TRION®

AIR BOSS

Model: IMP 38

FEATURES AND BENEFITS

A practical and economical method to eliminate oil mists is to apply Trion’s AIR BOSS Model 38 unit.

Under normal mechanical and thermal stresses, petroleum based and synthetic oils in the lubrication

systems break down into fine mist and smoke particles.

These particles, under pressure, escape through bearing seals to breather vents where they are

exhausted, these airborne oil mists can create health and fire hazards.

Trion’s Model 38 is ideal for collecting fumes and oil mists from Gas Turbines, Diesel Engines, Vacuum

Pumps, Compressors, Auxiliary Engines and Storage Tanks.

•Romoves fumes and oil mist from discharged air - helps maintain a cleaner work

environment and reduces costly maintenance clean-ups of oil

•Spiked Ionizers - no ionizing wires to replace, which reduces maintenance costs

•Low and constant static pressure - insures machinery performance

•3-speed selector switch - easy control for economic and effective results

•Easily installed and maintained - installed within 30 minutes to 1 hour

Specifications VENT FOG / IMP

Airflow Max Volume 1020 m3/hr

No. of Cells 1

Power (watts) 50

Noise Level dB(A) 50-70

Output Voltage (Kv) 12/6

Input Voltage 110V/1ph/50Hz - 230V/1ph/50Hz

Dimensions Height (mm) 1273 - 1727

Width (mm) 311 - 349

Length (mm) 390 - 714

Cell Weight (kg) 5.7 / 12.5

Weight (kg) 71 / 153

General Specification

Cabinet: Constructed of heavy gauge steel with

welded seams

Finish: High Bake Epoxy Powder

Airflow: Horizontal. Right/Left or Left/Right

Installation: Suspended, wall or frame mounted

Electrical Connection: Direct to junction box on unit

Pre-/after-filter: Washable aluminium mesh

Controls: On/Off Switch with operating light

Pre-Filter Options: Extended surface wraparound with 10

sq. ft of 2” thick polyester media

2” thick polyester pad in metal frame

Main Filter: 66 sq.ft. multi pocket with variable

stitching sealed against air leakage

Material: Borosilcate glass fibres with

bonded laminated backing

Efficiency to 95%

Main Filter Options: 65% efficiency filter bag

95% efficiency filter bag

Texwood: Polyester single pocket with

cleanable fibreglass liner

Optional: Filter change indicator gauge

Mounting: 4 eyebolts

Model: IMP 38

1. Clean Air Outlet

2. Dirty Air Outlet

3. Drain Outlet

4. Ionizer

5. Collector

6. Power Supply

7. Flame Arrestor

Air Purification Systems
