Tripp Lite TLP808TEL Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TLP808TEL

Protect It! Surge Suppressor

Highlights

8 outlets / 8-ft. cord

2820 joule rating

Modem/fax surge protection

$150,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's TLP808TEL surge suppressor has 8 outlets, an 8-ft. cord with a space-saving right-angle plug, and diagnostic LEDs. The unit has a

surge suppression rating of 2820 joules to handle the strongest surges. Built-in RJ11 jacks prevent surges from damaging your modem/fax/phone

equipment. $150,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Applications

Ideal for home computers and other important electrical equipment

Package Includes

TLP808TEL

6-ft. telephone cord

Instruction manual with warranty information

Features

8 outlets with integrated child safety covers

8-ft. cord with space-saving right-angle plug

Built-in RJ11 jacks (1 in/2 out) prevent surges from damaging your modem/fax/phone equipment; 6-ft. telephone cord included

Surge suppression rating: 2820 joules

EMI/RFI noise filtering

Can accommodate up to 3 transformers without blocking remaining outlets

$150,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Diagnostic LEDs indicate protection present & ground present

Keyhole supports for wall mounting

Lighted power switch

Lifetime product warranty

Specifications

OVERVIEW

Intended Application Home/Office

SYSTEM OVERVIEW

Voltage compatibility 120 VAC

Frequency compatibility 50/60 Hz

OUTPUT

Output volt amp capacity

(amps)

15A

Output watts 1800W

Outlet quantity / type 8 NEMA 5-15R

Outlet orientation Single row of 5, plus a second row of 3 for transformer accommodation

Outlet safety covers Includes built-in sliding outlet safety covers

Transformer

accommodation

Supports 3 large transformer plug accessories without covering remaining outlets, accepts up to 6 transformers

total

INPUT

Input connection type NEMA 5-15P

Input cord gauge, type 14 gauge, SJT

Input cord length (ft.) 8 ft.

Input cord length (m) 2.4

Recommended Electrical

Service

120V (110-125V)

Input plug features Space-saving right angle input plug

LEDS ALARMS & SWITCHES

Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status

Switches Combination AC circuit breaker and 2-position red illuminated on/off power switch

SURGE / NOISE SUPPRESSION

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

AC suppression joule rating 2820 joules

Clamping voltage (RMS) 150V

AC suppression response

time

< 1 ns

UL1499 let through rating 330V - UL Verified

EMI / RFI filtering Up to 40 dB

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection Yes

Telephone/DSL Protection

Details

1 line

Cable (Coax) Protection No

Network (Ethernet)

Protection

PHYSICAL

Shipping weight (lbs) 2.2

Shipping weight (kg) 1.0

Shipping Dimensions

(HWD/in)

2.5 x 14.75 x 8.75

Shipping Dimensions

(HWD/cm)

6.4 x 37.5 x 22.2

Unit weight (lbs) 1.6

Unit weight (kg) 0.7

Unit Dimensions (HWD/in) 1.6 x 9.25 x 4.25

Unit Dimensions (HWD/cm) 4.1 x 23.5 x 10.8

Material of construction Plastic

Integrated keyhole

mounting tabs

Keyhole mounting slots enable wall mounting

Receptacle Color white

AC line cord color white

Style Strip

SPECIAL FEATURES

Additional Information Pair of phone line output jacks serve as a line splitter to enable the protection of two devices sharing a single

dialup phone line

CERTIFICATIONS

UL1449 1998 Rev. (AC

Suppression)

UL1449

UL1363 (Power Tap) UL1363

UL497A (Communications) UL497A

FCC Part 68

(Communications)

FCC Part 68

cUL / CSA (Canada) cUL

Industry Canada

(Communications)

Industry Canada

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period Lifetime

Connected Equipment

Coverage

$150,000

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=141.
