TRENDnet TFC-1000MSC Manuel utilisateur
1000Base-SX/LX
Fiber Converters
Quick Installation Guide
Table of Contents
English ......................................................................................................
Spefications ..............................................................................................
Ordering Information...................................................................................
Troubleshooting ........................................................................................
1
1
2
4
5
1. Before You Start
2. .........................................................................
.................................................................................
Hardware Installation
Table of Contents
6
Version 02.02.2009
System Requirements
Product Detail
Fiber Converter
Quick Installation Guide
AC Power Supply (7.5 DC, 1.5A)
Package Contents
1. Before You Start
English
1
An environment that is free from strong electromagnetic field generators
(such as motors), vibration, dust and direct exposure to sunlight
10/100/1000Mbps Gigabit Switch
Multi-mode or Single-mode Fiber cables
CAT-5 or CAT-6 RJ-45 Ethernet Cable
TFC-1600 chassis (optional) or sturdy, level surface that can support the
weight of the Fiber Converter
Model Name Multi/Single-Mode Fiber Connector
TFC-1000MSC
TFC-1000S20
TFC-1000S50
TFC-1000S70
TFC-1000S10D3
TFC-1000S10D5
SC (Duplex)
SC (Simplex)
Multi-Mode
Single-Mode
Single-Mode
Bidirectional
2. Hardware Installation
English
2
Installing two stand alone Fiber Converters
1. Connect the fiber cable to the fiber
converters. This cable must be
multi-mode for the TFC-1000MSC.
This cable must be single-mode for
the TFC-1000S20/S50/S70/S10D3/
S10D5.
2. Connect an RJ-45 Ethernet cable
from the Ethernet port on the fiber
converters to an Ethernet port on
your switch (e.g TEG-S160TX or
TEG-S240TX).
Note: The TX and RX cables must be reverse on the opposite fiber connection.
Note: The TFC-1000S10D3 must be paired with the TFC-1000S10D5.
3. Connect the power adapter to the
back of the fiber converter.
5. Unfasten the thumbscrew and
remove the fiber converter from the
metal casing.
Your installation is now complete.
English
3
4. Unscrew the bay cover from the
desired bay on the chassis.
6. Slide the media converter into an
available slot and fasten the
thumbscrew.
Installing Media Converter in a Chassis
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
4
DIP Switches: Switch 1: On(Forced Mode); Off(Auto-Negotiation)
Switch 2: On(LLR enabled); Off(LLR disabled)
Cable :
1000BASE-T
Cat. 5e or Cat. 6 EIA/TIA-568 100-ohm screened
twisted-pair (STP)
1000BASE-SX
62.5/125µm multi-mode fiber optic cable
50/125µm multi-mode fiber optic cable
1000BASE-LX
9/125µm single-mode fiber optic cable
10/125 µm single-mode fiber optic cable
Applicable Standards: IEEE802.3ab 1000BASE-TX
IEEE802.3z 1000BASE-SX/LX
Fixed Ports: 1 TX port, 1 FX port
1488000pps for 1000Mbps
Forwarding rate:
LED Indicators: PWR, LNK/ACT
Weight: 305 g
Power: External power adaptor 7.5V 1.5A
5.5 Watts Max.
10 ~ 90%, non-condensing
Power Consumption:
Operating: 0°C ~ 40°C (32°F ~ 104°F)
Storage: -25°C ~ 70°C (-13°F ~ 158°F)
Temperature:
Humidity:
FCC part 15 Class B, CISPR ClassB, VCCI Class B,
CE Mark
Certifications:
Dimensions: L120 × W88 × H25 mm
Specifications
5
Ordering Information
TFC-1000MSC
TFC-1000S20
TFC-1000S50
TFC-1000S70
TFC-1000S10D3
TFC-1000S10D5
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
MMF
(50 or 62.5 )
SC
µm µm
SMF
(10 )
SC
µm
SMF
(10 )
SC
µm
SMF
(10 )
SC
µm
Bi-directional SMF
(10 )
SC
µm
Bi-directional SMF
(10 )
SC
µm
Media Converters
Model Number Speed
(Mbps)
Speed
(Mbps)
Cable/Connector Max.
Distance
Max.
Distance
Wavelength Cable(/125 µm )
/Connector
RJ-45 Port Fiber Port
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
100M
100M
100M
100M
100M
100M 1300nm
1300nm
1300nm
1300nm
TX: 1310nm
RX: 1550nm
TX: 1550nm
RX: 1310nm
220M
62.5/125µm
550M
50/125µm
20 km
50 km
70 km
10 km
10 km
Note: MMF (multi-mode fiber); SMF (single-mode fiber)
TFC-1000S40D3
TFC-1000S40D5
TFC-1000S60D3
TFC-1000S60D5
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
Cat. 5E, 6
EIA/TIA-568
100-ohm STP
SMF
(10 )
ST
µm
SMF
(10 )
SC
µm
Bi-directional SMF
(10 )
SC
µm
Bi-directional SMF
(10 )
SC
µm
1000
1000
1000
1000
1000
1000
1000
1000
100M
100M
100M
100M
TX: 1310nm
RX: 1550nm
TX: 1550nm
RX: 1310nm
40 km
40 km
60 km
60 km
TX: 1310nm
RX: 1550nm
TX: 1550nm
RX: 1310nm
6
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
After connecting the Fiber converter, the LEDs do not turn on. What should I
do?
First, check that the power outlet is receiving power. Second, make sure the
power adapter is firmly connected to the Fiber converter and the power outlet.
Third, make sure the Ethernet and the Fiber cables are connected.
All the LEDs are on, but I can't make a connection. What should I do?
First, verify that you are using the proper fiber cable (e.g. multi-mode fiber
cable for multi-mode converter; single-mode fiber cables for single-mode
converters). Second, verify that the TX and RX cables have been reverse on the
opposite Fiber connection. Third, power down the fiber converters and the
switches. Wait 15 seconds, then plug the switches and the fiber converters back
in.
What is the maximum distance that is supported by the fiber converter?
Please reference section 4 for distance information.
If you still encounter problems or have any questions regarding the Fiber Converters
please contact TRENDnet's Technical Support Department.
7
Limited Warranty
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
If a product does not operate as warranted above during the applicable warranty period,
TRENDnet shall, at its option and expense, repair the defective product or deliver to
customer an equivalent product to replace the defective item. All products that are
replaced will become the property of TRENDnet. Replacement products may be new or
reconditioned.
TRENDnet shall not be responsible for any software, firmware, information, or memory
data of customer contained in, stored on, or integrated with any products returned to
TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product through any unauthorized service center. This warranty is voided if
(i) the product has been modified or repaired by any unauthorized service center, (ii) the
product was subject to accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within the applicable
warranty period for a Return Material Authorization (RMA) number, accompanied by a
copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-
authorized by TRENDnet with RMA number marked on the outside of the package, and
sent prepaid, insured and packaged appropriately for safe shipment.
5 Year Limited Warranty
Fiber Converters
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE
AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT
TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING
WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES
NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S
MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE
RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER
HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET
ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER
BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF
LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Note: AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry 1-Year
Warranty
8
