Ubiquiti Bullet Manuel utilisateur
2
2
English
Deutsch
Español
Français
Italiano
Models:
Bullet/Pico/Loco/NanoStation
1
English
English
Typical Deployment
LAN or Computer to
Ethernet Port labeled
LAN on PoE Adapter
Ethernet Port on Ubiquiti
Device to Ethernet Port labeled
POE on PoE Adapter
Connect the Power Cord to the
PoE Adapter and a power outlet
Note: Shielded Category 5 (or above) cabling should be
used for all wired Ethernet connections and should be
grounded through the AC ground of the PoE.
2
Quick Reference Guide
Accessing AirOS
1. Make sure that your host machine is connected via Ethernet to
the Ubiquiti Networks device (as shown on previous page).
2. Configure the Ethernet adapter on your host system with a
static IP address on the 192.168.1.x subnet (e.g. 192.168.1.100).
3. Launch your Web browser and type http://192.168.1.20 in the
address field and press enter (PC) or return (Mac).
4. Enter ubnt in the Username and Password fields. Select your
country from the Select Your Country drop-down. To use the
product you must agree to the terms of use. To do so, click
I agree to these terms of use. Click Login.
5. The AirOS Interface will appear allowing you to customize your
settings as needed.
3
English
Ubiquiti Networks Wiki and Forum
Ubiquiti Networks has an online Wiki with Manuals, Guides, and
Information. It is located at www.ubnt.com/wiki.
Another great resource is the Ubiquiti Networks Forum. You can
post and view comments, questions, and answers with other
forum members and Ubiquiti staff at www.ubnt.com/forum.
4
Quick Reference Guide
Installer Compliance Responsibility
Devices must be professionally installed and it is the professional
installer's responsibility to make sure the device is operated within
local country regulatory requirements.
Country Code
Since Ubiquiti Networks equipment can be paired with a variety
of antennas and cables, the Antenna Gain, Cable Loss, and Output
Power fields are provided to the professional installer to assist in
meeting regulatory requirements.
The country that the product is being used in should be selected
from the Country Codes drop-down.
5
English
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the
manufacturer.
WARNING: Do not use this product in location that can be
submerged by water.
WARNING: Avoid using this product during an electrical
storm. There may be a remote risk of electric shock from
lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and
current requirements indicated on the manufacturer’s label.
Connection to a different power source than those specified
may result in improper operation, damage to the equipment
or pose a fire hazard if the limitations are not followed.
2. There are no operator serviceable parts inside this equipment.
Service should be provided only by a qualified service
technician.
3. This equipment is provided with a detachable power cord
which has an integral safety ground wire intended for
connection to a grounded safety outlet.
a. Do not substitute the power cord with one that is not the
provided approved type. Never use an adapter plug to
connect to a 2-wire outlet as this will defeat the continuity
of the grounding wire.
b. The equipment requires the use of the ground wire as a
part of the safety certification, modification or misuse can
provide a shock hazard that can result in serious injury or
death.
c. Contact a qualified electrician or the manufacturer if there
are questions about the installation prior to connecting the
equipment.
6
Quick Reference Guide
General Warranty
UBIQUITI NETWORKS, Inc (“UBIQUITI NETWORKS”) represents and warrants that the
Products furnished hereunder shall be free from defects in material and workmanship
for a period of one (1) year from the date of shipment by UBIQUITI NETWORKS
under normal use and operation. UBIQUITI NETWORKS sole and exclusive obligation
under the foregoing warranty shall be to repair or replace, at its option, any
defective Product that fails during the warranty period. The expense of removal and
reinstallation of any item is not included in this warranty.
The foregoing warranty is exclusive and in lieu of all other warranties, express
or implied, including the implied warranties of merchantability and fitness for a
particular purpose and any warranties arising from a course of dealing, usage or trade
practice with respect to the products. Repair or replacement in the manner provided
herein shall be the sole and exclusive remedy of Buyer for breach of warranty and
shall constitute fulfillment of all liabilities of UBIQUITI NETWORKS with respect to
the quality and performance of the Products. UBIQUITI NETWORKS reserves the
right to inspect all defective Products (which must be returned by Buyer to UBIQUITI
NETWORKS factory freight prepaid).
No Products will be accepted for replacement or repair without obtaining a Return
Materials Authorization (RMA) number from UBIQUITI NETWORKS. Products returned
without an RMA number will not be processed and will be returned to Buyer freight
collect. UBIQUITI NETWORKS shall have no obligation to make repairs or replacement
necessitated by catastrophe, fault, negligence, misuse, abuse, or accident by Buyer,
Buyer’s customers or any other parties. The warranty period of any repaired or
replaced. Product shall not extend beyond its original term.
Warranty Conditions
The foregoing warranty shall apply only if:
(I) The Product has not been subjected to misuse, neglect or unusual physical,
electrical or electromagnetic stress, or some other type of accident.
(II) No modification, alteration or addition has been made to the Product by
persons other than UBIQUITI NETWORKS or UBIQUITI NETWORK’S authorized
representatives or otherwise approved by UBIQUITI NETWORKS.
(III) The Product has been properly installed and used at all times in accordance,
and in all material respects, with the applicable Product documentation.
(IV) All Ethernet cabling runs use CAT5 (or above) shielded cabling.
Disclaimer: UBIQUITI NETWORKS does not warrant that the operation of the products
is error-free or that operation will be uninterrupted. In no event shall UBIQUITI
NETWORKS be responsible for damages or claims of any nature or description
relating to system performance, including coverage, buyer’s selection of products
for buyer’s application and/or failure of products to meet government or regulatory
requirements.
Returns
In the unlikely event a defect occurs, please work through the dealer or distributor
from which this product was purchased.
7
Deutsch
Deutsch
Typische Anwendungsbereiche
Verbinden Sie das LAN oder den
Computer mit dem Ethernet-Port
mit der Beschriftung „LAN“ am
PoE-Adapter.
Verbinden Sie den Ethernet-Port des
Ubiquiti-Geräts mit dem Ethernet-Port mit
der Beschriftung „POE“ am PoE-Adapter.
Schließen Sie das Netzkabel an den
PoE-Adapter und an eine Steckdose an
Hinweis: Für alle kabelgebundenen Ethernet-Verbindungen
sollten Kabel der Güteklasse 5 (oder höher) verwendet und
über den PoE-Adapter geerdet werden.
8
Kurzanleitung
Zugriff auf das AirOS
1. Verbinden Sie den Host-Computer über Ethernet mit dem
Gerät von Ubiquiti Networks (wie auf der vorangegangenen
Seite dargestellt).
2. Konfigurieren Sie den Ethernet-Adapter des Host-Systems mit
einer statischen IP-Adresse im Subnetz 192.168.1.x
(z.B. 192.168.1.100).
3. Starten Sie Ihren Webbrowser, geben Sie in die Adresszeile
„http://192.168.1.20“ ein und drücken Sie die Eingabetaste.
4. Geben Sie unter „Username“ (Benutzername) und „Password“
(Passwort) den Wert „ubnt“ ein. Wählen Sie in der Dropdown-
Liste Ihr Land aus. Sie dürfen das Produkt nur verwenden,
wenn Sie den Nutzungsbedingungen zustimmen. Klicken
Sie dazu auf „I agree to these terms of use“ (Ich stimme den
Nutzungsbedingungen zu). Klicken Sie auf „Login“ (Anmelden).
5. Nehmen Sie die gewünschten Einstellungen auf der AirOS-
Benutzeroberfläche vor.
