Tripp Lite EZB-HDMIM-2 Instructions d'installation

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: EZB-HDMIM-2

Easy Pull Type-B Connectors - M/M set of HDMI

Highlights

HDMI Connector Kit includes: 2 x HDMI Male 1 ft. Cables

Versatile trunk cable allows for a variety of connection options

High quality digital cable supports resolutions up to 1080p

Requires Tripp Lite B122-000 signal booster, P166-001-A Active Wall plate

Signal Booster or B123-001 HDMI Signal Booster

Description

Easy Pull Connector Kit includes: 2 x HDMI Male Cables - 1 ft. pigtails. Completes your Easy Pull trunk run with a finished appearance. Digital

video support up to 1080p. Use with either PVC or Plenum digital trunk cables. Requires Tripp Lite B122-000 signal booster, P166-001-A Active Wall

plate Signal Booster or B123-001 HDMI Signal Booster.

Applications

Use where standard HDMI cables won't fit, such as conduit or confined wall or ceiling spaces

Package Includes

2 x HDMI Male 1 ft. Pigtail Cable

Features

Eliminates the need to field terminate HDMI connectors

Allows cable to be run according to code - inside conduit, drop ceilings, etc.

Makes pulling long cables fast and easy

Digital trunk cables available in 50 and 100 ft. lengths

Use with Tripp Lite P166-001-A Active Wallplate Signal Booster, or B123-001 HDMI Signal Booster

High quality digital cable supports resolutions up to 1080p

Specifications

OVERVIEW

Display Style Easy Pull

INPUT

Cable Length (ft.) 1

Cable Length (m) 0.30

CONNECTIONS

Connector A

HDMI (MALE)

Connector B

HDMI (MALE)

Number of Connectors 2

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Extenders/Signal Boosters B123-001 1-ft. HDMI v1.3 Active Signal Extender Cable

(HDMI M/F)

1

Video Cables & Adapters EZB-050 50-ft. Easy Pull Long-Run Display Cable

Type-B Digital PVC Trunk Cable

1

Video Cables & Adapters EZB-100 100-ft. Easy Pull Long-Run Display Cable

Type-B Digital PVC Trunk Cable

1

Wallplates P166-001-A HDMI Display-side Wallplate with Signal Booster 1

Wallplates P166-001-P HDMI Send/Recieve Pass-through Wallplate 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3800.

Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
