TRIGEM LN620 Manuel utilisateur
Motherboard
User’s Guide
LN620
Disclaimer and Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior written
permission of TriGem Computer, Inc. No patent liability is assumed with respect
to the use of information contained herein. While every precaution has been taken
in the preparation of this publication, TriGem Computer, Inc. assumes no
responsibility for errors or omissions. There is no liability assumed for damages
resulting from the use of the information contained herein. Further, this publication
and features described herein are subject to change without notice.
Trademarks
TirGem is a registered trademark of TriGem Computer, Incorporated. Other product
names herein are for identification purposes only and may be trademarks of their
respective owners. TriGem disclaims any and all rights to those marks.
• Intel and Pentium II are registered trademarks of Intel Corporation, MMX is
a trademark of Intel Corporation.
• PS/2 and VGA are trademarks of International Business Machines Corporation.
• Microsoft, MS-DOS, Microsoft Windows 95, Microsoft Windows NT are
registered trademarks of Microsoft Corporation.
Copyright© 1997 by TriGem Computer, Inc.
Safety Information
Safety Information
Battery Warning Instruction
Caution
If battery is incorrectly replaced there poses a danger of explosion. Replace battery
only with the same or equivalent type recommended by the manufacturer. Discard
used batteries according to the manufacturer’s instructions.
Attention
Il y a danger d’explosion s’il y a remplacement incorrect de la batterie. Remplacer
uniquement avec une batterie du meme type ou d’un type recommande par le
constructeur. Mettre au rebut les batteries usagees conformement aux instructions
du fabricant.
Vorsicht
Explosionsgefahr bei unsachgemaäß em Austausch der Batterie. Ersatz nur durch
denselben oder einen vom Hersteller empfohlenen ähnlichen Typ. Entsorgung
gebraushter Batterien nach Angaben des Herstellers.
Fuse Warning Instruction
Caution
For continued protection against risk of fire, replace only with same type and rating
of fuse. Disconnect input power before servicing. Only connect this equipment to
an earthed socket outlet.
Vorsicht
Vor jeder service-arbeit netzstecker ziehen! Apparatet ma kun tilkobles jordet
stikkontakt.
Attention
Debrancher avant d’ouvrir.Apparaten skall anslutas till jordat nätuttag.
Atencion
Desconecte fuerza electrica antes del servicio. Laite on liitettävä
suojäkosketinistoraasian.
CONTENTS
Chapter 1 Motherboard Description
Features........................................................................................................ 1-1
Motherboard Overview .............................................................................. 1-3
Motherboard Connectors............................................................................ 1-4
Power Supply Connector ..................................................................... 1-5
Front Panel Connectors ........................................................................ 1-5
Rear Panel Connectors ......................................................................... 1-6
Board Expansion Connectors.............................................................. 1-9
FDD Connector..................................................................................... 1-9
Primary and Secondary E-IDE Connectors........................................ 1-9
Chapter 2 Using the BIOS Setup Program
About the Setup Program........................................................................... 2-1
Entering the Setup Program ....................................................................... 2-2
Exiting the Setup Program ......................................................................... 2-4
Setup Menu.................................................................................................. 2-5
Standard Setup Menu ........................................................................... 2-5
Advanced Setup Menu......................................................................... 2-8
Chipset Setup Menu............................................................................ 2-11
Power Control Setup Menu................................................................ 2-12
PCI/PnP Setup Menu .......................................................................... 2-14
Peripheral Setup Menu ....................................................................... 2-15
Utility Menu............................................................................................... 2-17
Detect IDE........................................................................................... 2-17
Color Set .............................................................................................. 2-18
Security Menu ........................................................................................... 2-18
Supervisor / User ................................................................................ 2-18
Anti-Virus ............................................................................................ 2-22
Defaults Menu........................................................................................... 2-23
Original................................................................................................ 2-23
Optimal ................................................................................................ 2-23
Chapter 3 Installing and Removing Board Options
Before You Begin ........................................................................................ 3-1
Installing the Pentium II Processor............................................................ 3-2
Installing the Retention Mechanism.................................................... 3-2
Installing the Pentium II Processor...................................................... 3-3
Setting the Processor Speed................................................................. 3-5
Upgrading to a Boxed Pentium II Processor............................................ 3-5
Removing the Pentium II Processor.................................................... 3-5
Removing the Heatsink Support Base ................................................ 3-7
Upgrading the Processor...................................................................... 3-9
Installing and Removing Memory Modules........................................... 3-10
Installing a Memory Module ............................................................. 3-11
Removing a Memory Module ........................................................... 3-11
Changing DIP Switch Settings................................................................. 3-12
The Things to do in Post-installation ...................................................... 3-13
Appendix A Specifications
Form Factor ................................................................................................ A-1
Processor..................................................................................................... A-1
Main Memory............................................................................................. A-1
Intel 440LX AGPset and PCI/IDE Interface ............................................ A-2
I/O features ................................................................................................. A-2
Five usable expansion slots ...................................................................... A-2
Other features ............................................................................................. A-3
Manufacturing Options.............................................................................. A-3
Power Supply ............................................................................................. A-4
Appendix B Error and Information Messages
BIOS Error Messages..................................................................................B-1
BIOS Beep Codes .......................................................................................B-3
Appendix C Motherboard Resources
DMA Channels............................................................................................C-1
Interrupts......................................................................................................C-2
Appendix D Update on Installing Windows 95
Installing the Bus Master IDE Driver....................................................... D-2
Installing the USB Driver.......................................................................... D-3
Installing the USB Driver.................................................................... D-3
1-11-1
1-11-1
1-1
Motherboard Description
Chapter 1
This chapter describes the major features of your motherboard.
Features
The motherboard supports the following features:
Slot 1 connector, 233 MHz, 266 MHz, or 300 MHz Intel Pentium II
processor with MMX technology
Three 168 pin DIMM sockets, support up to 384 MB of synchronous DRAM
(SDRAM) memory and support unbuffered EDO DRAM
512 KB of synchronous Pipeline Burst SRAM external cache on the substrate
in the Single Edge Contact (S.E.C.) cartridge
Two built-in PCI bus Enhanced IDE hard disk drive controllers, each channel
supports up to two hard disk drives or CD-ROM drives
Intel 82443LX PCI/A.G.P. controller
Intel 82371AB PCI/ISA/IDE Xcelerator
ITE 8679F super I/O controller
Two Universal Serial Bus (USB) interfaces
Three 32-bit PCI slots, one 16-bit ISA slot, and one shared PCI/ISA slot
One A.G.P. (Accelerated Graphics Port) connector
Motherboard Description
Motherboard Description
1-21-2
1-21-2
1-2
Motherboard Description
System and video BIOS shadow RAM
Plug-and-Play (PnP) BIOS feature
A built-in PS/2 style keyboard connector and a built-in PS/2 compatible
mouse connector
Two serial ports (one built-in connector and one optional pin header) and one
built-in parallel port
The following are manufacturing options:
Wake up LAN connector
Wake up Ring connector
Management extension hardware
Chassis security connector
System fan controller connector
TheAccelerated Graphics Port(A.G.P.) isahigh-performance
interconnect for graphic-intensive applications, such as 3D
applications.A.G.P.is independent ofthe PCI busand is intended
for exclusive use with graphical-display devices.
The motherboard has two USB ports; one USB peripheral can be
connected to each port. For more than two USB devices, an external
hub can be connected to either port. The motherboard fully supports
the universal host controller interface (UHCI) and uses
UHCI-compatiblesoftwaredrivers.
1-31-3
1-31-3
1-3
Motherboard Description
Motherboard Overview
Figure 1. Motherboard overview
Back panel I/O connectors
ISA connectors
ROM BIOS
Wake up LAN connector
PCI connectors
ITE 8679F super I/O controller
Intel 82443LX (PAC)
Battery
Serial port (COM2)
connector
Slot 1 connector
DIMM sockets
Chassis security connector
Speaker
Intel 82371AB (PIIX4)
A.G.P. connector
Front panel connector
System fan connector
DIP switch
Fan connector
(active heatsink fan)
Power supply
connector
Secondary E-IDE connector
Primary E-IDE connector
FDD connector
Wake up Ring
connector
IrDA connector
Management
extension hardware
Fan connector
1-41-4
1-41-4
1-4
Motherboard Description
Motherboard Connectors
Figure 2. Motherboard connectors
DIMM sockets
Power supply
connector
ISA connectors
PCI connectors
Serial port (COM2)
connector
Chassis security
connector
A.G.P. connector
Front panel connector
System fan connector
Fan connector
(active heatsink fan)
Secondary E-IDE connector
Primary E-IDE connector
FDD
connector
Wake up ring
connector
DIP switch
IrDA connector
Slot 1 connector
Wake up LAN
connector
Fan connector
