Unitech MS910 Manuel utilisateur

Confidential

Unitech Scanner User’s Manual 2011/5/20

1/20

MS910

Pocket Wireless Scanner

Quick Guide

Confidential

Unitech Scanner User’s Manual 2011/5/20

2/20

Overview

First of all, thank you for choosing Unitech’s products. This decoder build-in scanner comes in

one model and supports SPP , HID two modes of wireless communication.

The scanner supports the following bar code symbologies:

* All major 1D barcodes incl.

* GS1 DataBar

Confidential

Unitech Scanner User’s Manual 2011/5/20

3/20

Introduction：

：：

：

Charging the battery：

：：

：

1. Flip open the mini USB port on the scanner.

2. Insert the mini USB connector into the port on the scanner and USB A connector into a USB

port on the host PC.

Confidential

Unitech Scanner User’s Manual 2011/5/20

4/20

Beeper Indication：

：：

：

Type Definition

Single beep Good read

Single long beep Power up

Two beeps Wireless connection

Two short beeps The scanner successfully reads a configuration

barcode

Three short beeps The scanner reads a barcodes while

disconnected

Three beeps Wireless disconnection

Five beeps Low power

10 or 11 short beeps The scanner switches from one communication

mode to another

LED Indication：

：：

：

Type Definition

Off Standby or Power off

Flashing Green Disconnected or Discoverable

Green for 2 sec Good Read

Flashing Red Low power

Solid Red Charging

Confidential

Unitech Scanner User’s Manual 2011/5/20

5/20

Getting connected：

：：

：

I. Window PC

SPP mode

1. Press the trigger for 1 second to activate the scanner.

2. Scan “Disconnect”

3. Scan ”BT Mode - SPP” the scanner will emit 10 beeps.

4. Select “Wireless Scanner” from discovered device list. The default pincode is “1234”.

5. Open serial communication software with com port (see device manager) properly set up.

6. The scanner will beep twice to verify the connection.

HID mode

1. Press the trigger for 1 second to activate the scanner.

2. Scan “Disconnect”

3. Scan ”HID Mode - SPP” the scanner will emit 11 beeps.

4. Select “Wireless Scanner” from discovered device list.

5. The Bluetooth application may prompt you to scan a pincode (see PINCODE SETUP section) it

generated.

6. The scanner will beep twice to verify the connection.

Confidential

Unitech Scanner User’s Manual 2011/5/20

6/20

PinCode Start:

1. When asked by Bluetooth application to enter a pincode

2. Scan [Pincode-Start]

3. Scan the numeric barcodes according to the pincode generated by the Bluetooth application, and

then scan [Enter]

4. Scan [Pincode-Stop]

5. The scanner will beep twice to verify a successful connection.

Confidential

Unitech Scanner User’s Manual 2011/5/20

7/20

II. Windows Mobile

1. Press the trigger for 1 second to activate the scanner.

2. Scan “Disconnect”

3. Scan ”HID Mode - SPP” the scanner will emit 11 beeps.

4. PDA choiceSettingBluetoothWireless Scanner

Confidential

Unitech Scanner User’s Manual 2011/5/20

8/20

5. Input any digit as pincode, e.g.555

6. Scanner need to set pincode within 10 sec. in “Pincode Start” section. (Page 6)

Confidential

Unitech Scanner User’s Manual 2011/5/20

9/20

7. The scanner will beep twice to verify a successful connection.

Confidential

Unitech Scanner User’s Manual 2011/5/20

10/20

III. Android OS

1. Download BluetoothConnect.apk onto your mobile device and install it.

2. Once you enter the BluetoothConnect, the application may ask you to enable Bluetooth

connection, and then click [Yes].

3. Click the Menu button to enable the settings menu.
