Tripp Lite TE600 Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TE600

TE Series 600VA Tower Line-Interactive 120V UPS with serial port

Highlights

6 outlets (3 UPS/surge, 3 surge-only)

Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages

Larger scale battery produces significantly longer runtimes

Serial port works with software to facilitate unattended shutdown

$200,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's TE600 UPS System provides line-interactive voltage regulation and long lasting battery support for small business telephone systems,

voicemail systems, personal computers and other communications, network and telecom applications. 600VA power handling capacity and large

capacity battery system maintains continuous operation through power interruptions with over 1 hour runtime for many phone systems. Line

interactive voltage regulation maintains normal 120 volt output levels during brownouts as low as 75 and overvoltages as high as 147, saving battery

reserves for use only during complete power failures. Unique design features 6 protected outlets (3 UPS supported & 3 surge-suppression only),

diagnostic LEDs and a built-in serial port that works with PowerAlert Software and cabling to provide automatic unattended shutdown of network and

PC applications (part# 75-0195). $200,000 Ultimate Lifetime Insurance (USA & Canada Only).

Package Includes

TE600 UPS System

Warranty information

Instruction manual

Features

Provides connected equipment with continuous power during short and long duration loss of commercial power

Line-interactive voltage regulation corrects brownouts and overvoltages from 75 to 147 volts back to usable 120V output levels, without

using battery power

Supports loads up to 600VA/425 watts

22 minutes half load runtime (300VA/210 watts), 7 minutes full load runtime (600VA/425 watts)

6 protected outlets total (3 UPS Supported & 3 surge-suppression only); 6-ft. cord

DB9 serial network interface

Complete surge protection and EMI/RFI noise filtering

$200,000 Ultimate Lifetime Insurance (USA and Canada Only)

4 diagnostic LEDs indicate AC present, on battery, voltage correction & battery low/replace

Battery replacement door

Specifications

OUTPUT

Output Volt Amp Capacity

(VA)

600

Output Watt Capacity

(watts)

425

Nominal Output Voltage(s)

Supported

115V; 120V

Frequency compatibility 60 Hz

Output voltage regulation

(line mode)

-18%, +8%

Output voltage regulation

(Battery mode)

115V (+/- 5%)

Built-in UPS output

receptacles

6 5-15R outlet(s)

Surge suppression only

outlets

3 UPS outlets, 3 surge-only outlets

Output AC waveform (AC

mode)

Sine wave

Output AC waveform

(battery mode)

PWM sine wave

INPUT

Rated input current (at

maximum load)

12A

Nominal Input Voltage(s)

Supported

120V AC

UPS input connection type 5-15P

UPS Input cord length (ft.) 6

UPS Input cord length (m) 1.8

Recommended Electrical

Service

15A 120V

BATTERY

Full load runtime (minutes) 9 min. (600w)

Half load runtime (minutes) 22 min. (300w)

DC system voltage (VDC) 12

Battery recharge rate

(included batteries)

Less than 6 hours from 10% to 90%

Replacement battery

cartridge (internal UPS

battery replacement)

RBC52 (quantity 2)

Battery Access Battery access door

VOLTAGE REGULATION

Voltage regulation

description

Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 75 to 147

Overvoltage correction Input voltages between 128 and 147 are reduced by 12%

Undervoltage correction Input voltages between 93 and 107 are boosted by 14%

Severe undervoltage

correction

Input voltages between 75 and 92 are boosted by 30%

LEDS ALARMS & SWITCHES

LED Indicators 4 LEDs indicate line power, battery power, overload and battery low/replace status

Alarms Audible alarm indicates power-failure and low-battery conditions

Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation

SURGE / NOISE SUPPRESSION

UPS AC suppression joule

rating

480

UPS AC suppression

response time

Instantaneous

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form factors

supported with included

accessories

Tower

Installation form factors

supported with optional

accessories

Wallmount (UPSWM - tower mounting kit)

Primary form factor Tower

UPS / Power Module

dimensions in primary form

factor (height x width x

depth / inches)

10.8 x 5.2 x 7.5

UPS / Power Module

dimensions in primary form

factor (height x width x

depth / cm)

27.3 x 13.3 x 19

UPS / Power Module weight

(lbs)

UPS / Power Module weight

(kg)

8.6

UPS Shipping dimensions

(height x width x depth /

inches)

14 x 8.5 x 11

UPS Shipping dimensions

(height x width x depth / cm)

35.6 x 21.6 x 27.9

Shipping weight (lbs) 21

Shipping weight (kg) 9.5

UPS housing material Vinyl

ENVIRONMENTAL

Operating Temperature

Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full

load)

92.2

Battery mode BTU / hr. (full

load)

125.7

COMMUNICATIONS

Communications interface DB9 Serial

PowerAlert software Free download from www.tripplite.com

LINE / BATTERY TRANSFER

Transfer time 2-4 milliseconds

Low voltage transfer to

battery power (setpoint)

High voltage transfer to

battery power (setpoint)

147

SPECIAL FEATURES

Cold Start (startup in

battery mode during a

power failure)

Cold-start operation supported

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B

(EMI)

WARRANTY

Product Warranty Period

(Worldwide)

2-year limited warranty

Connected Equipment

Insurance (U.S., Canada &

Puerto Rico)

$200,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Product Type Related Model Description Qty.

Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1

Extended Warranties WEXT3-OMNI 3-Year Extended Warranty - For OmniSmart, OmniPro, OmniVS 1

Extended Warranties WEXT5-OMNI 5-Year Extended Warranty - For OmniSmart, OmniPro, OmniVS 1

Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial

lines

Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and

communication lines

Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and

communication lines

Wallmount Bracket UPSWM Wallmount Bracket and installation accessories (4 washers, 4 screws,

1 Velcro safety strap)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=66.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
