Tripp Lite TLP810SAT Manuel utilisateur
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: TLP810SAT
Protect It! Surge Suppressor
Highlights
8 outlets / 10-ft. cord
3570 joule rating
2 sets of coaxial/satellite surge protection jacks (1 set provides digital
broadband quality and can handle 2.2GHz bandwidths)
Modem/fax surge protection
$250,000 Ultimate Lifetime Insurance (USA & Canada only)
Description
Tripp Lite's TLP810SAT Surge Suppressor offers complete AC, telephone and coax line surge suppression on two lines for comprehensive system
protection of home theaters, A/V systems and desktop PCs. Heavy grade AC surge suppression shields connected equipment from damage and
performance problems due to the heaviest transient surges. Two pairs of coax line suppression jacks protect any two type F coax lines for cable-TV,
satellite, broadcast antenna or cable modems. One set of coaxial jacks provide digital broadband quality and can handle 2.2GHz bandwidths. Set of
RJ11 jacks offers surge suppression for pay-per-view satellite systems, dial-up and DSL modems, fax machines and cordless phones. TLP810SAT
offers 8 total outlets, 10-foot cord with space-saving angled plug and diagnostic LEDs with audible alarm to warn of wiring problems and suppressor
damage. Network grade AC suppression rated at 3570 joules shields equipment from surges and line noise. Integrated child-safety outlet covers
safely seal off unused outlets. Attractive black suppressor housing with keyhole mounting tabs and 3 designated transformer plug outlets offers
convenient protection of entire home theatre, a/v and computer equipment and accessories. $250,000 Ultimate Lifetime Insurance (USA & Canada
only)
PLUG/OUTLETS: Input: NEMA5-15P/Output: 8 NEMA5-15R/10-ft. AC line cord
ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)
FORMAT: Corded multi-outlet strip with transformer-spaced outlets
SUPPRESSION: AC: 150V RMS Clamping/3570 joules
PHONE: Set of phone jacks (RJ11, 2-wire, 1 line)
COAX: 2 Sets Type F Coax Jacks
Applications
Ideal for home theater, satellite or cable TV applications requiring AC protection and coax line suppression. Also compatible with desktop
computer applications requiring AC plus dialup or cable modem protection.
Package Includes
TLP810SAT Surge Suppressor
6-ft. telephone cable
Two 6-ft. coax cables
Two 6-ft. coax cables
Instruction manual with warranty information
Features
3570 joules AC surge suppression shields equipment from the strongest surges and line noise
8 AC outlets with room for 3 transformer plugs without blocking outlets covers computers and all peripherals
Phone line surge suppression protects both dialup and DSL modems, plus fax machines, cordless phones and more (pair of RJ11 jacks,
2-wire, 1 line, includes 6-ft. phone cable)
Two sets of coax jacks protect cable modems, plus satellite, cable TV and broadcast antennas (pair of type N coax jacks, includes 6-ft. coax
cable. One set provides digital broadband quality and can handle 2.2GHz bandwidths
Long 10 foot AC line cable with space-saving angle input plug conveniently reaches distant outlets
Lighted power switch with integrated 15A circuit breaker offers power control and overload protection
Integrated child-safety sliding outlet covers safely seal off all unused outlets
Diagnostic LEDs confirm outlet grounding and surge suppression status
Audible alarm offers notification of suppressor damage
Attractive black suppressor housing with keyhole mounting tabs allow versatile placement options
$250,000 Ultimate Lifetime Insurance (USA & Canada only)
Specifications
OVERVIEW
Intended Application Home/Office, Audio/Video
SYSTEM OVERVIEW
Voltage compatibility 120 VAC
Frequency compatibility 50/60 Hz
OUTPUT
Output volt amp capacity
(amps)
15
Output watts 1800
Outlet quantity / type 8 NEMA 5-15R
Outlet orientation Single row of 5, plus a second row of 3 for transformer accommodation
Outlet safety covers Includes built-in sliding outlet safety covers
Transformer accommodation Supports 3 large transformer plug accessories without covering remaining outlets, accepts up to 6 transformers
total
INPUT
Input connection type NEMA 5-15P
Input cord gauge, type 14 gauge, SJT
Input cord length (ft.) 10 ft.
Input cord length (m) 3.0
Recommended Electrical
Service
120V (110-125V)
Input plug features Space-saving right-angle input plug
LEDS ALARMS & SWITCHES
Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
Alarms Audible alarm sounds to indicate damage to suppression components
Switches Combination AC circuit breaker and 2-position red illuminated on/off power switch
SURGE / NOISE SUPPRESSION
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
AC suppression joule rating 3570 joules
Clamping voltage (RMS) 150V
AC suppression response
time
< 1 ns
UL1499 let through rating 330V - UL Verified
EMI / RFI filtering Up to 40 dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection
Details
1 line
Cable (Coax) Protection Yes
Cable (Coax) Protection
Details
2 line (1 line supports 2.2GHz bandwidths)
Network (Ethernet) Protection No
PHYSICAL
Shipping weight (lbs) 2.5
Shipping weight (kg) 1.1
Shipping Dimensions
(HWD/in)
2.5 x 14.75 x 8.75
Shipping Dimensions
(HWD/cm)
6.4 x 37.5 x 22.2
Unit weight (lbs) 1.6
Unit weight (kg) 0.7
Unit Dimensions (HWD/in) 1.6 x 9.25 x 4.25
Unit Dimensions (HWD/cm) 4.1 x 23.5 x 10.8
Material of construction Plastic
Integrated keyhole mounting
tabs
Keyhole mounting tabs enable wall mounting
AC line cord color Black
Style Strip
CERTIFICATIONS
UL1449 1998 Rev. (AC
Suppression)
UL1449
UL1363 (Power Tap) UL1363
UL497A (Communications) UL497A
FCC Part 68
(Communications)
FCC Part 68
cUL / CSA (Canada) cUL
Industry Canada
(Communications)
Industry Canada
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period Lifetime
Connected Equipment
Coverage
$250,000
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=143.
©2009 Tripp Lite. All Rights Reserved.
