Tripp Lite B118-302-R Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: B118-302-R

HDMI Splitter, 2-Port

Highlights

Supports video resolutions up to 1080p

HDCP compliant

Connects to both HDMI and DVI-D Single-Link displays

ATC certified

Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule

purchases

Description

Tripp Lite's HDMI Splitter allows the digital signal from a Blu-Ray player or other HDMI device, to be displayed on multiple HDMI or DVI-D Single

Link monitors. Up to 32 displays can be connected by cascading up to three levels of additional splitters. Splitters can be located up to 100 ft. away

from the video source using a combination of Tripp Lite long length HDMI cables ( P568-050, P568-100-HD ) and a HDMI Signal Booster

(B122-000-60 or B123-001). Includes mounting hardware that allows the unit to be wallmounted, rackmounted or pole mounted. Compliant with the

Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Applications

Retail, Classroom, Movie Theaters...anywhere a HD signal needs to be broadcast to multiple digital dispays

Package Includes

B118-302-R 2-Port HDMI Splitter

1 ft. HDMI cable

Mounting hardware

External Power Supply (Input: 100-240V, 50/60Hz, 0.4A Output: 5V, 2A)

Owner's Manual

Features

Supports video resolutions up to 1080p

HDCP compliant

Supports 3D, Lip-Sync Pass Through, and CEC Pass Through

Connects to both HDMI and DVI-D Single-Link displays

Cascade up to three levels of splitters to support up to 32 displays

Includes mounting hardware that allows the unit to be wallmounted, rackmounted, or pole mounted

ATC certified

Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

Specifications

OVERVIEW

Display Style Splitter

Model Type HDMI Splitters

CONNECTIONS

Connector A

HDMI (FEMALE)

Connector B

(X2) HDMI (FEMALE)

Number of Connectors 3

Ports 2

WARRANTY

Product Warranty Period

(Worldwide)

1-year limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Video Cables & Adapters P568-006 6-ft. HDMI Gold Digital Video Cable

(HDMI M/M)

Video Cables & Adapters P568-006-FL 6-ft. Flat HDMI Gold Cable

(HDMI M/M)

Video Cables & Adapters P568-006-RA2 6-ft. HDMI Gold Right-angled Digital Video Cable

(HDMI-RA M/M)

Video Cables & Adapters P568-006-SW 6-ft. HDMI Gold Cable with Swivel Connectors

(HDMI M/M)

Video Splitters B118-304-R HDMI Splitter, Ver 1.3b, 4-Port 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=4032.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
