Tripp Lite P560-050 Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: P560-100

100-ft. DVI Dual Link TMDS Cable (DVI-D M/M)

Highlights

For use with Dual or Single TMDS Link specified equipment

Compatible with Flat Panel Displays, Digital CRT Displays and Projectors

Provides bandwidth for resolutions up to 2560 x 1600

High Speed Digital Transmission to 9.9Gbps

Superior molded cables with foil/braid shielding for maximum EMI/RFI

protection

Check monitor manufacturers cable length specs - may need Tripp Lite

B120-000 DVI Extender

Description

Tripp Lite's 100 foot DVI Dual Link TMDS cable delivers the high performance, high bandwidth needed for todays digital video displays. Note:

Review your monitor manufacturers specifications for a stated maximum DVI cable length. While many monitors only support a 5 meter (16ft) DVI

cable, simply adding a Tripp Lite B120-000 DVI Extender will guarantee full digital signal strength at any length up to 150ft. Gold plated contacts

ensure excellent conductivity, while double shielding (foil and braid) provides maximum EMI/RFI protection. Use in conjunction with DVI video cards

that are specified as Dual or Single Link. Both DVI connectors are molded, have integral strain relief for long life reliability, and ferrite collars to drain

off extraneous electrical interference.

System Requirements

Monitor with DVI, and CPU with Dual or Single Link DVI capabilities

Package Includes

DVI Dual Link TMDS cable - DVI-D, M/M, 100'

Features

Superior molded cables with foil/braid shielding for maximum EMI/RFI protection

Dual Link digital signalling for transmission speeds to 9.9Gbps and 2560 x 1600 resolution

Meets DVI DDWG Standard

PC and Mac compatible

For use with Digital CRT displays, Flat Panel Displays, HDTV and Projectors

Check monitor manufacturers cable length specs - may need Tripp Lite B120-000 DVI Extender

Specifications

OVERVIEW

Intended Application Connecting Peripherals

Display Style Direct Connect

Model Type DVI

INPUT

Cable Length (ft.) 100

Cable Length (m) 30.48

PHYSICAL

Color Black

Style DVI

CONNECTIONS

Connector A

DVI-D DUAL LINK (MALE)

Connector B

DVI-D DUAL LINK (MALE)

Number of Connectors 2

CERTIFICATIONS

Certifications RoHS

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Cables and Accessories P120-000 DVI Male to VGA Female Adapter

(Analog DVI-M to HD15F)

Extenders/Signal Boosters B120-000 DVI Dual Link Signal Extender

(DVI F/F)

Video Cables & Adapters P126-000 DVI Female to VGA Male Adapter

(Analog DVI-F to HD15M)

Video Cables & Adapters P560-006 6-ft. DVI Dual Link TDMS Cable

(DVI-D M/M)

Video Cables & Adapters P560-010 10-ft. DVI Dual Link TDMS Cable

(DVI-D M/M)

Video Cables & Adapters P560-050 50-ft. DVI Dual Link TDMS Cable

(DVI-D M/M)

Video Cables & Adapters P561-006 6-ft. DVI Single Link TMDS Cable (DVI-D M/M) 1

Video Cables & Adapters P561-010 10-ft. DVI Single Link TMDS Cable (DVI-D M/M) 1

Video Cables & Adapters P562-006 6-ft. DVI Dual Link Extension TDMS Cable

(DVI-D M/F)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3327.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
