Trinity INFINITY Manuel utilisateur
Infinity – Operational Manual
This document contains the latest technical information about
Infinity which is a micro-controller based energy meter. The
product Infinity is sophisticated electronic equipment, and the
user is advised to read this User's Manual carefully before
attempting to install or operate the equipment.
Published on: 15.05.2015
Document Version: 1.7
USER'S MANUAL
INFINITY
Energy Meter
Infinity – Operational Manual
Warranty Statement
Trinity warrants to the original retail purchaser of the Trinity
product enclosed with this limited warranty statement that the
product, if purchased new and used in the India conforms to the
manufacturer's specifications and will be free from defects in
workmanship and materials for a period of one year from the date
of original purchase, unless expressly stated otherwise by Trinity,
in a written format.
Should your Trinity product prove defective during the warranty
period, please bring the product securely packaged in its original
container or an equivalent, along with proof of the date of original
purchase, to our Trinity Dealer or Factory. You are responsible for
all costs (shipping, insurance, travel time) in getting the product to
the service location. Trinity will, at its option, repair or replace on
an exchange basis the defective unit, without charge for parts or
labor. When warranty service involves the exchange of the
product or of a part, the item replaced becomes Trinity property.
The replacement unit may be new or refurbished to the Trinity
standard of quality, and at Trinity's option, the replacement may be
another model of like kind and quality. Trinity's liability for
replacement of the covered product will not exceed the original
retail selling price of the covered product. Exchange or
replacement products or parts assume the remaining warranty
period of the product covered by this limited warranty.
What This Warranty Does Not Cover:
This warranty does not apply to refurbished or reconditioned
products. This warranty covers only normal use in India. This
warranty does not cover damage to the Trinity product caused by
parts or supplies not manufactured, distributed or certified by
Trinity. This warranty is not transferable. This warranty does not
cover third party parts, components or peripheral devices added
to the Trinity product after its shipment from Trinity. Trinity is not
responsible for warranty service should the Trinity label or logo or
the rating label or serial number be removed or should the product
fail to be properly maintained or fail to function properly as a result
of misuse, abuse, improper installation, neglect, improper
shipping, damage caused by disasters such as fire, flood, and
Infinity – Operational Manual
lightning, improper electrical current, interaction with non-Trinity
products, or service other than by an Trinity Authorized Service.
The warranty and remedy provided above are exclusive and in
lieu of all other express or implied warranties including, but not
limited to, the implied warranties of merchantability or fitness for a
particular purpose. In the event, the remedies above fail, Trinity's
entire liability shall be limited to a refund of the price paid for the
Trinity product covered by this limited warranty. Except as
provided in this written warranty, neither Trinity Energy Systems
Pvt. Ltd. nor its affiliates shall be liable for any loss,
inconvenience, or damage, including direct, special, incidental, or
consequential damages, resulting from the use or inability to use
the Trinity product, whether resulting from breach of warranty or
any other legal theory.
Infinity – Operational Manual
Infinity – Operational Manual
Introduction........................................................................ 1
The Main Features Available In The Model................... 2
Technical Specifications ................................................. 4
Installation And Commissioning ......................................... 6
3P4W Mode Installation ................................................. 6
Back View Of The Unit ................................................... 10
RS485 Connection .......................................................... 11
Operational Details ......................................................... 12
Programming Mode............................................................. 13
Setting CT-Primary.......................................................... 13
Setting Meter Id For RS485 Port..................................... 14
Setting Time To Run Hour And Load Run Hour .............. 16
Setting Energy Parameter For Display…………………... 17
Run Mode............................................................................ 18
Communication................................................................... 20
Modbus RTU On RS485 Port.......................................... 20
Ordering Options ................................................................ 24
Introduction
Infinity is a digital energy meter for use in three phase electrical
systems as well as sub-metering applications. The design of this
meter is based on proven microcontroller technology with front
end ASICs, resulting in compact and accurate energy metering.
The accuracy of the meters is maintained even under severely
distorted waveform conditions which occur due to harmonics in
the system.
Infinity is the advanced model with bright 16X1 LC display having
optional features like RS485 port, dual source measurement and
whole current measurement up to 60A.
Infinity – Operational Manual
1
The Main Features Available in the Model
Class 1.0S accuracy as per IS13779
Class 0.5 accuracy also available
Compact 96 x 96 x 55 mm enclosure
Microcontroller based
Backlit 16 X 1 LC Display Optional Dual Source
Dual source measurement (EB & DG) along with Run Hour or
Load Run Hour available.
Energy Measurement Selectable Between KWh & KVAh
Whole current models up to 60Aavailable
RS-485 Communication port with MODBUS-RTU protocol
2
Infinity – Operational Manual
3
Infinity – Operational Manual
Technical Specifications
Parameters
Type Name Statistics
Three Phases and Neutral of a 3P4W system
Supply
INPUT
Direct Voltage Input : Up to 300V L-N
Burden : 0.5VA
Voltage
Current
Wide operating Voltage SMPS : 80VAC -
300VAC, 50-60 H
Power Supply
Secondary Current: 5A or 1A ( optional )
Input
CT Primary : Site Selectable
Range of Reading : 5 -5000A
Burden : < 1.0VA
Overload : 5A CT = 6A RMS Continuous
(Through CT) 1A CT = 1.2A RMS Continuous
(Whole Current) : 120% of Imax continuous.
Infinity – Operational Manual
4
MEASU-
REMENT Comm
unica
tion
RS485 Port
Parameters
Type Name Statistics
Bezel 96 X 96 mm
Panel Cutout 92 X 92 mm
Depth of
installation 55 mm
O O
Operating temp 10 C to 50 C
Weight 0.276 Kgs
Min. Operating
Current 0.4% of CT primary.
Dual Source By presence or absence of 230VAC across
Sensing two terminals. Can be looped.
Supporting MODBUS-RTU protocol.
Energy
Total Active
Energy (KWh)
Range of Reading : 0 to 9999999.9 KWh
Accuracy : 1.0S as per IS13779.
MISCELLANEOUS
Dimensions
Run Hour and Load Run Hour (Any One Parameter Available Through Programming Mode)
5
Infinity – Operational Manual
Range of Reading : 0 to 9999999.9 KVAh
Accuracy : 1.0S as per IS13779.
(Energy Measurement Selection In Programming Mode)
Total Apparent
Energy (KVAh)
