4.6 Interfaces on the system control 32
24 V supply voltage (DC) 32
Ethernet 33
RS-485 33
5 Standards and directives 34
5.1 CE certification 34
5.2 EU declaration of conformity TruCon-
vert DC 1008 / TruConvert DC 1010
35
5.3 EU declaration of conformity TruConvert Sys-
tem Control
36
5.4 CSA certification 37
Location of the CSA mark 37
6 Installation 38
6.1 Inspecting the delivery 38
6.2 Disposing of packaging material 38
6.3 Transport 38
6.4 Storage conditions 38
6.5 Requirements for the site 39
6.6 Possible installation positions 40
6.7 Electrical connection 41
Establishing electrical connection 42
Using ferrite core to achieve the limit
value for level C1
44
Connection diagram with 3 DC-DC mod-
ules (example)
46
6.8 Dismantling the DC-DC module 46
6.9 Shipping the module 47
6.10 Disposing of the module 47
7 Operation 48
7.1 Commissioning 48
Performing initial commissioning 48
7.2 Active interface 53
7.3 Operation via web-based user interface 53
Calling up the web GUI 53
Orientation of the user interface 54
Menu structure 57
7.4 Operation via Modbus 58
Establishing a connection 58
2Table of contents 2022-06-01 A67-0140-00.BKen-0
01-07
