TRENDnet TK-200K Manuel utilisateur

TRENDnet

TRENDware, USA

What's Next in Networking

TK-200K/TK-400K

Version 07.11.05

KVM Switch Kit

User’s Guide

Le Guide de l'utilisateur du

Kit de Switch KVM

Diese Benutzeranleitung

KVM-Umschalters

Esta guía del usuario

Kit de conmutador KVM

KVM-коммутатор в комплекте

Руководство пользователя

Table of Contents

English ...................................................................................................... 1

1. Prepare for Installation ......................................................................

2. Introduction .......................................................................................

3. Installation .........................................................................................

4. Operation ..........................................................................................

Specifications ...........................................................................................

Troubleshooting ........................................................................................

Thank you for purchasing TRENDnet's TK-200K/TK-400K KVM Switch Kit. This

guide will help you set up your KVM switch. Following the installation

instructions should be quick and easy. If you run into problems, please refer to

the Troubleshooting section. If you need further technical support, please visit

www.TRENDNET.com or call our technical support team by phone.

Verify Package Contents

Please make sure you have everything in the box:

The TK-200K 2-Port/TK-400K 4-Port PS/2 KVM Switch is compatible with

virtually all computers and operating systems. You only need to have one

monitor, one PS/2 keyboard, and one PS/2 mouse.

User’s Guide

TK-200K/TK-400K

1. Prepare for Installation

English UG

English

TRENDnet

TRENDware, USA

What's Next in Networking

TK-200K/TK-400K

Version 07.11.05

KVM Switch Kit

User’s Guide

Le Guide de l'utilisateur du

Kit de Switch KVM

Diese Benutzeranleitung

KVM-Umschalters

Esta guía del usuario

Kit de conmutador KVM

KVM-коммутатор в комплекте

Руководство пользователя

2. Introduction

The TK-200K/TK-400K is a PS/2 KVM Switch Kit that allows you to control 2 or

4 computers, respectively, using a single monitor, PS/2 keyboard, and PS/2

mouse. By using this KVM Switch, you'll cut hardware costs, save valuable

space, and reduce energy consumption. KVM cables are included in this kit for

your convenience.

Hardware Support

The TK-200K/TK-400K KVM Switch is compatible with virtually all PS/2 mice,

including Microsoft Intellimouse, Microsoft Optical Mouse, and Logitech Net

Mouse.

Software Support

The TK-200K/TK-400K KVM Switch does not require any drivers or software. It

is compatible with the following operating systems: Windows

98/ME/2000/XP/2003 Server, Linux, and Netware.

Plug-N-Play and Hot-Pluggable

The TK-200K/TK-400K KVM Switch connects to your computers via the PS/2

interface for convenient Plug-and-Play functionality and hot-pluggability.

Front-panel buttons and Hot-Key Commands

You can use the front-panel push buttons or Hot-Key commands to switch

between your computers quickly and easily.

With full-sized features crammed into a space-conserving size, TRENDnet's

TK-200K/TK-400K KVM Switch is perfect for use at home or in the office.

English

3. Installation

1. Turn off both computers and their peripherals, and disconnect all power

cords.

2. Connect the shared keyboard, monitor, mouse to their respective ports on

the KVM switch. The KVM Switch's inputs are color-coded for your

convenience.

3. Connect each set of integrated KVM cables to each computer's video, PS/2,

mouse connectors.

4. Turn on the connected computers. After the computers boot up completely,

you may begin operating the KVM switch. Installation is now complete.

English

NOTE: Do not switch the PC port (i.e.: Do not press the push button of

the KVM switch or enter a "Hot-Key" command) while the computers are

booting up.

VGA

4-Port KVM Switch Kit

(TK-400K)

PC 1

LCD Monitor

Keyboard

VGA

PS/2

PC 2

VGA

PC 4

PS/2

VGA

PC 3

PS/2

VGA Cable

PS/2 Cable

Mouse

VGA

PC 1

PS/2

KeyboardMouse

VGA

PS/2

2-Port KVM Switch Kit

(TK-200K)

VGA Cable

PS/2 Cable

PC 2

LCD Monitor

To switch between computers, you use the front-panel push buttons or hot-key

commands.

Hot-Key Commands

A keyboard hot-key command consists of three keystrokes:

Hot-Key command = ScrLk + ScrLk + Command key(s)

After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.

You then have another 2 seconds to press a command key. If you do not press

a key within 2 seconds, the switch will exit hot-key mode.

Below are the “Hot-Key” commands:

4. Operation

English

In Hot-Key mode, press the “Up-Arrow” to select the previous port, “Down

Arrow” to select the next port, and “S” key to set the KVM switch to Auto-Scan

mode.

ScrLk ScrLk Previous Channel

Next Channel

Auto Scan

+ + =

ScrLk

ScrLk S

Port Selection: Push Button and Hot-Key Commands

Auto-Scan Intervals: 10 seconds

Power Type: PS/2 Interface Power.

Optional 5V~9V DC, 500mA~1A Adapter

Specifications

Computer Connections: 2 (TK-200K) or 4 (TK-400K)

KVM Cable: TK-200K: 2 sets of integrated 1.2 M (4 ft) KVM Cables

TK-400K: 4 sets of integrated 1.8 M (6 ft) KVM Cables

Console Port Connectors:

1 x PS/2 keyboard 6-pin mini din female

1 x PS/2 mouse 6-pin mini din female

1 x VGA HDB15 (15-pin) female

2 x PS/2 keyboard 6-pin mini din female (TK-200K)

2 x PS/2 mouse 6-pin mini din female (TK-200K)

2 x VGA HDB15 (15-pin) female (TK-200K)

4 x PS/2 keyboard 6-pin mini din female (TK-400K)

4 x PS/2 mouse 6-pin mini din female (TK-400K)

4 x VGA HDB15 (15-pin) female (TK-400K)

PC Port Connectors:

VGA Resolution: 1920 x 1440

Dimensions:

TK-200K: 113 x 84 x 31 mm

(4.45 x 3.31 x 1.22 inches)

TK-400K: 192 x 81 x 31 mm

(7.5 x 3.2 x 1.2 inches)

Weight: Approx. 155g. (5.5 Oz.) (TK-200K)

Approx. 240g. (8.5 Oz.) (TK-400K)

0º ~ 40ºC (32º ~104º F)

Operating Temperature:

-20º ~ 60ºC (-4º ~ 140º F)

Storage Temperature:

0%~90%, Non-Condensing

Humidity:

FCC and CE

Certifications:

Troubleshooting

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Where is the power supply? I did not find one in the box.

The TK-200K/TK-400K does not require a power supply. It draws power from

the PS/2 connection of your computers. As long as you are connected to the PS/2

port, your KVM switch will function.

Can I connect and disconnect the PS/2 cables while the computers are turned

on?

Yes, you can connect or disconnect the PS/2 cables while the computers are

turned on because the KVM switch is Plug-and-Play and Hot-Pluggable.

Will the KVM switch restore the keyboard settings when switching between

computers?

Yes, the KVM switch will restore the keyboard settings between computers

such as Cap lock, Num key, etc.

How do I switch from one computer to another with the KVM switch?

You can switch PCs by pressing the Push button on the KVM switch or by

using the Hot-Key commands. For a complete listing of the Hot-Key commands,

see the reverse-side of this page.

If you have further questions, please contact Trendware's Technical Support

Department.

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received.

Including interference that may cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

TRENDnet

TRENDware, USA

What's Next in Networking

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDware’s website at http://www.TRENDNET.com

TRENDware International, Inc.

3135 Kashiwa Street. Torrance, CA 90505

http://www.TRENDNET.com

TRENDnet Technical Support

Contact

Telephone:

Fax:

Email:

1(310) 626-6252

1(310) 626-6267

[email protected]

Tech Support Hours

7:30am - 6:00pm Pacific Standard Time

Monday - Friday

Tech Support Hours

Telephone

Fax:

Deutsch :+49 (0) 6331 / 268-460

Français :+49 (0) 6331 / 268-461

Español :+49 (0) 6331 / 268-462

English :+49 (0) 6331 / 268-463

Italiano :+49 (0) 6331 / 268-464

Dutch :+49 (0) 6331 / 268-465

+49 (0) 6331 / 268-466

8:00am - 6:00pm Middle European Time

Monday - Friday

US/Canada Support Center European Support Center

Contact
