TRENDnet TK-804R Manuel utilisateur

TK-804R

2.01

Quick Installation Guide

Table of Contents

Version 07.25.2009

English 1

1. Before You Start

2. How to Install 2

3. Operation 6

Technical Specifications 11

Troubleshooting

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

1. Before You Start

?PS/2 or USB Keyboard

?PS/2 or USB Mouse

?VGA Compatible Monitor

?USB KVM Cables (e.g. TK-CU06/TK-CU10/TK-CU15)

?Windows 95/98(SE)/ME/2000/NT/XP/2003 Server/Vista, Linux, Unix, Mac

Package Contents

?TK-804R

?Multi-Language Quick Installation Guide

?AC Power Adapter (9V DC, 1A)

?Rack mount kit

?Daisy-chain cable (HDB 15-pin

male to HDB 15-pin female) (9in/22.86cm)

?Daisy-chain terminator (HDB 15-pin male)

System Requirements

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

2. How to Install

To KVM

To PC

PC 1, 2, 3, 4, 5, 6, 7, 8

1. Turn OFF all computers and their

peripherals, and then disconnect all power

cords.

2. Connect the shared PS/2 or USB keyboard,

monitor, and PS/2 or USB mouse to the KVM

switch's Console Port.

3. Connect the included AC Power Adapter to the

KVM switch and then to a power outlet.

4. Use the KVM cables to connect your PC to the

KVM switch.

5. Turn ON the connected computers one-by-one

and wait until each computer's desktop

appears.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

Note:

1. The maximum accumulated daisy-chain cable length is 30 meters

2. You must use the daisy-chain cable provided with the KVM switch

3. You can only daisy-chain the KVM switch with another TK-804R

4. You can daisy-chain up to 16 KVM switches. There is a maximum of 128 PCs

connections

Daisy-Chain

1. Connect one end of the provided daisy-chain

cable to the Daisy-Chain OUT port on the first

(master) KVM switch.

2. Connect the opposite end of the daisy-chain

cable to the Daisy-Chain IN port on the second

(slave) KVM switch.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

3. If you have a third KVM switch, connect one

end of the daisy-chain to the Daisy-Chain OUT

port on the second KVM switch. Then connect

the opposite end of the daisy-chain cable to the

Daisy-Chain IN port on the third (slave) switch.

Repeat for each additional switch.

4. Connect the included Daisy-Chain terminator to

the Daisy-Chain OUT port on the last KVM

switch in the chain

5. Turn ON the connected computers one-by-one

and wait until each computer's desktop

appears.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

The KVM Switch can be mounted in an EIA standard-size 19-inch rack, which can be

placed in a wiring closet with other equipment.

Note: If you would like to mount the KVM switch to a EIA 19” equipment rack, install the

included mounting brackets to the sides of the KVM switch, secure them with the

screws provided, and then mount the KVM switch to the equipment rack with the

hardware provided by the equipment rack manufacturer.

Rack Mount

1. Attach the mounting brackets to both sides of

the KVM switch and secure them with the

provided screws.

2. Carefully position the KVM switch onto the rack.

Align the bracket to the screw holes on the

rack, then use the screws provided with the

equipment rack to mount the KVM switch.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet.

Your configuration is now complete.

0 10 1

Push Buttons

Press the push buttons to switch between

computers.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

3. Operation

Note: To switch between computers, you can use the front-panel push buttons, On

Screen Display (OSD) or the Hot Key commands.

LED Indicators

Red LED light: KVM cable is connected and

PC is powering the KVM switch.

Green LED light: Indicates the selected PC

port is active, whether the computer is turned

on or off.

Bank Number

Indicates the sequence of the KVM

switch when daisy-chained.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

Hot-Key Commands

A keyboard hot-key command consists of at least three keystrokes:

Hot Key command = Scroll Lock + Scroll Lock + Command key(s)

After pressing the Scroll Lock key, you have 2 seconds to press the key

again. You then have another 2 seconds to press a command key. A beep confirms that

the KVM switch is in "Hot-Key" mode. If you do not press a key within 2 seconds, the

switch will exit hot-key mode.

To select a specific PC port:

Scroll Lock

For example, to select port 1 on the 1st KVM switch, you hit the following key

sequence.

Select PC =

For example, to select port 08 of the 8 KVM switch on a series of daisy-chained

TK-804R's you hit the following key sequence:

Note: When using the KVM switch standalone, do not enter the bank number. For

example, to select port 1 on the KVM switch you hit the following key sequence.

Scroll Lock Scroll Lock +

++ + +

ABY Z

Bank number

Port number

Scroll Lock Scroll Lock +

++ + +

0101

Scroll Lock Scroll Lock +

++++

0808

For a list of all the Hot Key commands, please see the Quick Reference Sheet.

ENGLISHFRANÇAISDEUTSCHESPAÑOL

ÐÓÑÑÊÈÉ

On Screen Display (OSD) Control

To activate the OSD Menu, use the following hot-key command:

Scroll Lock Scroll Lock Space Bar

Note: For detailed information regarding the OSD, please refer to the Quick

Reference Sheet.
