Owner’s Manual

Mobile Workstation

with Flat-Panel Mount

Model: DMCS1732S

75x75

100x100 32"

MAX 17.6 lb.

(8 kg)

MOUNT

4.4 lb.

(2 kg)

KEYBOARD

22 lb.

(10 kg)

CPU

Español 13 • Français 25 • Русский 37 • Deutsch 49

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

www.tripplite.com/warranty

19-02-168-93394E.indb 1 4/8/2019 3:12:52 PM

NOTE: Read the entire instruction manual before you start assembly and

installation.

Warranty and Product Registration

WARNING

• Do not begin the installation until you have read and understood

the instructions and warnings contained in this manual. If you have

questions regarding any of the instructions or warnings, please visit

www.tripplite.com/support.

• This product was designed to be installed and utilized ONLY as speciﬁed

in this manual. Improper installation of this product may cause damage

or serious injury.

• This product should only be installed by someone of good mechanical

ability, with basic building experience and a full understanding of this

instruction manual.

• Make sure the unit can safely support the combined load of the

equipment and all attached hardware and components.

• Always use an assistant or mechanical lifting equipment to safely lift

and position equipment.

• This product is intended for indoor use only. Using this product outdoors

could lead to product failure and/or personal injury.

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original

defects in material and workmanship for a period of 5 years from the date of initial purchase. If the product

should prove defective in material or workmanship within that period, Seller will repair or replace the

product, in its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT,

MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY

EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED

WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION

TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL

INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied

warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential

damages, so the above limitations or exclusions may not apply to you. This warranty gives you speciﬁc legal

rights, and you may have other rights which vary from jurisdiction to jurisdiction).

WARNING: The individual user should take care to determine prior to use whether this device is suitable,

adequate or safe for the use intended. Since individual applications are subject to great variation, the

manufacturer makes no representation or warranty as to the suitability or ﬁtness of these devices for any

speciﬁc application.

PRODUCT REGISTRATION

Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered

into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice.

Photos and illustrations may differ slightly from actual products.

19-02-168-93394E.indb 2 4/8/2019 3:12:52 PM

Component Checklist

IMPORTANT: Ensure you have received all parts according to the component

checklist prior to installing. If any parts are missing or faulty,

visit www.tripplite.com/support for service.

Package M

Package P

A (x1) B (x1) C (x1) D (x1) E (x1)

P-A M4x12

(x4)

P-B M4x16

(x4)

P-C M5x12

(x4)

P-D M5x16

(x4)

P-E D5

(x4)

P-F

(x4)

F (x2) G (x2) H (x1) I (x1) J (x1)

K (x1)

M (x2) N (x1)

R (x2) S 4 mm (x1) T 5 mm (x1) U (x1)

O (x1) P (x2) Q (x2)

M-B (x3) M-C M6x6 (x3) M-D M6x12 (x4)

M-E M6x16 (x2) M-F (x2) M-G (x5)

L (x1)

M-A (x1)

19-02-168-93394E.indb 3 4/8/2019 3:12:52 PM

Assembly

M-D S

M-G

M-B

M-A

19-02-168-93394E.indb 4 4/8/2019 3:12:53 PM

Assembly

M-B

M-G

M-F

M-C S

19-02-168-93394E.indb 5 4/8/2019 3:12:55 PM

Assembly

PJM-E

19-02-168-93394E.indb 6 4/8/2019 3:12:56 PM

Assembly

Make sure the

bump on Cand

the bolt hole on

Bare matched in

alignment.

19-02-168-93394E.indb 7 4/8/2019 3:12:57 PM

Assembly

19-02-168-93394E.indb 8 4/8/2019 3:12:58 PM

Assembly

P-F P-E

P-E

P-B

P-D

P-A

P-C

19-02-168-93394E.indb 9 4/8/2019 3:12:58 PM

Assembly

19-02-168-93394E.indb 10 4/8/2019 3:12:59 PM
