TRENDnet TE100-S16g Manuel utilisateur

TE100-S16g_TE100-S24g (V1) /07.31.2015

ŸQuick Installation Guide (1)

Ÿ16-Port 10/100Mbps GREENnet Switch

Ÿ24-Port 10/100Mbps GREENnet Switch

TE100-S16g / TE100-S24g

Package Contents

1. Before You Start

2. Hardware Installation

ŸTE100-S16g / TE100-S24g

ŸMulti-Language Quick Installation Guide

ŸPower Cord

ŸRack Mount Kit

System Requirements

ŸA computer with a network adapter installed

ŸCat.5, Cat.5e or Cat.6 Network Cable

ŸThe surface must support at least 1.86 Kg for the Switch

ŸThe power outlet should be within 1.82 m (6 ft) of the switch

ŸVisually inspect the DC power jack to make sure that it is securely

connected to the power adapter

ŸMake sure that there is proper heat dissipation from and adequate

ventilation around the switch

ŸDo not place heavy objects on the switch

1. Connect the Power Cord to the TE100- S16g/TE100-S24g and then to a

power outlet.

Rack Mount

The switch can be mounted in an EIA standard-size, 19-inch rack, which can be

placed in a wiring closet with other equipment.

1. Attach the mounting brackets to both sides of the switch and secure them

with the provided screws.

2. Carefully position the switch onto the rack. Align the bracket to the screw

holes on the rack, then use the screws provided with the equipment rack to

mount the switch.

2. Connect a Cat.5, Cat.5e or Cat.6 RJ-45 network cable from the computer to

an available Ethernet port on the TE100- S16g/ TE100-S24g.

3. LEDs

Power

ŸGreen: Power is on

ŸNot Illuminated: Power is off

Link/ACT

ŸGreen (Solid): Link to another device

ŸGreen (Blinking): Activity is occurring from the link

ŸNot Illuminated: Nothing is detected on the port

100Mbps

ŸGreen: Connection for the port is 100/200Mbps (Half/Full)

ŸNot Illuminated: Connection for the port is 10/20Mbps (Half/Full) or

nothing is detected on the port.
