Tyan

S1832DL

Tiger 100

Motherboard User’s Manual

Revision 2.20

manual may be reproduced or translated without prior written consent from Tyan

Computer Corp.

All registered and unregistered trademarks and company names contained in this

manual are property of their respective companies including, but not limited to the

following.

AMI BIOS is a trademark of American Megatrend Incorporated.

Windows is a trademark of Microsoft Corporation.

IBM, PC, AT, PS/2 are trademarks of IBM Corporation.

INTEL, Pentium II, Pentium III, Celeron, Xeon are trademarks of Intel Corporation.

S1832 Tiger 100 is a trademark of TYAN Computer Corporation.

Information contained in this publication has been carefully checked for accuracy and

reliability. In no event will Tyan Computer be held liable for any direct or indirect,

incidental or consequential damage, loss of use, loss of data, or other malady resulting

from errors or inaccuracies of information contained in this manual. The information

contained in this document is subject to change without notice.

PRINTED IN USA.

Table of Contents

1. Introduction.......................................................................4

Overview..................................................................... 4

Icons........................................................................... 5

Hardware Specifications/Features................................. 6

Software Specifications.................................................7

Technical Support......................................................... 8

Returning Merchandise for Service................................ 8

2. Board Installation..............................................................10

Unpacking....................................................................10

Precautions.................................................................. 10

Installation Steps...........................................................11

What is a Jumper.......................................................... 12

Map of Motherboard Jumpers....................................... 13

Picture of Motherboard Features................................... 14

Setting Jumpers............................................................ 15

Mounting the Motherboard in the Chassis....................... 19

Installing Memory......................................................... 19

Installing the CPU & Cooling Fan.................................. 23

Connecting IDE & Floppy Drives.................................. 30

Connecting the Power Supply........................................ 32

Installing Add-on Cards................................................ 33

Connecting PS/2, Serial, Parallel & USB Devices.......... 34

Frequently Asked Questions.......................................... 35

3. BIOS Configuration...........................................................38

Main Setup...................................................................39

Advanced CMOS Setup................................................44

Chipset Setup............................................................... 49

Power Management Setup............................................ 55

Plug and Play Setup..................................................... 59

Peripheral Setup........................................................... 64

Supervisor and User Security.........................................68

Language Utility........................................................... 69

Flash Writer Utility........................................................ 69

4. System Resources.............................................................70

Beep Codes................................................................. 70

Troubleshooting System Problems.................................. 71

Displayed Error Messages............................................ 72

Appendix 1 - CPU Retention Module Options.....................74

Appendix 2 - Glossary........................................................... 76

http://www.tyan.com

Chapter 1

Introduction

Overview

The S1832DL Tiger 100 is a quality, high performance mainboard designed for

dual Intel Pentium II or Pentium III microprocessors. This mainboard utilizes

the Intel 440BX AGPset and can support CPU speeds of 233MHz through

500MHz, and host bus speeds of 66MHz to 100MHz.

TheS1832DLmainboard,withbuilt-inAGPslot,provideshighperformance

capabilities that are ideal for a wide range of demanding applications such as

CAD, CAM, CAE, desktop publishing, 3D animation, and video production.

This integrated system board achieves high reliability with numerous features

and yet is small enough to be supported in an ATX form factor. Some of the

features included are onboard dual channel PCI PIO, Bus Master IDE and

UltraDMA/33, onboard floppy controller, and onboard high speed I/O.

Flexibility and expandability have been designed into the Tiger 100. With I/O

and drive controller support built onboard, the one AGP slot, five PCI and two

ISA slots (one shared, seven usable slots) are free for numerous add-on

expansion cards.

Remember to take a look at TYAN Computer’s web site located at

chapter 1

Introduction

S1832DL Tiger 100

INTRO

http://www.tyan.com. There you can find information on all of TYAN’s

products along with detailed FAQs for trouble-shooting, distributors list,

drivers, and BIOS setting explanations.

Icons

In order to help you navigate this manual and set up your system, we have

added several icons to our format.

This icon alerts you to particularly important details regarding

the setup or maintenance of your system. This icon often

appears next to information that may keep you from damaging

your board or system. While we will often point out the most

vital paragraphs in a chapter, you should always read every word in the text.

Failing to do so can lead to exasperation and expense.

Wherever possible, we have included step-by-step instructions

for setting up your system, which are indicated by this icon.

However, it is in your best interest to read an entire section (and

perhaps the entire manual) before you begin to fiddle with your

motherboard.

While we have alerted you to potential dangers in several places

in the manual with this icon, these warnings should not be

regarded as the whole of your safety regimen. Never forget that

computers are electrical devices, and are capable of delivering a

shock. Prevent damage to yourself and to your board: always ensure that your

system is turned off and unplugged whenever you are working with it, and that

you are equipped with a static safety device.

important!

procedure

warning

http://www.tyan.com

Chapter 1

Introduction

Hardware Specifications/Features

Processor Information •Two SEC slots (Slot One type).

•66to100MHzBIOSselectablebus

support.

•PentiumII,P-III233-500MHz.

•Supports Celeron CPU (single only).

Chipset Information •Intel440BXAGPset.

•IntelPIIX4e controller.

•National 309 Super I/O chipset.

Voltage and Power •ATX power supply connector.

Information •+12V power source for DC fans

onboard.

•3.3VDRAM support.

•Utilizes GTL+ bus to reduce power

consumption and EMI.

Main Memory •Up to 1024MB onboard.

•Four 168-pin DIMM sockets.

•Supports100MHz SDRAM with

SPD.

System Management •NationalLM79 and LM75

ASICs with onboard alarm for

monitoring temperature, supply

voltages, and fan speed.

•System Manager software

•Chassis intrusion detection capable.

Expansion Slots •One32-bit AGPslot.

•Five 32-bit PCI Bus Master slots.

•Two 16-bit ISA slots.

•One shared, seven usable slots.

S1832DL Tiger 100

INTRO

Physical Dimensions •ATX design.

•12inchesx 9.8 inches.

•Requires Intel Venus compatible I/O

shield.

BIOS Information •AMI Plug and Play flash BIOS.

•DeepGreen, EnergyStar, ACPI,

Year2000,and PC98compliant.

•Soft power-down, multiple boot

options.

•Win98/NT5ready, DMI 2.0

compliant.

•PCI2.1,APM 1.1compliant.

Disk Drive & System I/O •Two PCIbus mastering EIDE

channels.

•SupportsEIDE CD-ROMs.

•PIO Mode 3 & 4 (up to 17MB/sec

DTR).

•UltraDMA/33 bus mastering mode

(up to 33MB/sec DTR).

•Support for two floppy drives (up to

2.88MB).

•Two serialports (16550 UARTs).

•OneECP/EPP parallelport.

•OneSerial IR (InfraRed) I/O interface port.

•Two USB rev1.2 (universal serial

bus) connectors.

•One PS/2 mouse connector.

•One PS/2 keyboard connector.

Software Specifications

OS •Operates with MS-DOS, Windows

3.x,Windowsfor WorkGroups3.x,

Windows 95, Windows 98, Windows

NT,OS/2, NovellNetware, andSCO Unix.

http://www.tyan.com

Chapter 1

Introduction

Technical Support

If a problem arises with your system, you should turn to your dealer for help

first. Your system has most likely been configured by them, and they should

have the best idea of what hardware and software your system contains.

Hence, they should be of the most assistance. Further, if you purchased your

system from a dealer near to you, you can actually bring your system in to

them to have it serviced, instead of attempting to do so yourself (which can

have expensive consequences).

If your dealer is unable to assist you,

1) try our web page: http://www.tyan.com

2) technical support phone line: (510) 440-8808

3) or e-mail address: [email protected]

Returning Merchandise for Service

During the warranty period, contact your distributor or system vendor FIRST

for any product problems. This warranty only covers normal customer use and

does not cover damages incurred during shipping or failure due to the

alteration, misuse, abuse, or improper maintenance of products.

For Resellers Only:

A receipt or copy of your invoice marked with the date of purchase is required

before any warranty service can be rendered. You can obtain service by calling

the manufacturer for a Return Merchandise Authorization (RMA) number. The

RMA number should be prominently displayed on the outside of the shipping

carton and the package should be mailed prepaid, or hand-carried to the

manufacturer. TYAN will pay to have the board shipped back to you.

S1832DL Tiger 100

INTRO

This page intentionally left blank.

http://www.tyan.com

Chapter 2

oard Installation

chapter 2

Board Installation

important!

Unpacking

The mainboard package should contain the following:

•S1832DLmainboard

•One 40-pin IDE & 34-pin floppy cable pack

•User’s manual

•Two CPU retention modules

•One Tyan System Management & Driver CD

Precautions

What’sthe firstthingIshoulddo?

The first thing you should do is read this user’s manual. It contains important

information which will make configuration and setup much easier.

Here are some precautions you should follow when installing your

motherboard:

(1) Groundyourselfproperlybeforeremovingyourmotherboard

fromthe antistatic bag. Unplug the power from your computer

and then touch any metal part on the computer case. (Or wear a

grounded wrist strap.)

(2) Holdthemotherboardbyitsedgesanddonottouchthebottomof

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels TYAN Carte mère

TYAN

TYAN THUNDER K7 Instructions d'installation et d'utilisation

TYAN

TYAN S4992 Manuel utilisateur

TYAN

TYAN TAHOE 2 ATX Manuel utilisateur

TYAN

TYAN S1837 Manuel utilisateur

TYAN

TYAN S2932-E Manuel utilisateur

TYAN

TYAN Tiger K8WE Manuel utilisateur

TYAN

TYAN THUNDER K7 Manuel utilisateur

TYAN

TYAN S2505T Instructions d'installation et d'utilisation

TYAN

TYAN S5545 Manuel utilisateur

TYAN

TYAN S5501 Manuel d'exploitation et d'entretien

TYAN

TYAN TRINITY I7205 Manuel utilisateur

TYAN

TYAN S8030 Manuel utilisateur

TYAN

TYAN TOLEDO I3010W Manuel utilisateur

TYAN

TYAN TOMCAT I845 Manuel utilisateur

TYAN

TYAN S8026 Manuel utilisateur

TYAN

TYAN TOLEDO I3000R Manuel utilisateur

TYAN

TYAN Tomcat i945GM S3095 Manuel utilisateur

TYAN

TYAN S5547 Manuel utilisateur

TYAN

TYAN TOMCAT K8E Manuel utilisateur

TYAN

TYAN THUNDER K8QSD PRO Manuel utilisateur

TYAN

TYAN Thunder K8S Pro Manuel utilisateur

TYAN

TYAN THUNDER N3600B Manuel utilisateur

TYAN

TYAN S1846 Tsunami ATX Manuel utilisateur

TYAN

TYAN THUNDER I7525 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
