Universal Remote Control UR-S475TVE Manuel utilisateur

Operating Manual

for 2 in 1 Cable TV

Remote Control

UR-S475TVE

Universal Remote Control, Inc.

www.universalremote.com

OCE-0003A Rev 03(05/14/02)

This remote control is preprogrammed to operate

CABLE Box. Please program it for your TV by

following the instructions shown below.

Instructions

Batteries

Programming your remote control

Install two AAA alkaline

batteries as shown here

The remote control uses AAA batteries. Please be sure

to match the batteries with the (+) and (

)markings

inside the battery compartment during installation.

STEP2

Press [TV] and [MUTE] buttons simultaneously

until the red light is on.

STEP3 Point the remote control toward the TV and

enter the three-digit code from the code table. If there

is more than one code number assigned to your TV

brand, try one code number at a time until the TV

turns off right after you entered the number.

Searching Method

Press [CH +] button and hold until the TV turns off. As

soon as the TV turns off, release [CH+] button.

*Tip : You can confirm the power off and on by

pressing [MUTE] button.

STEP4 Press [TV] button to store the three-digit

code.

*Tip :

Red light

will blink twice.

Three-digit code :

STEP2 Press [CH +] button.

*Tip : Red light will blink twice.

The [CATV] button sends out the TV and CABLE

power commands if you press the [CATV] button.

To return to the original function, press the [CH-]

button in the STEP2 .

B. Recalling the TV Three Digit code :

STEP1 Press [TV] and [MUTE] buttons simultaneously

until the red light is on.

STEP2 Press [VOLUME -] button.

The red light will blink a number of times indicating the

number of each digit of the code. Each digit is

separated by one second interval of red light being off.

*Tip : One blink, three blinks and 10 blinks,

indicates the code number 130.

The remote control is preprogrammed to control

VOLUME and MUTE functions through your TV. To

switch VOLUME and MUTE functions to your Cable Box:

STEP1 Press [CATV] and [MUTE] buttons simultaneously

until red light is on.

STEP2 Press [VOLUME +] button.

STEP3 Press [CATV] button.

To return to the TV’s VOLUME press [TV] button.

*Tip : Red light will blink twice.

Set-up for advanced functions

A. To turn on your TV and Cable at the same time

with CATV button:

STEP1 Press [CATV] and [0] buttons simultaneously

until the red light is on.

Set-up for your VOLUME control

Set-up for your Cable Box

The remote control is preprogrammed to control

your cable box. If it does not work properly, please

set-up the right code by using the three-digit code

or searching method.

If you have a TV with a remote control, we

recommend that you plug its power cord directly

into a wall outlet if available (your cable installer

may select an alternate setup)

Operation

If red light does not blink when you press keys the

operation is intermittent:

Make sure the batteries are inserted correctly.

Replace old batteries with two new AAA batteries.

Please do not mix old batteries with new ones.

Helpful hints

Press arrow gently &

pull down to remove cover

Setup for your cable box

No setup is required. The remote control is

preprogrammed to operate your cable box.

Setup for your TV

Find your TV brand and its three-digit code on the

back of this manual. If the TV brand is not listed,

please use the Searching Method in STEP3 .

STEP1 Turn on your TV manually.

*Tip : If you have RCA TV, don’t turn on the TV.

Three Digit Code Table

BRAND NAME CODE NUMBER (3 DIGIT) LIST

ENVISION 070

FISHER 007 057

FUNAI 028 043 234

FUTURETECH

043

GE 160 161 070 073 130 144 004 008 009 034

056 074 091 155 223 224 232 241

GOLDSTAR 004 106 119 110 112 113 127 143 242 244

GO VIDEO 235

HALL MARK 004

HARMAN KARDON

211

HITACHI 163 004 007 009 011 072 010 012 023 075

143 158 208 234

INFINITY 164

INKEL 129

INSTANTREPLAY

232

JBL 164 209

JCL 232

JCP 070

JCPENNY 004 008 024 030 065 101 143 160 156 235

242

JENSEN 013

JVC 038 001 034 083 232 238

KENWOOD 001 070 234

KLOSS 002 059

KMC 219

KTV 070 043 143 154

LG 004 106 119 110 112 113 127 143 242 244

LLOYD 234

LODGENET 072

LOGIK 072

LUXMAN 004

LXI 007 015 052 081 160 164 234

MAGNAVOX 070 003 004 022 059 060 061 063 064 127

164 094 160 056 232 234 239

MAGIN 235

MARANTZ 164 070 232

MARTA 242

MATSUI 164

MEMOREX 004 007 072 232 234 241 242

BRAND NAME CODE NUMBER (3 DIGIT) LIST

A MARK 112 143

ADMIRAL 072 081 160 161

AIWA 234

AKAI 070 146 004

AMPRO 073 167 241

ANAM 043 054 055 056 080 112 131 232

AOC 058 070 004 112 222

AUDIOVOX 076 103

CANDLE 070 002 003 004

CANON 232

CAPEHART 058

CETRONIC 043

CITIZEN 070 002 003 004 101 103 143

CLASSIC 043

CONCERTO 004

CONTEC 043 051 207 230

CORONADO 143

CRAIG 043 054 028 235

CROWN 043 143

CURTIS MATHES

070 004 101 143 232

CXC 043

DAEWOO 076 103 055 004 127 143 016 043 044 125

120 214 215 229 231 243

DAYTRON 004 143

DWIN 161

DYNASTY 043

DYNATECH 062 209 234

ELECTROHOME

024 076 143

EMERSON 028 043 048 155 005 076 096 004 051 143

151 153 154 216 217 230 232 234 242 246

BRAND NAME CODE NUMBER (3 DIGIT) LIST

MEI 232

METZ 088

MGA 024 070 004 042

MINERVA 088

MITSUBISHI 109 024 042 004 040 146 028 124 226 247

MTC 070 004 062 101 209 229 234 235

MULTITECH 234

NAD 015 025

NEC 070 130 134 040 056 007 019 024 004 213

NIKEI 043

ONKING 043

ONWA 043

OPTONICA 019 081

ORION 096 201 202 203 204 205

PANASONIC 034 056 080 164 206 232 240

PENNEY 065 160 004 008 070 143 030 221

PENTAX 232

PHILCO 070 003 004 024 056 059 060 063 064 127

143 164 232 234

PHILIPS 164 005 038 093 127 070 003 004 059 232

234 242

PILOT 242

PIONEER 025 023 135 176 004 018 070

PORTLAND 004 143

PROSCAN 144 160 161 167

PROTON 004 058 143 171 173 193 131

QUASAR 034 056 232 240

RADIO SHACK

004 019 127 143 043 244

RCA 160 161 144 156 065 070 004 023 024 056

074 152 221 232 234 235

REALISTIC 007 019 232 234 235 242

RICO 237

RUNCO 072 169 073 130 179 180 181

SAMPO 070 004 058 218 220

SAMSUNG 004 101 127 133 143 160 089 105 070 233

235

SANYO 007 053 057 082 020 212

SCOTT 004 005 028 043 048 143

SEARS 004 007 015 028 030 057 082 094 143 160 242

BRAND NAME CODE NUMBER (3 DIGIT) LIST

SELECO 189

SHARP 081 014 019 028 004 022 081 143 175 029

232 245

SIGNATURE 072 234

SONY 001 085 126 139 232 236 237

SOUNDESIGN

003 004 028 043 234

SPECTRICON

112

SSS 004 043

SUPRE MACY

002

SYLVANIA 070 003 059 060 063 064 127 160 164 044

056 210 232 234

SYMPHONICS

052 234

TANDY 081 234

TATUNG 056 062 209

TEAC 234

TECHNICS 034 080 232 240

TECHWOOD 004

TEKNIKA 002 003 004 024 028 043 072 101 143 103

227 232 234 242

TELERENT 072

TERA 172

TMK 004

TOSHIBA 015 030 007 040 062 101

TOTEVISION 143 235 242

UNIVERSAL 008 009

UNITECH 235

VIDEO CONCEPTS

146 234

VIDEOSONIC 235

VIDIKRON 174 188

VIDTECH 004

WESTING HOUSE

076

WARDS 004 064 164 008 009 019 028 060 061

063 072 074 143 070 224 225 232 234

235

YAMAHA 004 070 234

YORK 004

YUPITERU 043

ZENITH 073 072 095 103 234 237 241 242

ZONDA 112

Remote Converter Converter Model

Code No

CABLE

UR-S475TVE Scientific Atlanta 8590/8540 004
