Trust 11670 Manuel utilisateur

4 Port USB Hub

4 PORT USB HUB

User’s manual

Version 1.0

4 Port USB Hub

Thank you

Thank you very much for purchasing this product from the Trust range. We wish you

hours of fun with it. Please read this manual carefully before using the product.

Registration

win one of the fabulous prizes. The web site is also the place to look for dealer

addresses, comprehensive product information, drivers, and FAQs (Frequently Asked

Questions).

No part of this manual may be reproduced or transmitted, in any form or by any

means, electronic or mechanical, including photocopying, recording, or information

storage and retrieval systems, for any purpose other than the purchaser's personal

use, without the prior written permission of the manufacturer.

Disclaimer Statement

The manufacturer specifically disclaims all warranties, either express or implied,

including but not limited to implied warranties of merchantability and fitness for a

particular purpose, with respect to the software, the product manual(s) and written

materials, and any other accompanying hardware. The manufacturer reserves the

right to revise or make improvements to its product at any time and without obligation

to notify any person of such revisions or improvements.

In no event shall the manufacturer be liable for any consequential or incidental

damages, including any loss of business profits or any other commercial damages,

arising out of the use of its product.

All company or product names are trademarks or registered trademarks or service

marks of their respective owners.

01 UK 11670 4PORT.DOC

4 Port USB Hub

Table of Contents

1. Introduction ........................................................................................................2

1.1 Conventions in the Manual...........................................................................2

1.2 Content of the Packaging.............................................................................2

1.3 Minimum System Requirements ..................................................................2

2. Safety ..................................................................................................................3

2.1 General.........................................................................................................3

2.2 Adapters.......................................................................................................3

3. Connecting .........................................................................................................4

3.1 Description of the 4 Port USB Hub...............................................................4

3.2 Connecting the Power Supply Adapter ........................................................5

3.3 Connecting the USB Cable ..........................................................................5

3.4 Connecting Devices .....................................................................................5

3.5 Installing in Windows....................................................................................5

4. Troubleshooting.................................................................................................6

5. Specifications.....................................................................................................6

4 Port USB Hub

1. Introduction

This manual is intended for users of the 4 Port USB Hub. No specific prior knowledge

is needed to install and use this product.

If you have any questions after reading this manual, please contact one of the

Trust service centres. You will find information on the service centre nearest to

you at the back of this manual. You can also visit the Trust website

(www.trust.com) for support, comprehensive product information, drivers, and

FAQs (Frequently Asked Questions).

1.1 Conventions in the Manual

The following conventions have been used in this manual to indicate instructions:

Note: Do not short circuit the USB Hub ports. This can cause damage

1.2 Content of the Packaging

Check the contents of the packaging before reading the manual. You should find the

following items in it:

•4 Port USB Hub

•USB cable

•Power supply adapter

Please contact your dealer if anything is missing or damaged.

1.3 Minimum System Requirements

•Free USB port

•Windows 95 OSR2.x or Windows 98

•USB device

4 Port USB Hub

2. Safety

2.1 General

1. Do not use this equipment in damp environments such as bathrooms, damp

basements, swimming pools, etc.

2. Never insert objects into the openings on the outside of the device as you can

come into contact with live electrical components. This can cause fire or give

strong electrical shocks.

3. Do not try to repair the equipment yourself. If you open or remove the casing you

might accidentally come into contact with live components. You could also be

exposed to other risks.

4. You should disconnect the power supply and have the equipment repaired by

qualified personnel if:

a) the cable or the plug is damaged or worn;

b) the equipment has come into contact with fluids;

c) the equipment has been dropped and/or the casing has been damaged;

5. Position the device so that its cables cannot be damaged.

2.2 Adapters

1. Insert the adapter into a suitable outlet.

2. The adapter is intended for use in Europe.

3. Use the adapter only with the equipment it was supplied with. Never use a

different adapter with this equipment. Other uses, such as providing power for a

Walkman, can cause fire.

4 Port USB Hub

3. Connecting

Before using this device, it must be connected to your computer. Follow the

instructions below for doing this safely.

Note: Switch off your computer before connecting the USB Hub.

3.1 Description of the 4 Port USB Hub

Figure 1: Front side of the device

The LED A will light up once the power supply adapter has been connected to the

USB Hub. The other four LEDs (g) will also light up.

If an LED (B) is no longer lit, this means that the USB port is overloaded or short-

circuited.

LED On Off

A Power supply adapter is

connected

Power supply adapter is

not connected

B Port is ready for use or

already in use

Port is short circuited or

overloaded

Table 1 Overview of LED status

ABC

Figure 2: Back side of device

4 Port USB Hub

Function Description

A Upstream port (connection to computer)

B Downstream port (connection for USB device)

C Power supply adapter connection

Table 2 Overview of connections

3.2 Connecting the Power Supply Adapter

1. Insert the round power supply adapter plug into connection C (Figure 2) on the

USB Hub.

2. Insert the power supply adapter into the wall socket.

3.3 Connecting the USB Cable

In order to transmit data from the USB Hub to the computer, the USB cable provided

should be connected.

1. Connect the USB cable with the six-sided plug to connection A on the USB Hub

(Figure 2).

2. Connect the other end of the USB cable with the flat plug to a free USB

connection on your computer. (Figure 3)

Figure 3: Connecting to the computer

3.4 Connecting Devices

Use the cable provided with the product to connect these to the USB Hub. To do so,

refer to the manual supplied with the device. The devices should be connected to one

of the four USB connections (B) on the backside of this USB Hub

3.5 Installing in Windows

When starting up Microsoft Windows after the USB Hub has been connected,

Windows will detect new hardware (General Purpose USB Hub). A driver for this

device will be installed automatically.

4 Port USB Hub

4. Troubleshooting

Problem Cause Possible solution

New device is not

found

USB Hub is not

receiving power

Connect the power supply adapter to

the USB Hub

USB cable is not

connected properly

Connect the USB cable properly

between the computer and the Hub

‘General Purpose

USB Hub’ is not

detected

USB cable is not

connected properly

Connect the USB cable properly

between the computer and the Hub

USB Hub is not

receiving power

Connect the power supply adapter to

the USB Hub

USB support has not

been installed

(Windows 95)

Install the USB support. (this can be

found on the Windows CD-ROM or

on the Internet)

Check the Internet (www.trust.com) for the FAQs.

Please contact your dealer if you still have problems with the USB Hub after trying

these solutions.

More information on the USB can be found at www.usb.org on the Internet

5. Specifications

Upstream 1 B-type port

Downstream 4 A-type ports

Throughput Up to MB/s

LED 1 LED for power

4 LED for power to the A-type ports

Short circuit protection On every port

Output voltage and

current

5V DC / 500mA max per output

Power supply adapter 5V DC / 3.7A
