TV-IP100
Version 07.08.2005
Internet Camera Server
Quick Installation Guide
Guide d'installation rapide pour
Caméra Internet Serveur
Anleitung zur Schnellinstallation der
Internet Kamera Server
Guía de Instalación Rápida para
Servidor de Cámara de Internet
Table of Contents
English ......................................................................................................
Troubleshooting ........................................................................................
1
1
2
3
4
1. Prepare for Installation ......................................................................
2. Install Hardware ................................................................................
3. Configure the Internet Camera ..........................................................
Thank you for purchasing the TV-IP100. This Internet Camera will allow you to
view live images from internal and external networks.
This guide will help you set up and configure your Internet Camera. Following
the installation instructions should be quick and easy. If you run into problems,
please refer to the Troubleshooting section or the more detailed installation
procedures on the CD User's Guide. If you need further technical support,
please visit www.trendnet.com or call our technical support department by
phone.
Verify Package Contents
Please make sure you have everything in the box:
1
1. Prepare for Installation
English QIG
English
System Requirement
1. 10/100Mbps Ethernet
2. CD-ROM Drive
3. CPU: Intel Pentium III 266 MHz or above
4. Memory: 128 MB or above (256 MB Recommend)
5. Web Browser: Microsoft Internet Explorer 5.0 or above
6. VGA Resolution: 800 x 600 or above
TV-IP100
CD-ROM Quick Installation Guide
AC Power Adapter Metal Stand and
Mounting Bracket
Copyright ©2005. All Rights Reserved. TRENDware International, Inc.
TRENDnet
TRENDware, USA
What's Next in Networking
TV-IP100
Version 07.08.2005
Internet Camera Server
Quick Installation Guide
Guide d'installation rapide pour
Caméra Internet Serveur
Anleitung zur Schnellinstallation der
Internet Kamera Server
Guía de Instalación Rápida para
Servidor de Cámara de Internet
2
2. Install Hardware
1. Position the metal stand, and mount the Internet Camera to the stand.
2. Connect the RJ-45 network cable to the Internet Camera then connect the
other end of the network cable to a switch or hub.
3. Connect the power adapter to the Internet Camera. Make sure to use the
power adapter supplied with the Internet Camera.
English
3
2
1
TV-IP100
Note: Using a different power adapter may damage the unit.
3English
1. Open Internet Browser Window and enter <http://192.168.0.20> (camera's
default IP address). Click System Administration.
2. Enter an IP address, Subnet mask, and Default gateway for your camera
and click the Save button to keep the changes. Now your camera is ready
to use.
3. Configure the Internet Camera
Note: The PC's IP (Example 192.168.0.50) address must correspond
with the Internet Camera's IP address (Default IP: 192.168.0.20) in the
same segment for the two devices to communicate.
For detailed information about each feature, please refer to the User's Guide
on the CD-ROM or contact our support.
Note: If you need to access the configuration remotely, it is
recommended to enter a static IP address and the Internet DNS IP
address.
4
Q1.
A1.
Q2.
A2.
Q3.
A3.
Q4.
A4.
The image is blurry, how do I fix this?
You can adjust the Internet Camera's focus by rotating the lens.
Can I replace the camera lens?
No. It cannot be replaced.
How do I view the Internet Camera's live images within my Local
Network?
Open a web browser (Internet Explorer or Netscape), type your
Wireless Internet Camera's IP address (i.e.: 192.168.0.20) in the Address
bar, and then hit the Enter key. The Welcome page of the Internet Camera
will appear.
When I enter the IP address of the camera, the image does not load,
why?
Please make sure all the Active X features are enabled for your
Internet Explorer.
1. Go to Tool (on the Tool bar) > Internet options > Security
Troubleshooting
5
2. Click on Custom Level and make sure all ActiveX controls are set to
"Enable" and click OK.
3. Once you save the settings, the browser will load again and the image
should appear.
1. Select Use the following IP address option and enter the IP, Subnet
Mask and Default gateway addresses.
2. Click OK to complete
6
Q5.
A5.
How do I configure my computer's IP address?
For Windows 2000/XP users:
- On the Desktop, right click on My Network Places > select Properties
> right click on the Local Area Connection > select Properties,
the Local Area Connection Properties Window will appear
- Under General tab, select Internet Protocol (TCP/IP) > click on
Properties button, Internet Protocol (TCP/IP) Properties Window will
appear
7
For Windows 98/ME users:
- On the Desktop, right click on Network Neighborhood > select Properties >
right click on the Local Area Connection > select Properties, the Local Area
Connection Properties Window will appear
- Under Configuration tab, select your Network Adapter (TCP/IP protocol) >
click on Properties button, TCP/IP Protocol Properties Window will appear
For detailed information about the TV-IP100’s configuration and advanced
settings, please refer to the User's Guide on the included CD-ROM or to
www.TRENDnet.com.
1. Select Specify an IP address option and enter the IP, Subnet
Mask addresses.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Copyright ©2005. All Rights Reserved. TRENDware International, Inc.
@
TRENDnet
TRENDware, USA
What's Next in Networking
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDware’s website at http://www.TRENDNET.com
TRENDware International, Inc.
3135 Kashiwa Street. Torrance, CA 90505
http://www.TRENDNET.com
TRENDnet Technical Support
Contact
Telephone:
Fax:
Email:
1(310) 626-6252
1(310) 626-6267
Tech Support Hours
7:30am - 6:00pm Pacific Standard Time
Monday - Friday
Tech Support Hours
Telephone
Fax:
Deutsch :+49 (0) 6331 / 268-460
Français :+49 (0) 6331 / 268-461
Español :+49 (0) 6331 / 268-462
English :+49 (0) 6331 / 268-463
Italiano :+49 (0) 6331 / 268-464
Dutch :+49 (0) 6331 / 268-465
+49 (0) 6331 / 268-466
8:00am - 6:00pm Middle European Time
Monday - Friday
US/Canada Support Center European Support Center
Contact
