TRENDnet TE100-S16 - DATA SHEETS Manuel utilisateur

TE100-S16

16-Port 10/100Mbps

Fast Ethernet Switch

User’s Guide

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in

accordance with this user’s guide, may cause harmful interference to

radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference, in which case the user will

be required to correct the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product

may cause radio interference, in which case the user may be required

to take adequate measures.

UL Warning

a) Elevated Operating Ambient Temperature-If installed in a closed or

multi-unit rack assembly, the operating ambient temperature of the

rack environment may be greater than room ambient. Therefore,

consideration should be given to installing the equipment in an

environment compatible with the manufacturer's maximum rated

ambient temperature (Tmra).

b) Reduced Air Flow-Installation of the equipment in a rack should

be such that the amount of air flow required for safe operation of the

equipment is not compromised.

c) Mechanical Loading-Mounting of the equipment in the rack should

be such that a hazardous condition is not achieved due to uneven

mechanical loading.

d) Circuit Overloading-Consideration should be given to the

connection of the equipment to the supply circuit and the effect that

overloading of circuits might have on over current protection and

supply wiring. Appropriate consideration of equipment nameplate

ratings should be used when addressing this concern.

e) Reliable Earthing-Reliable earthing of rack-mounted equipment

should be maintained. Particular attention should be given to supply

connections other than direct connections to the branch circuit (e.g.,

use of power strips).

P/N :1907ESW16D15000

TABLE OF CONTENTS

About This Guide..............................................1

PURPOSE.....................................................................................................1

TERMS/USAGE..........................................................................................1

OVERVIEW OF THISUSER’S GUIDE......................................................1

Introduction.......................................................2

FAST ETHERNET TECHNOLOGY...........................................................2

SWITCHING TECHNOLOGY....................................................................3

FEATURES ..................................................................................................4

Unpacking and Installation.................................6

UNPACKING...............................................................................................6

INSTALLATION..........................................................................................6

RACK MOUNTING....................................................................................7

Identifying External Components.......................8

FRONT PANEL ...........................................................................................8

REAR PANEL .............................................................................................9

Technical Specification....................................10

ABOUT THIS GUIDE

Congratulations on your purchase of the 16-port 10/100Mbps

Auto-negotiation Fast Ethernet Switch. This device integrates

100Mbps Fast Ethernet and 10Mbps Ethernet network

capabilities in a highly flexible package.

Purpose

This guide discusses how to install your 16-port 10/100Mbps Fast

Ethernet Switch.

Terms/Usage

In this guide, the term “Switch” (first letter upper case) refers to your

16-port 10/100Mbps Fast Ethernet Switch, and ”switch” (first letter

lower case) refers to other Ethernet switches.

Overview of this User’s Guide

Introduction. Describes the Switch and its features.

Unpacking and Installation.Helps you get started with the basic

installation of the Switch.

Identifying External Components. Describes the front panel, rear

panel, and LED indicators of the Switch.

Technical Specifications. Lists the technical (general, physical and

environmental, and performance) specifications of the Switch.

INTRODUCTION

This chapter describes the features of the Switch and some

background information about Ethernet/Fast Ethernet switching

technology.

Fast Ethernet Technology

The growing importance of LANs and the increasing complexity of

desktop computing applications are fueling the need for high

performance networks. A number of high-speed LAN technologies

have been proposed to provide greater bandwidth and improve

client/server response times. Among them, 100BASE-T (Fast

Ethernet) provides a non-disruptive, smooth evolution from the

current 10BASE-T technology. The non-disruptive and smooth

evolution nature, and the dominating potential market base, virtually

guarantee cost effective and high performance Fast Ethernet solutions

in the years to come.

100Mbps Fast Ethernet is a new standard specified by the IEEE 802.3

LAN committee. It is an extension of the 10Mbps Ethernet standard

with the ability to transmit and receive data at 100Mbps, while

maintaining the CSMA/CD Ethernet protocol. Since the 10/100Mbps

Fast Ethernet is compatible with all other 10Mbps Ethernet

environments, it provides a straightforward upgrade and takes

advantage of the existing investment in hardware, software, and

personnel training.

Switching Technology

Another approach to pushing beyond the limits of Ethernet technology

is the development of switching technology. A switch bridge Ethernet

packets at the MAC address levelof the Ethernet protocol transmitting

among connected Ethernet or Fast Ethernet LAN segments.

Switching is a cost-effective way of increasing the total network

capacity available to users on a local area network. A switch

increases capacity and decreases network loading by dividing a local

area network into different segments, which don’t compete with each

other for network transmission capacity.

The switch acts as a high-speed selective bridge between the

individual segments. The switch, without interfering with any other

segments, automatically forwards traffic that needs to go from one

segment to another. By doing this the total network capacity is

multiplied, while still maintaining the same network cabling and

adapter cards.

For Fast Ethernet networks, a switch is an effective way of eliminating

problems of chaining hubs beyond the “two-repeater limit.” A switch

can be used to split parts of the network into different collision

domains, making it possible to expand your Fast Ethernet network

beyond the 205-meter network diameter limit for 100BASE-TX

networks. Switches supporting both traditional 10Mbps Ethernet and

100Mbps Fast Ethernet are also ideal for bridging between the

existing 10Mbps networks and the new 100Mbps networks.

Switching LAN technology is a marked improvement over the

previous generation of network bridges, which were characterized by

higher latencies. Routers have also been used to segment local area

networks, but the cost of a router, the setup and maintenance required

make routers relatively impractical. Todayswitches are an ideal

solution to most kinds of local area network congestion problems.

Features

The Switch were designed for easy installation and high performance

in an environment where traffic on the network and the number of

user increase continuously.

The Switch with its standard EIA-19 rack-mountable size is

specifically designed for middle to large workgroups. The Switch

provides immediate access to a rapidly growing network through a

wide range of user-reliable functions.

The Switch is ideal for deployment with multiple high-speed servers

for shared bandwidth 10Mbps or 100Mbps workgroups. With the

highest bandwidth 200Mbps (100Mbps full-duplex mode), any port

can provide workstations with a congestion-free data pipe for

simultaneous access to the server.

The Switch is expandable by cascading two or more switches

together. As all ports support 200Mbps, the Switch can be cascaded

from any port and to any number of switches.

The Switch is a perfect choice for a site that may upgrade to Fast

Ethernet in the future. Ethernet workgroups can connect to the

Switch now, and change adapters and hubs anytime later without

needing to change the Switch or reconfigure the network.

The Switch combines dynamic memory allocation with

store-and-forward switching to ensure that the buffer is effectively

allocated for each port, while controlling the data flow between the

transmit and receive nodes to guarantee against all possible packet

loss.

The Switch is an unmanaged 10/100 Fast Ethernet Switch that offers

solutions in accelerating Ethernet Workgroup’s bandwidth. Other key

features are:

?? 16-port 10/100BASE Ethernet Switch with RJ-45

connectors

?? Support Auto-negotiation for speed and duplex modes

for each port

?? Supports Auto-MDI-II/MDI-X for each port

?? Wire speed reception and transmission

?? Store-and-Forward switching method

?? Integrated address Look-Up Engine, supports 8K

absolute MAC addresses

?? Supports 512Kbytes RAM for data buffering

?? Front-panel diagnostic LEDs

?? Broadcast storm protection

?? IEEE 802.3x flow control for full-duplex

?? Back pressure flow control for half-duplex

?? Standard 19” Rack-mountable size

UNPACKING AND INSTALLATION

This chapter provides unpacking and setup information for

the Switch.

Unpacking

Open the shipping carton of the Switch and carefully unpacks its

contents. The carton should contain the following items:

?? One the 16-port 10/100Mbps Fast Ethernet Switch

?? One AC powercord, suitable for your area’s electrical

power connections

?? Four rubber feet for shock cushioning

?? Screws and two mounting brackets

?? This User’s Guide

If any item is found missing or damaged, please contact your local

reseller for replacement.

Installation

The site where you install the Switch stack may greatly affect its

performance. When installing, consider the following pointers:

Install the Switch in a fairly cool and dry place. See Specifications

for the acceptable temperature and humidity operating ranges.

Install the Switch in a site free from strong electromagnetic field

generators (such as motors), vibration, dust, and direct exposure to

sunlight.

Leave at least 10cm of space on the left and right hand side of the

Switch for ventilation.

Autres manuels pour TE100-S16 - DATA SHEETS

Table des matières

Autres manuels TRENDnet Changer

TRENDnet

TRENDnet TPE-TG82ES Manuel utilisateur

TRENDnet

TRENDnet TK-208K Manuel utilisateur

TRENDnet

TRENDnet TEG-S40TXE Manuel utilisateur

TRENDnet

TRENDnet TK-1603R Manuel utilisateur

TRENDnet

TRENDnet TEG-3102WS Manuel utilisateur

TRENDnet

TRENDnet TE100-DX4PCI Manuel utilisateur

TRENDnet

TRENDnet TI-PG541i Manuel utilisateur

TRENDnet

TRENDnet TE100-DX8Eplus Manuel utilisateur

TRENDnet

TRENDnet TK-403KR Manuel utilisateur

TRENDnet

TRENDnet TPE-80WS - Web Smart PoE Switch Manuel utilisateur

TRENDnet

TRENDnet TEG-S2600I - 10/100Mbps Switch With Mini-GBIC... Manuel utilisateur

TRENDnet

TRENDnet TEG-2248WS - Gigabit Web Smart Switch Manuel utilisateur

TRENDnet

TRENDnet TK-804R Manuel utilisateur

TRENDnet

TRENDnet TK-802R Manuel utilisateur

TRENDnet

TRENDnet TEG-S081Fi Manuel

TRENDnet

TRENDnet TPE-TG80G Manuel utilisateur

TRENDnet

TRENDnet TPE-TG44G Manuel utilisateur

TRENDnet

TRENDnet TPE-S88 - Web Smart PoE Switch Manuel utilisateur

TRENDnet

TRENDnet TK-423K Manuel utilisateur

TRENDnet

TRENDnet TEG-S2400I - DATA SHEETS Manuel utilisateur

TRENDnet

TRENDnet TK-408K Manuel utilisateur

TRENDnet

TRENDnet TK-210K Manuel utilisateur

TRENDnet

TRENDnet TI-PG541i Manuel utilisateur

TRENDnet

TRENDnet TK-423K - USB/PS/2 KVM Switch Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
