TRENDnet TE100-S800i Manuel utilisateur

TE100-S800i

TE100-S810Fi

Quick Installation Guide

Español .....................................................................................................

Troubleshooting ........................................................................................

1.Antes de iniciar ..................................................................................

2. Cómo conectar ..................................................................................

3. Cómo utilizar el conmutador ..............................................................

Table of Contents

Version 10.13.05

Requisitos del sistema

Cable de poderAC

Cable RS-232

Guía de instalación rápida

Guía del usuario en CD-ROM

100-S800i/TE100-S810Fi

Contenidos del paquete

1. Estaciones de trabajo con tarjetas de red

2. Protocolo TCP/IPinstalado en todas las estaciones de trabajo

3. Una navegador Web como Internet Explorer o Netscape Navigator

4. Un cable de red RJ-45 para conectar su estación de trabajo al

TE100-S800i/TE100-S810Fi

(TE100-S800i)

8-Port 10/100Mbps Layer 2 Managed Switch

(TEG-S810Fi)

8-Port 100Base-FX Layer 2 Managed Switch with 100Base-FX Port

Workstations with 32-bit PCI

Fast Ethernet Card

(TE100-PCIWA)

Accounting

Department

Internet

Servers with 32-bit PCI

Fast Ethernet Card

(TE100-PCIWA)

Servers with 32-bit PCI

Fast Ethernet Card

(TE100-PCIWA)

Sales

Department

8-port 10/100Mbps

Fast Ethernet Mini Switch

(TE100-S88Eplus)

5-port 10/100Mbps

Fast Ethernet Mini Switch

(TE100-S5Pplus)

8-port 10/100Mbps

Fast Ethernet Mini Switch

(TE100-S8P)

MIS

Department

100Mbps

Español

1. Antes de iniciar

1. Conecte el cable de alimentaciónAC a la

parte posterior del TE100-S800i/

TE100-S810Fi.

3. Verifique que los LEDs de PWR (Encendido)

despliegan una luz verde sólida.

2. Conecte el cable de red en la parte frontal

del conmutador y su PC.

Español

2. Cómo conectar

Español

Nota: Para más detalles sobre las características avanzadas, por favor

consulte la Guía del Usuario.

La instalación ha sido completada

7. Seleccione la opción apropiada

para configurar el conmutador

SNMP.

4. Haga clic en la pestaña General,

seleccione Protocolo de Internet

(TCP/IP) y luego haga clic en

Propiedades.Cambie la dirección

IP a 192.168.16.222 y haga clic en

OK para aplicar las

configuraciones.

6. Nombre de usuario: root

Contraseña: root

5. Abra su navegador Web, escriba

http://192.168.16.1, y luego pulse

Enter (Intro).

Español

Q1.

A1.

Q2.

A2.

Q3.

A3.

How come I cannot see any light from any of my LED's?

Your TE100-S800i/TE100-S810Fi is not getting any power. Make

sure that your surge protector or your outlet is getting power and make

sure that theAC Power cord is properly connected to your

TE100-S800i/TE100-S810Fi.

I changed my IP settings to 192.168.16.222 to access the switch, but I

still cannot get into the Web configuration page. What should I do?

Make sure there is no other network device using the same IP

address. Afterwards, consult the User's Guide to access the switch

through the Console Port. Once you reach the command line interface,

perform a factory reset and try again.

I performed a factory reset on the TE100-S800i/TE100-S810Fi, but I

still cannot access the web configuration page. What should I do?

If you are configuring more than one TE100-S800i/TE100-S810Fi,

then it is possible that you are experiencing IP conflict between these two

switches. Please configure each switch one at a time, and make sure you

assign a unique IP address to each switch.

If you have any questions regarding the TE100-S800i/TE100-S810Fi, please

contact TRENDnetTechnical Support Department.

Troubleshooting

Certifications

This equipment has been tested and found to comply with FCC and CE Rules. Operation is

subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received.

Including interference that may cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FORANY RADIO ORTV INTERFERENCE

CAUSED BY UNAUTHORIZED MODIFICATIONS TOTHIS EQUIPMENT. SUCH MODIFICATIONS

COULD VOID THE USER’SAUTHORITY TO OPERATE THE EQUIPMENT.

Waste electrical and electronic products

must not be disposed of with household

waste. Please recycle where facilities

exist. Check with you Local Authority or

Retailerforrecyclingadvice.

3135 Kashiwa Street

Torrance, CA 90505

USA

TRENDnet Technical Support

Tech Support Hours

24/7 Toll Free Tech Support

Contact

Telephone: 1(866) 845-3673

Email: [email protected]

Contact

Tech Support Hours

Telephone:

Deutsch :+49 (0) 6331 / 268-460

Français :+49 (0) 6331 / 268-461

0800-90-71-61 (numéro vert)

Español :+49 (0) 6331 / 268-462

English :+49 (0) 6331 / 268-463

Italiano :+49 (0) 6331 / 268-464

Dutch :+49 (0) 6331 / 268-465

Fax: +49 (0) 6331 / 268-466

8:00am - 6:00pm

Middle European Time

Monday - Friday

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDnet’s website at http://www.trendnet.com

US/Canada Support Center European Support Center
