TRENDnet's TFC-110 series Fiber Media Converter

transforms 10/100Base-TX UTP/STP media to 100Base-FX

media and vice versa. The 10/100Base-TX port auto-sense

10 or 100Mbps connection speed, auto-negotiates half-/full-

duplex mode, and auto-selects MDI-X / MDI-II media type.

The fiber connection can be multi-mode SC, MT-RJ, or

single-mode SC Connector and it has a slide-switch for

selecting half- or full-duplex mode. This converter will give

your Switch/Hub the ability to interface with fiber connection

over a distance up to 2 km. With the optional 16-slot EIA-19"

rack-mount chassis; the TFC series converters are the

perfect solutions for various fiber media conversions for your

network.

TFC-110MSC (b1)

10/100Base-TX to 100Base-FX Multi-Mode

Fiber Converter with SC-Type Connector

TFC-110MSC(b1)

rev: 07.19.2010

• Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX / 100Base-FX standards

• One 10/100Base-TX auto-negotiation RJ-45 port

• Auto-negotiation 10/100Mbps connection speed and Half/Full-duplex mode on TX port

• Auto MDIX for 10/100Base-TX port

• One 100Mbps fiber port with Multi-mode SC-Type Connector

• Half / Full-Duplex mode selector on Fiber port

• Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed

• Wall-Mountable

• Optional 19” system chassis with redundant power supply (TFC-1600), holds up to 16 TFC series Media Converters

• 3-year limited warranty

FEATURES

fiber

Supported Frame Size

Temperature

Network Media

Wavelength

Protocol

Ports

Power Adapter

Humidity

• IEEE802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX

• Power, Link/Activity, Full-Duplex, and Speed

• Standard Ethernet up to 1522-Byte

• 7.5VDC, 1.5A (7.2 watts max.)

• Operating: 0°~ 40°C (32°~ 104°F)

• Storage: 5% ~ 90% (non-condensing)

• 100Base-TX: Cat. 5, EIA/TIA-568 100-ohm UTP/STP, up to 100 meters

• 100Base-FX: Multi-Mode fiber optic cable 50/125 or 62.5/125 µm, up to 2 Km

• 1300nm

• CSMA/CD

• Storage: -25°~ 70°C (-13°~ 158°F)

• 1 x 10/100Base-TX

• 1 x 100Base-FX

• 100Mbps (Half-Duplex), 200Mbps (Full-Duplex)

• Operating: 10% ~ 90%

Data Transfer Rate

Diagnostic LEDs

Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

10/100Base-TX to 100Base-FX Multi-Mode

Fiber Converter with SC-Type Connector

TFC-110MSC (b1)

RELATED PRODUCTS

TFC-110MSC

TFC-110MST

TFC-110MM

TFC-110S15

TFC-1600 16-Slot Chassis System for TFC series Fiber Converter

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with SC-Type Connector

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with ST-Type Connector

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with MT-RJ Connector

10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (15Km) with SC-Type Connector

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

SPECIFICATIONS

TFC-110S30

10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (30Km) with SC-Type Connector

10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (60Km) with SC-Type Connector

TFC-110S100 10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (100Km) with SC-Type Connector

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com
