Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: P606-015

15-ft. IEEE 1284 AB Parallel Printer Cable (DB25M to Cen36M)

Highlights

Superior molded cables with integral strain relief and foil-shielding for

maximum EMI/RFI protection

IEEE 1284 Printer Cables provide superior conductivity and support

high-speed bi-directional printing

Description

Tripp Lite's 15-ft. IEEE 1284 A-B parallel printer cable connects computers with a DB25 female parallel port to parallel printers with a Centronics 36

female parallel port. It supports high-speed IEEE 1284 bi-directional communication. The cable features nickel plated DB25 male/Cent36 male

connectors and gold plated copper contacts for superior conductivity. It is manufactured from superior molded cable with integral strain relief and

double shielding for maximum EMI/RFI protection. It contains low-capacitance, impedance matched, twisted-pair conductors that protect against

cross-talk and other transmission problems.

System Requirements

Computers with a DB25 Female parallel port

Parallel printers with a Centronics 36 Female parallel port with high-speed IEEE 1284 Bi-Directional communication (although not essential).

Package Includes

15-ft. IEEE 1284 AB Parallel Printer Cable DB25M to Cen36M

Features

Supports high-speed IEEE 1284 bi-directional communication (modes: standard compatible nibble byte ECP and EPP)

Length: 15-ft. Connectors: DB25 male/Cent36 male

Nickel plated connectors and gold plated copper contacts offer superior conductivity

Superior molded cable with integral strain relief and double shielding (foil and braid) for maximum EMI/RFI protection

Low-capacitance impedance matched twisted-pair conductors protect against cross-talk and other transmission problems

Bi-directional communication allows your printer to broadcast printer error messages back to network computers

Molded ends with easy-grip textured overmold

Specifications

OVERVIEW

Intended Application Connecting Peripherals

INPUT

Cable Length (ft.) 15

Cable Length (m) 4.57

PHYSICAL

Color Black

Style Printer Cables

CONNECTIONS

Connector A

DB25 (MALE)

Connector B

CENTRONICS 36 (MALE)

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Surge Protectors DB25-PAR Network Surge Suppressor - Essential protection for data and

communication lines

Switches B170-002-R IEEE Rev 2 Pos Autoswitch - 3xDB25F 1

Switches P606-006 6-ft. IEEE 1284 AB Parallel Gold Cable

(DB25M to Cen36M)

Switches P606-010 10-ft. IEEE 1284 AB Parallel Gold Cable

(DB25M to Cen36M)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2294.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
