Owner’s Manual

Place URC

logo here.

Page | 1

Congratulations!

With your new URC-A6 universal remote,

you now have the power to control your

home entertainment system with just one

easy-to-use control. Thousands of audio and

video component codes have already been

programmed into the remote for you, making

it a breeze to set up. Be sure to install the

included batteries first. See page 5 for

instructions.

Quick Set-up

Note: Selecting the proper Component

button is a key to your success. f you have

a combination component that includes a

DVD or Blu-Ray player, use the DVD button

regardless of other functions, so that the DVD

transport controls will work properly. Select

SAT/CABLE for your cable box so the Menu,

Guide, nfo and Exit buttons work correctly.

Set-up one component at a time, and you’ll

move quickly through your system.

TEP1: Turn on the component you want to

activate. (Other components can be on or

off, it doesn’t matter.)

TEP2:Point your new URC-A6 universal

remote toward the component and press the

appropriately labeled Component button (TV

for TV, DVD for DVD, etc.) While holding

this button down, press the numeric keys one

at a time sequentially (1, 2, 3, etc.) until the

component turns off.

TEP3:Release the Component button to

save the code. The component light will

blink three times to confirm that the code has

been stored.

Check your work before you move to the

next component. Press the POWER [ON]

button to turn the component back on.

Next, test the VOLUME and CHANNEL

buttons (or PLAY and STOP buttons for VCR

and DVD). Repeat Steps 1-3 to activate up

to six components.

Didn’t work for one of your components?

See other set-up options starting on page 7.

Page | 2

Keypad Layout and

Button Functions

Allows you to turn the selected

component on and off.

POWER

Designed to send Power On/Off

commands for up to six components

with one button press.

SYSTEM OFF

sed to select the

component you

want to operate

and signals remote control

activity.

Displays the Applications

Menu through the Cable Set

Top Box.

COMPONENTS

Raises or lowers the sound

volume.

VOL ME

Exits from current

screen through the

Cable Set Top Box.

Custom-programmable Favorite

Channel Buttons

FAVORITES

Controls Picture-In-

Picture actions.

PIP

CONTROLS

se to enter code numbers

for programming

components and to enter

channel numbers to tune

in channels. Also used to

make numeric entries on

on-screen menus.

Perform standard VCR and

DVD functions when in VCR

and DVD mode, or VOD

(Video-On-Demand) and

DVR (Digital Video

Recorder) functions when

in Cable mode.

TRANSPORT

CONTROLS

MEN

Displays the

Program Guide

listings through

the Cable Set Top

Box.

Displays information about

the program currently

playing or highlighted in the

Program Guide through the

Cable Set Top Box.

INFO

G IDE

sed for

programming steps

and on-screen

navigation and

highlighting.

C RSOR

NAVIGATION

PAD

EXIT

Selects highlighted

screen options.

SELECT

Selects the video

source from

available

components.

INP T

Returns to the

previously tuned

channel through

the Cable Set Top

Box.

LA T

Silences the Audio.

Press to activate. Press

again to restore sound

to the previous level.

M TE

N MBER PAD

Replace

with

high

quality


Page | 3

Table of Contents

Quick Set-up ..............................1

Keypad Layout & Button Functions..

................................................2

Getting Started – Overview

• Battery nstallation..................5

• Activation Overview ..............5

• Using Component Buttons ......6

• Learning Capability................6

• Low Battery Warning..............6

• Couch Mode ........................6

Get Started with the Basics ........7

• Quick Set-Up ........................8

• Three-Digit Set-up .............9-10

• Auto-Search Set-up .........11-12

• Set-up Using the

Learning Method..............13-15

Activating Optional

Advanced Features...............16-17

• MacroPower™ Total System

On/Off ............................18

• “My Favorites”.................19-22

Activating Push Throughs ..........22

• SimpleSound™ Total System

Volume Control ....................23

• Channel Control

Punch Through ....................24

• Transport Control

Punch Through ....................25

• OSD (On-Screen Display)

Control Punch Through..........26

Page | 4

Erasing Commands -

Overview ................................27

• Erasing a Single Learned

Command ..........................28

• Erasing All Learned Commands

from One Component ..........29

• Erasing MacroPower & Other

Macro Commands ..............30

• Erasing SimpleSound & Other

“Punch Through”

Commands..31

• Factory Reset ......................32

Finding a Component’s Set-Up

Code Number..........................33

Pre-Programmed

Code Tables ..........................34

• Cable/Sat ..........................35

• TV..................................36-37

• DVD/DVR. ..........................38

• AUD O ..............................39

• AUX ..................................40

• L GHTS ..............................41

FAQs ....................................42

Warranty ................................43

Specifications ..........................43

nformation to the user ..............44

Warnings ................................44

Getting Started - Overview

BatteryInstallation

Press the tab and remove the cover of the

battery compartment located in the back of

your remote. nsert the two AAA Alkaline

batteries (included in the package) making

sure to match the positive (+) and negative (-)

symbols as shown in the diagram. Place the

cover back over the battery compartment.

Activationoverviewcontrolup

tosixcomponents

Your URC-A6 Universal remote control is

designed to operate virtually all brands of

AUD O, TV, DVD, CD, SAT/CABLE, Lights,

and AUX (Music Server, games, etc.)

components.

ComponentButtons

Be sure to match your component to the

proper Component button on the top of the

remote.

f your component is a combination device

that includes a DVD option, program the

DVD or AUX button so that the transport

controls will work properly.

The AUX (Auxiliary) button is designed to

operate a 6th audio/video component that

you may have in your system… such as a

T VO, a second VCR or DVD, or an

additional audio component.

Page | 5

Replace

with

high

quality


Replace

with

high

quality


UsingComponentButtons

Once you have activated the URC-A6 remote

for all of your components, you can simply

press a Component button at the top of the

remote, and the buttons on the URC-A6 will

work with that component.

Each time you press a button on the remote,

the Component button light will turn on,

indicating which component you are

controlling.

LearningCapability

The URC-A6 has the ability to learn functions

from the original remote controls of other

manufacturers, even if they are not in our

pre-programmed database. See page 13 for

instructions.

LowBatteryWarning

When the batteries are low and need to be

replaced, the component light will quickly

blink three times when you press the POWER

ON button.

CouchMode

We’re watching out for your batteries. Your

URC-A6 remote is designed to automatically

turn itself off if a button is pressed for more

than 30 seconds. This prevents battery

power from being depleted if the remote

accidentally slips between the couch

cushions.

We love to help!

PLEASE CONTACT OUR TECHN CAL

SUPPORT CENTER.

E-MA L: techsupport@UniversalRemote.com

Phone: 1-800-901-0800 (9:00AM - 6:00PM

EST Monday - Friday)

PLEASE DO NOT RETURN

TH S PRODUCT TO THE STORE

Page | 6

Page | 7

Three ways to get started

There are three ways you can activate your

new URC-A6 universal remote control using

its pre-programmed codes.

1. Quick Set-Up (page 8)

2. Three-Digit Code Set-up (page 9)

3. Auto—Search Set-up (page 11)

Component Buttons

Selecting the proper Component button is a

key to your success. f you have a

combination component that includes a DVD

or Blu-Ray player, use the DVD button

regardless of other functions, so that the DVD

transport controls will work properly. Select

SAT/CABLE for your cable box so the Menu,

Guide, nfo and Exit buttons work correctly.

n addition to activating the pre-programmed

codes, the URC-A6 universal remote has the

capacity to learn from your component

remote. See instructions on page 13.

AUX Component Button

While most component buttons are self-

explanatory, the AUX Component button is

designed for components such as Xbox ,

PS2 or PC media centers. Simply program

the AUX button in the same manner as any

other component using Quick Set-Up, the 3-

Digit Set-up or Auto-Search Set-up.

The AUX button can also be used for other

components such as a second TV, DVD, or

any other audio/video component that you

may have in your system. You may need to

activate the key as a Macro if you are

connecting a second DVD or VCR.

See

page 16 for more information on automated

activity macros.

Page | 8

1. Quick Set-up

Set-up one component at a time, and you’ll

move quickly through your system.

tep1: Turn on the component you want to

activate. (Other components can be on or

off, it doesn’t matter.)

tep2: Point your new URC-A6 universal

remote toward the component and press the

appropriately labeled Component button (TV

for TV, DVD for DVD, etc.) While holding

this button down, press the numeric keys one

at a time sequentially (1, 2, 3, …) until the

component turns off.

tep3: Release the component button to

save the code. The component light will

blink three times to confirm that the code has

been stored.

Check your work Press the POWER [ON]

button to turn the component back on.

Next, test the VOLUME and CHANNEL

buttons (or PLAY and STOP buttons for VCR

and DVD) to make sure they all work.

Repeat steps one through three until all your

components are set up properly.

Replace

with

high

quality


Page | 9

2. Three-Digit Set-up

TEP1: Find the 3-digit code numbers for

your component type and brand from the

lists in the back of this manual. The codes

are listed by component type (TV, VCR, DVD,

etc.), then by brand name. Be sure to

identify the list of codes for the correct

component and brand. For instance, if you

would have a Sony television, first locate the

TV category, and then look for the Sony

brand. Be careful. Codes for Sony DVDs

may be different than from Sony TVs.

You may want to write the numbers down on

a piece of paper before moving to step two.

TEP2: Turn on the component you want to

activate. (Other components can be on or

off, it doesn’t matter.)

TEP3: On your URC-A6 universal remote,

press the Component button that you want to

set up and the SELECT [SEL] button at the

same time. Hold down both buttons for two

seconds until the Component light turns on.

This signals that you are in set-up mode, and

you can then release the buttons.

TEP4:Point the URC-A6 toward the

component and use the number buttons 0-9

to punch in the first 3-digit code for that

specific component.

f the 3-digit code number you just punched

in is the correct number, the component you

are activating will turn off. f it did not turn

off, enter the next code number from your list

until it does turn off.

Note: f you do not press a button within 30

seconds, the component light will turn off.

The remote will exit the set-up mode, and

you will have to start over with step three.

Replace

with

high

quality


Autres manuels pour URC-A6

Table des matières

Autres manuels Universal Remote Control Télécommande

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manuel utilisateur

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manuel utilisateur

Universal Remote Control

Universal Remote Control Easy Clicker UR3L-SR4 Manuel utilisateur

Universal Remote Control

Universal Remote Control UR2-DTA Manuel utilisateur

Universal Remote Control

Universal Remote Control URC 22?-7 Manuel utilisateur

Universal Remote Control

Universal Remote Control MX-800 Manuel utilisateur

Universal Remote Control

Universal Remote Control CABLEVISION UR2-CBL-CV04 Manuel utilisateur

Universal Remote Control

Universal Remote Control ZC800 Manuel utilisateur

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8780L Manuel utilisateur

Universal Remote Control

Universal Remote Control UR4-DCT Manuel utilisateur

Universal Remote Control

Universal Remote Control MX-5000 Network Wand Manuel utilisateur

Universal Remote Control

Universal Remote Control PHAZR-5 Manuel utilisateur

Universal Remote Control

Universal Remote Control Complete Control MX-980 Manuel du propriétaire

Universal Remote Control

Universal Remote Control PHAZR-5 UR5L-9000L-IP Manuel utilisateur

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manuel utilisateur

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Manuel utilisateur

Universal Remote Control

Universal Remote Control UR5U-8820L Manuel utilisateur

Universal Remote Control

Universal Remote Control PHAZR-5 Manuel utilisateur

Universal Remote Control

Universal Remote Control UR4U-MDVR-CHD2 - SPECS SHEET Manuel utilisateur

Universal Remote Control

Universal Remote Control UR5U-8520L Manuel utilisateur

Universal Remote Control

Universal Remote Control RF10 MASTERCONTROL Manuel utilisateur

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Manuel utilisateur

Universal Remote Control

Universal Remote Control MX-980 Manuel utilisateur

Universal Remote Control

Universal Remote Control PHAZR-5 UR5U-9000 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
