1 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

DVW32G6 Advanced Wireless Voice

Gateway - Safety and Installation

Product Insert

Federal Communications Commission

(FCC) Interference Statement

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable

protection against harmful interference in a

residential installation. This equipment generates,

uses and can radiate radio frequency energy and,

if not installed and used in accordance with the

instructions, may cause harmful interference to

radio communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does

cause harmful interference to radio or television

reception, which can be determined by turning

the equipment off and on, the user is encouraged

to try to correct the interference by one of the

following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the

equipment and receiver.

•Connect the equipment into an outlet on a

circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced

radio/TV technician for help.

FCC Regulatory Information

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired operation.

There is one statement for this product:

•Only the type of PCB antenna tested may be

Ubee Interactive — www.ubeeinteractive.com

2 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

used.

Devices will not permit operations on channels

120-132 for 11a and 11n/a which overlap the

5600 - 5650 MHz band.

FCC Caution: Any changes or modifications not

expressly approved by the party responsible for

compliance could void the user's authority to

operate this equipment.

For product available in the USA/Canada market,

only channel 1 ~ 11 can be operated. Selection

of other channels is not possible.

For operation within 5.15 ~ 5.25GHz / 5.47

~5.725GHz frequency range, it is restricted to

indoor environment.

FCC Radiation Exposure Statement:

This device complies with FCC radiation

exposure limits set forth for an uncontrolled

environment. This device should be installed and

operated at a minimum distance of 28cm

between itself and your body.

This device and it's antennas(s) must not be

co-located or operating in conjunction with any

other antenna or transmitter except in

accordance with FCC multi-transmitter product

procedures.

Safety Notices

Read these instructions carefully before

operating the device. It is important to be aware

of these safety instructions. Install the device

according to these instructions and keep this

guide for future reference.

1. Do not use this device in a humid space, in

the rain, or near splashing water.

2. Do not install during thunder or lightning

storms.

3. Do not cover any ventilation openings in the

device case.

4. Do not place the device near heat sources

such as radiators or stoves.

Ubee Interactive — www.ubeeinteractive.com

3 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

5. Clean the device only with a clean, dry cloth.

Do not use liquid or chemical cleaners.

6. Avoid static discharge when touching the

device by first touching the coaxial connector

of the coaxial cable.

7. Installation of the device should include

grounding the coaxial cable to the earth at the

building entrance per ANSI/NFPA 70 and the

National Electrical Code (NEC, in particular,

Section 820.93, Grounding of the Outer

Conductive Shield of a Coaxial Cable). The

device is designed for IT power systems with

phase-to-phase voltage at 110V.

8. Disconnecting the Device: If the device

becomes damaged or encounters some other

abnormality, disconnect the power plug from

the AC wall outlet immediately.

9. The device should be installed in a location

not to exceed the maximum temperature of

40 degrees Celsius (104 degrees

Fahrenheit).

10.This device MUST be placed upright for best

WiFi coverage

with the aid of the stand, the

stand must be fixed at a 90-degree angle to

the device. Otherwise, the device will have

the risk of tipping over.

11.Keep the device away from Children and

Pets.

12.Place the device on a cool surface. Failure to

do so may result in overheating which can

cause extreme damage.

13.Do not modify or attempt to disassemble the

device. Use it only according to the

instructions.

14.Do not dispose of the device in a trash

container. Please recycle.

Ubee Interactive — www.ubeeinteractive.com

4 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

Installation

To install this device, follow the procedures

below and refer to the following page for a

connection diagram.

1. Connect one end of a coaxial cable (not

included) to the CABLE port on the device.

Connect the other end to a cable splitter or the

cable wall outlet. Be sure not to bend or over

tighten the cables as this may strain the

connector and cause damage. If you plan to

connect the device and a television to the

same cable wall outlet, you must use a cable

line splitter (not included).

2. Connect one end of the supplied Ethernet

cable to one of the ETHERNET ports (ETH1

to ETH4) on the device. Connect the other

end to the ETHERNET port on a PC. Note:

Category 5e or Category 6 Ethernet cables

with RJ-45 connectors must be used when

connecting Ethernet devices to the LAN ports.

This ensures Gigabit Ethernet speeds (unless

the computer does not support it).

3. Connect one end of an RJ-11 phone cable to

one of the TEL ports on the device (a port that

has been provisioned for voice service as

specified by the service provider). Connect the

other end to the phone port of the telephone.

Note: If voice service is not provisioned

through the service provider, telephone

service is not available.

4. Connect the power cord to the POWER port

on the device. Plug the other end of the power

cord into the AC wall outlet. Important: Use

only the power cord that is shipped with the

device.

Ubee Interactive — www.ubeeinteractive.com

5 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

Wall-Mount Installation

You can mount the device on a wall using the 2

mounting brackets on the bottom of the device.

We recommend that you use two round or pan

head screws.

1. Install two screws horizontally apart on a wall

using the measurement shown to the right.

The screws should protrude from the wall so

that you can fit the device between the head

of the screw and the wall. If you install the

screws in drywall, use hollow wall anchors to

ensure that the unit does not pull away from

the wall due to prolonged strain from the cable

and power connectors.

2. Remove the device from the product package.

3. Mount the device on the wall.

4. Refer to the following figure.

The Distance of the Pothook (Horizontal)

The Screw’s Size (mm)

6.65+/-0.35

1.9+/-0.15

19.0+/1.20

Ubee Interactive — www.ubeeinteractive.com

6 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

Additional Information

1. RESET Button (back of device): This button

resets the device to factory defaults. Using a

pointed object, insert it into the button opening,

and hold for more than 10 seconds. The

device will reset and reboot. Note: Not all

parameters are reset to factory defaults. Refer

to the User Guide for more information.

2. Battery (bottom of device): A slot is provided

that houses the battery and can be

opened/closed for battery insertion or

replacement.

3. WPS button (top of device): The WPS button

is used for the Wi-Fi Protected Setup (WPS)

method to connect a Wi-Fi device to the

DEVICE. Refer to the User Manual for more

information.

LEDs and Other Device Indicators

See the following diagram and descriptions of the

device’s LED behavior, and the behavior of the

back-panel Ethernet indicators.

LED Indicators (Color = Blue When On):

Power—If On, indicates that

the device has successfully

completed internal power-on

tests. LED flashes if power-on

fails or if the device is

operating on battery. Note

that the LED flashes briefly

immediately after powering

the device.

DS/US—When the device

initializes, the LED flashes.

When the device locks on to

channels and registers OK, the

LED is On. When the device

performs a firmware upgrade,

the LED flashes.

Ubee Interactive — www.ubeeinteractive.com

7 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

ONLINE—When the device is obtaining an IP

address and configuration file, the LED flashes.

When device obtains these items, the LED is On.

2.4G—When 2.4G Wi-Fi is enabled, the LED is

On. When 2.4G Wi-Fi is disabled, the LED is Off.

5G—

When 5G Wi-Fi is enabled, the LED is

On. When 5G Wi-Fi is disabled, the LED is

Off.

Tel 1/Tel 2—The LED is On when a telephone is

on-hook. The LED flashes when a telephone is

off-hook.

MoCA— When MoCA is enabled, the LED is On.

When MoCA is disabled, the LED is Off.

When passing MoCA network traffic, the LED is

flashing.

Battery—LED is On when the battery is installed

and charged. LED is Off if no battery is installed.

If the battery is at low power level (30mins left),

the battery LED will flash.

WPS (top of device)—If not used, the LED is Off.

When the user pushes the WPS button or

triggers WPS via the device’s web GUI, the LED

flashes white for 4 minutes until a PIN is entered

from a wireless client that wishes to connect.

After a Wi-Fi client attaches successfully, the

LED remains solid white for 5 minutes, and then

turns off.

Ubee Interactive — www.ubeeinteractive.com

8 Ubee DVW32G6 – Safety and Installation Product Insert v1.0

Back Panel Ethernet Indicators

(Color = Orange or Green):

•When an Ethernet device, such as a computer,

is connected to the device, the LED is Orange

when connected at 10/100 Mbps speeds.

•When an Ethernet device, such as a computer,

is connected to the device, the LED is Green

when connected at 1000 Mbps speeds

(Gigabit Ethernet).

•When data is being passed between the

device and the connected device, the LED

flashes.

Table des matières

Autres manuels Ubee Porte

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
