Unitech MS140 Manuel utilisateur

User’s Manual

MS140-3 or MS140I-3

Keyboard Wedge

Slot Reader

PC Keyboard Wedge Setup Label

Overview

There are two models of the MS140 decoded slot reader available:

•The MS140-3 keyboard wedge slot reader which supports PC/AT, XT,

notebooks and Macintosh computers

•The MS140-2 RS232 interface slot reader that supports computers with

RS232 serial port.

Both of these readers support the most popular bar code symbologies, like

Code 39, UPC/EAN, Interleaved 2 of 5, Standard 2 of 5, Code 128, Codabar,

MSI, Code 11, Code 93, etc.

MS140-3 Keyboard Wedge

Setup of the keyboard wedge reader can be done in three different ways:

•Via computer keyboard of a desktop PC.

•By Scanner Configuration Manager Software to configure the scanner

setting through the keyboard port.

•By using the custom labels (batch setup).

Installation:

The picture below illustrates how to connect the reader to your computer.

Follow these procedures for installation:

1. Turn off computer power.

2. Unplug keyboard from computer. Plug the reader into computer’s

keyboard port and the keyboard into the reader.

3. Turn on power. One long beep from the reader indicates successful

power-up.

MS140

The default device ID of the reader is set to PC/AT. If your computer is not a

PC/AT, please perform the setup on a PC/AT machine first in order to select a

correct device ID. The device ID “06” (Keyboardless) is for notebook

computers.

Keyboard Wedge Setup

The reader’s behavior can be changed via a setup routine in the reader. Setup

can be performed on a PC/AT computer with any text editor program, such as

Notepad, WordPad, etc. After the text editor program is running, there are

three different ways to enter setup:

•Swipe the “Keyboard Wedge Setup Label” bar code located on the cover

page of this manual.

•Press the left and right SHIFT keys simultaneously within the first 20

keystrokes after computer power up. (This will apply when the reader

has device ID set to PC/AT interface only. Swipe the “Enter Setup”

label if you have this manual handy.)

•Use custom labels (batch setup).

When the reader enters the setup mode, a selection menu will be displayed on

the screen. Please refer to the MS140 Setup Manual Section.

MS140-2 RS232 Wedge

Setup of the RS232 wedge reader can be done in two different ways:

•Through a modem communication utility (such as HyperTerminal).

•Via custom labels (batch setup).

Installation:

The picture below shows how to connect the reader to your computer. Use the

following procedures for installation:

1. Turn off computer power.

2. Plug the reader into the computer’s RS232 port.

3. Turn on power. One long beep from the reader indicates successful

power-up.

MS140

Power

Supply

DB9 Connector

The default baud rate of the reader is set to 9600, no parity, and 8 data bits.

RS232 Interface Setup

The reader’s behavior can be changed through a setup routine in the reader.

Setup can be performed (at 9600 baud rate, 8bits and no parity) with any

modem communication utility, such as Windows’ HyperTerminal. To enter

Setup mode, start the Communication utility on the PC and swipe “RS232

Interface Setup Label” bar code label located on the back page of this manual.

On entering the Setup mode, a selection menu will be displayed on the screen

as follow:

MS140 SETUP MENU

Hamster_S V3.03 Nov.15,2000

Use numeric keys on the top of alphabetic keys for digit input.

0-Device 1-Scanner 2-Barcode 3-MSR 4-Others 5-RS232 6-Default 7-dump

8-Exit

Select==> _

Follow the prompts and make your selections accordingly. The setup

procedure is that simple. (Use Ctrl_R in lieu of the shift key in a string input

procedure. This method allows the user to input ASCII characters into a

string.)

Batch Setup

If more than one scanner needs to be configured, you can duplicate the settings

of the Master Scanner to the others. This is done by producing a set of custom

setup labels (derived from the master scanner) and then scanning these labels

to configure the other scanners. Selecting the Dump command in setup mode

or swiping the “Dump Setting” label below will dump the settings of the

reader to the screen as one or several ASCII string(s). Use any barcode

printing software, select Code 39 symbology, and use the output string(s) to

generate barcode labels. You can then scan these batch setup labels to

duplicate the settings.

Dump Setting

(Feel free to duplicate or photocopy)

Scanner Configuration Manager

Scanner Configuration Manager is a utility program to configure scanner

settings on a computer using the Windows 95/98 operating system. Use the

program to define the settings and then download the parameters to the

scanner. Download the program from our web site at www.unitech-adc.com.

Selectable Parameters and their Defaults

Parameters Selections Default

Keyboard Wedge

Device Selection IBM PC/AT, PS/2 mod 40, 60, 80 etc

IBM PS/2 Model 25, 56, 70, 90

Macintosh ADB bus

Keyboardless Wedge (Notebook)

IBM

PC/AT

RS232 Interface

Baud Rate 0-300; 1-600; 2-1200; 3-2400; 4-4800;

5-9600; 6-19200 9600

Parity 0-Even;1-Odd;2-Mark;3-Space;4-None None

Data bits 0-7 bits; 1-8 bits 8 bits

CTS/RTS 0-Ignore; 1-RTS Enabled at Power on; 2-

RTS Enabled in communication Ignore

ACK/NAK 0-Off; 1-On Off

BCC Character 0-Off; 1-On Off

Xon/Xoff Time out

0-1 sec; 1-3 sec; 2-10 sec; 3-Unlimited 1 sec

Beep Tone None/Low/Medium/High/Low to High/

High to Low Medium

Beep Tone

(On ACK) None/Low/Medium/High/Low to High/

High to Low High

Intercharacter delay

0 ms/1 ms/2 ms/5 ms/10 ms/30 ms/50

ms/100 ms 0 ms

Interblock delay 0 ms/10 ms/50 ms/100 ms/500 ms/1

second/3 second/5 second 0 ms

Function Code On/Off On

CapsLock Auto_trace/Low Case/Upper Case Auto_trace

Language US/UK/Swiss/Swedish/Spanish/

Norwegian/Italian/German/French/

Alt Key Mode/Danish

Double verification Off/1~7 On(Verify 1~7 times) Off

Label Type Positive /Positive and Negative Positive

Output of Wand Bar high, space low/

Bar low, space high Bar high,

space low

Level Duration 200 us/600 us 200 us

Terminator Enter/Return /Field Exit/None Enter

Code ID Disable/Enable Disable

Define Code ID 00-Code 39 Full ASCII

01-Code 39 Standard

02-EAN-13

03-UPC-A

04-EAN-8

05-UPC-E

06-I 2 of 5

07-Codabar

10-S 2 of 5

11-MSI

12-EAN 128

13-Code 32

14-Delta Code

15-Label Code

16-Plessey Code

17-Code 11

08-Code 128

09-Code 93 18-Toshiba Code

Data Length Exclude/ Include Exclude

Preamble Define up to 16 characters None

Postamble Define up to 16 characters None

Code 39 Disable/Enable Enable

Full ASCII/Standard Full ASCII

Check Digit Check and Send/ Check but

Not Send/ Not Check Not Check

Send/Not Send Start & Stop Not Send

Min 0 / Max 48 0 / 48

Interleaved 2 of 5

Disable/Enable Enable

Fix Length On/Off (by first three reads) Off

Check Digit Check and Send/ Check but

Not Send/ Not Check Not Check

First Digit Suppressed/ Last Digit Not

Suppressed/ Not Suppressed. Not

Suppressed

Min 4 / Max 64 10 / 64

Standard 2 of 5 /

Disable/Enable Disable

Toshiba Fix Length On/Off On

Check Digit Check and Send/ Check but

Not Send/ Not Check Not Check

Min 1 / Max 48 4/48

Code 32 Disable/Enable Disable

Leading Character Send / No Send Send

Tailing Character Send /No Send Send

Telepen Disable/Enable Disable

Standard/Numeric Set Standard

Disable/Enable Enable

UCC/EAN 128

Code ID Disable/Enable Disable

Code 128 / Disable/Enable Enable

Label Code Min 1 / Max 64 1 / 64

MSI / Plessey Disable/Enable Disable

Code CD Send / No Send No Send

CD Double Module 10/ CD Double

Module 11 Plus 10/CD single Module 10 CD Double

Module 10

Min 1 / Max 16 1 / 16

Code 93 Disable/Enable Enable

Min 1 / Max 48 1 / 48

Code 11 Disable/Enable Disable

One/Two CD Two CD

CD Send / No Send No Send

Min 1 / Max 48 1 / 48

Codebar Disable/Enable Disable

Start & Stop Send/No Send No Send

CD Calculate & Send/CD Calculate but no

Send/CD not Calculate CD not

Calculate

CLSI Format On/Off Off

Min 3 / Max 48 3 / 48

Disable/Enable Disable

Label Code IV

& V Checksum Send/No Send Send

UPC-ADisable/Enable Enable

Leading Digit Send / No Send Send

CD Send / No Send Send

UPC-EDisable/Enable Enable

Leading Digit Send / No Send Send

CD Send / No Send No Send

Zero Expansion On / Off Off

Disable/Enable NSC=1 Disable

EAN-13 Disable/Enable Enable

Leading Digit Send / No Send Send

CD Send / No Send Send

Bookland EAN Enable / Disable Disable

EAN-8Disable/Enable Enable

Leading Digit Send / No Send Send

CD Send / No Send Send

Supplement Code

Two Add-on Code Off / On Off

Five Add-on Code Off / On Off

Transmitted if Present/ Must Present

Must Present

Space Added / Not Added Not Added

Delta Distance Disable/Enable Disable

Code Check Digit Calculated / Not Calculated Calculated

Check Digit Send / No Send No Check

User’s Manual

MS140-2 or MS140I-2

RS232 Interface

Slot Reader

RS232 Interface Setup Label
