TScale ROW Series Manuel utilisateur

ROW series

Precision Balance

User sguide

UGROW-E1.01

ROWserialprecision balance user smanual

TableofContents

SECTION1INTRODUCTION……………………………………………………………1

SECTION2SPECIFICATIONS……………………………………………………..……2

SECTION3INSTALLATION……………………………………………………………….3

SECTION4KEYDESCRIPTIONS………………………………………………………5

SECTION5DISPLAYS…………………………………………………………………….6

SECTION6OPERATION…………………….……………………………………….…..7

6.1Zeroingthe display………………………………………………………………….7

6.2Taring……………………………………………………………………………..…….7

6.3Weighingasample…….………………………………………………….………….7

6.4Check-weighing…………………………………………………………………….8

6.5Accumulated total……………………………………………………………………….9

SECTION7PARAMETERS………………………………………………………………10

SECTION8BATTERYOPERATION………………………………………………..…13

SECTION9RS-232 OUTPUT…………………………………………………………..14

SECTION10CALIBRATION……………………………………………………..……..16

SECTION11ERRORCODE…………………………………………………………17

SECTION12 TECHNICALPARAMETES…………………………………………….18

ROWserialprecision balance user smanual

SECTION 1INTRODUCTION

TheROWseriesofprecision balanceprovidesan accurate,fastand versatileseries

ofgeneralpurposeweighingscalewithunitsconversion andcheck-weighing

functions.

All the keypadsaresealed,colorcoded membrane switchesandthe displaysare

largeeasytoread liquidcrystaltype displays (LCD).The LCDsaresupplied witha

backlight.

All unitsincludeautomaticzerotracking,unitsconversion ,audiblealarmforpre-set

weights,andan accumulation facilitythatallowsthe individualweightstobe stored

and recalled asanaccumulatedtotal.

-1-

ROWserialprecision balance user smanual

SECTION 2SPECIFICATIONS

Model ROW

Resolution 1/70,000

Interface RS-232 Output Optional

StabilisationTime 1 Secondstypical

OperatingTemperature0°C-40°C/ 32°F-104°F

Powersupply(external) 115 / 230 Vac,120/ 240 Vac, 50/60Hz, 10 watts

Calibration AutomaticExternal

Display 6digits22mmLCD display, attachedbacklight

indicatorHousing ABS Plastic,

Zerorange 0mV~5mV

Signalinputrange 0~15mV

ADC Sigmadelta

Internalcounts 600,000

ADC update Max60 times/second

Loadcell drivevoltage Max5V/150mA

Loadcells Uptofour350 ohmscells

-2-

ROWserialprecision balance user smanual

SECTION 3INSTALLATION

GENERAL INSTALLATION

Thescalesshouldbe sited inalocationthat will not degrade the accuracy.

Avoidextremesoftemperature. Donot placeindirect sunlight ornearair conditioning

vents.

Avoidunsuitabletables.Thetablesorfloormustberigidand notvibrate.Donot

placenearvibratingmachinery.

Avoidunstablepowersources.Donotusenearlargeusersofelectricitysuchas

weldingequipmentorlargemotors.

Avoidhighhumiditythatmightcausecondensation.Avoiddirectcontactwithwater.

Donotsprayorimmersethescalesinwater.

Avoidair movementsuchasfromfansoropeningdoors.Donotplacenearopen

windows.

Keeptheindicatorclean.

Donotstack materialonthescaleswhen theyarenot inuse.

INSTALLATIONOFROWSERIES

Pleasemakethe loadcell connectorfromtheload cell followthe drawingbelow

Attachthe ACpoweradaptertotheconnectoron theback of theindicator.

If you useROWforaplatformscale,youcan useattachedindicatorbracket,this

indicatorbracketisdesignfor38mmpole.

Loadcell connect asbelow(5pinair connecter)

-3-

EXC+

SEN+

SEN-

EXC-

SIG+

SIG-

SHIELD

LOAD CELL

ROWserialprecision balance user smanual

SECTION 4KEYDESCRIPTIONS

Zero

Set the zeropointforall subsequent weighing.Thedisplayshowszero.

Asecondaryfunction , of"Enter"keywhen settingparametersorotherfunctions.

Tare

Taresthescale.Storesthe currentweightinmemoryasatarevalue,subtractsthe

tarevalue fromtheweightandshowsthe results.Thisisthenetweight. Enteringa

value usingthekeypad willstorethat value asthe tarevalue.

Asecondaryfunction ,ofincrementingtheactivedigitwhen settingavaluefor

parametersorotherfunctions.

G/N

Press thekey,thescalecantoselectgrossweightornetweightafteryou tarea

weight.

Secondaryfunction ,Inthesettingmode,thiskeyusedtomoveactivedigits

right.

M+

ToprinttheresultstoaPCorprinterusingtheoptionalRS-232interface.Italso

addsthe value totheaccumulation memoryifthe accumulation functionisnot

automatic.

Secondaryfunction( Cor ),istoactasaclearkeyortomoveactivedigits

left when settingvaluesforparametersorotherfunctions.

UNITor U

Press thiskeytoselectthe weightunit. Movethe activedigitleft when settingvalues

forotherfunctions.

Secondaryfunction (ESC) ,istoreturntonormaloperation whenthe scaleisina

parametersettingmode.

ON/ OFF

Turnon oroffthepower.

-4-

ROWserialprecision balance user smanual

SECTION 5DISPLAYS

TheLCD displaywill showavalue andaunittothe right of thedigits.

InadditiontherearelabelsforTARE, GROSS weight, ZeroandforLowbattery

-5-

Batterylow

stable

heckweighing

Weighing unit

ROWserialprecision balance user smanual

SECTION 6OPERATION

6.1ZeroingTheDispla

You canpressthe ZERO keyatanytimetosetthezeropointfromwhichall other

weighingand counting ismeasured,within4%ofpowerup zero.Thiswill usually

onlybe necessarywhen theplatformisempty.Whenthe zeropointisobtained the

displaywill showthe indicatorforzero.

Thescalehasanautomaticrezeroingfunctiontoaccountforminordriftingor

accumulationof materialon the platform.Howeveryou mayneed topress the ZERO

keytorezerothe scaleifsmall amountsofweightareshownwhen theplatformis

empty.

6.2Taring

Zerothescalebypressingthe ZERO keyifnecessary.The zeroindicatorwill be on.

Placeacontainerontheplatform,avalue foritsweight will be displayed.

Press the TARE keytotarethe scale.Theweightthatwasdisplayedisstored asthe

tarevalue andthatvalue issubtractedfromthe display,leavingzeroon thedisplay.

The"TARE"indicatorwill be on.Asproductisaddedonlythe weightoftheproduct

will be shown.Thescalecouldbetaredasecondtimeifanothertype ofproductwas

tobe added tothefirstone.Againonlythe weightthatisaddedaftertaringwill be

displayed.

When thecontainerisremoved anegativevalue will be shown.If thescalewastared

justbeforeremovingthe containerthisvalueisthegross weightofthecontainerplus

all productthatwasremoved.Thezeroindicatorwill alsobe onbecausethe platform

isback tothesameconditionit waswhen the ZERO keywaslast pressed.

6.3Weighingasample

Todeterminethe weightofasamplefirsttaretheemptycontainerthenplacethe

sampleinthe container.the displaywill showthe weightand the unitsofweight

currentlyinuse.

6.4Check-Weighing

6.4.1About check-weighing

Check-weighingisaproceduretocauseanalarmtosoundwhen the weighton the

scalemeetsorexceedsvaluesstoredinmemory.The memoryholdsvaluesfora

-6-

ROWserialprecision balance user smanual

highlimit andalowlimit.

Check mode2:

When check range,thedisplaywill showOK andthebeeperwillsoundwhen the

weight isbetween thelimits.

Check mode3:

When check range,thedisplaywill showOK andthebeeperwillsoundwhen the

weight isoutofthe limits.

6.4.2Set limits

Press the UNIT keyand M+ keytogetherintheweighingmode,itwill display “F0

H-L”, press ZERO keytoenter, use TARE keytoselect “SET HI”or “SET LO”, press

ZERO keytoenter,use G/N keytomoveactivedigit, use TARE keytochangevalue,

use UNIT keytoclearvalue.Afteryou enterthe value,press ZERO keytosure,

press UNIT keytoescape.

6.4.3Set check weighingmode

Press the UNIT keyand M+ keytogetherinthe weighingmodetoentersettingmode,

press TARE until displayshow “F3 OFF”,press ZERO keytoenter,press TARE key

until displayshow “BEEP”,press ZERO keytoenter,press TARE keytoselect BP

2(check mode2), BP3 (check mode 3), BP1(no beep),press ZERO keytosure,

press UNIT keytoescape.

6.4.4NOTE

Theweightmustbegreaterthan 20scaledivisionsforthe check-weighingto

operate.

TodisabletheCheck-Weighingfunctionenterzerointobothlimitsbypressingthe

UNIT keyand M+keytogetherinthe weighingmode,then the currentlimitsare

shown. thenset zeroand storethezerovalues.

6.5AccumulatedTotal

6.5.1Note

Thescalecan besettoaccumulatemanuallybypressingthe M+ key.Seethe

PARAMETERSSectionfordetailsofselecting the methodusingfunction "F5 P RT".

Theaccumulationfunction isonlyavailablewhen weighing.

Pleasenotebeforeeveryaccumulateoperate,scaleneedreturntozero,andonly

press M+ keywhen stable,when weightlessthan20d,accumulateoperatewill be

invalid.

6.5.2Accumulateoperate

Theweight displayed will be storedinmemorywhen the M+ keyispressed andthe

-7-

ROWserialprecision balance user smanual

weight isstable.

Thedisplaywill show"ACC 1"and thenthetotalinmemoryfor2secondsbefore

returningtonormal.(afterdoaccumulateoperate,M+ indicatorwill turnon)Ifthe

optionalRS-232 interfaceisinstalled theweight will be outputtoaprinterorPC.

Removethe weight, allowing the scaletoreturntozeroand putasecondweighton.

Press theM+ key, thedisplaywill show"ACC 2"andthenthenewtotal.

Continueuntil all weightshavebeen added.

*Note:afteryou changeweighingunit, accumulatevaluewill be clear.

6.5.3memoryrecall

Toviewthe totalsinmemorypress M+ keyinzeropoint (ZERO indicatoron).

6.5.4memoryclear

Toclearthe memory, just press UNITkey

6.5.5automaticallyaccumulate

Atfirst, you need setscaletoautoaccumulatemode,Press the UNIT keyand M+

keytogetherinthe weighingmode,itwill display “F0 H-L”,press TARE keyuntil

displayshow “f5 prt”, press ZERO keytoenter, press TARE keytoselect “pauto”,

press ZERO keytosure,thenyou needsetbaudrateand M+ format, printtype,see

detail inSECTION7

Afteryou set, AUTO indicatoron.

Press weightonplatform,afterstable,youwill hearbeepontwice,you canadd or

remoteweightnow,scalewill beep on againafterstable,atlast, removeall weighton

platform,thelast weight value will storeinmemory

6.6AnimalScales

ROWcan setasan animalscale,you justneed set P4 CHK to mode2,see detail in

SECTION12.

Lettheanimalonthe platform,aftersomesecond,ifreadingdatachangenotalot,

you can hearbeepsound and readingdatawill be locked.

Inreadingdatalock mode,ifyou add/removebigweight, displaywill still updateand

lock newreadingdata.

6.7subtration scale

Thisisusedforhopperscale, you needset autozerorangeto0(seedetail in

-8-
