5 blue dimmer 0-100%

LED 5 white dimmer

0-255

LED 5 white dimmer 0-100%

LED 5 strobe

0-255

LED 5 strobe

5.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

6.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

Table des matières

Autres manuels Uplus Lighting Équipement d'éclairage

Uplus Lighting

Uplus Lighting IP1000 Strobe Manuel utilisateur

Uplus Lighting

Uplus Lighting 200 BLINDER Manuel utilisateur

Uplus Lighting

Uplus Lighting 250 BEAM Manuel utilisateur

Uplus Lighting

Uplus Lighting LED PROFILE FIX Manuel utilisateur

Uplus Lighting

Uplus Lighting PIXEL IP20X15 BAR Manuel utilisateur

Uplus Lighting

Uplus Lighting 19X15Z WASH Manuel utilisateur

Uplus Lighting

Uplus Lighting BL6 Manuel utilisateur

Uplus Lighting

Uplus Lighting 6 EYE RETRO BAR Manuel utilisateur

Uplus Lighting

Uplus Lighting PF350 Manuel utilisateur

Uplus Lighting

Uplus Lighting 230 BEAM Manuel utilisateur

Uplus Lighting

Uplus Lighting RETRO 360 Manuel utilisateur

Uplus Lighting

Uplus Lighting BSW 350 Manuel utilisateur

Uplus Lighting

Uplus Lighting 400 BLINDER Manuel utilisateur

Uplus Lighting

Uplus Lighting IP 300Z SPOT-WW Manuel utilisateur

Uplus Lighting

Uplus Lighting 200 LED RETRO Manuel utilisateur

Uplus Lighting

Uplus Lighting 150COBPAR Manuel utilisateur

Uplus Lighting

Uplus Lighting 20 MINI SPOT Manuel utilisateur

Uplus Lighting

Uplus Lighting 400 IP BLINDER Manuel utilisateur

Uplus Lighting

Uplus Lighting BAR 6 LASER Manuel utilisateur

Uplus Lighting

Uplus Lighting 460LED BSW Manuel utilisateur

Uplus Lighting

Uplus Lighting IP-Z740 Manuel utilisateur

Uplus Lighting

Uplus Lighting IR 1210 PAR Manuel utilisateur

Uplus Lighting

Uplus Lighting 250 LED BEAM Manuel utilisateur

Uplus Lighting

Uplus Lighting 200 LED BSW Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
