TRENDnet TV-IP600W - Wireless Pan/Tilt/Zoom Internet Camera Server... Manuel utilisateur

TV-IP600W

rev: 08.11.2009

The ProView Wireless Pan/Tilt/Zoom Internet Camera provides real-time

security surveillance wirelessly over a large viewing area. Monitor people

in your camera's viewing field from any Internet connection. See more with

one wireless Internet camera—remotely pan the camera side-to-side a

remarkable 312 degrees and tilt up-and-down 115 degrees.

The TV-IP600W provides high quality video streams over a secure

wireless connection. Manage up to 32 TRENDnet cameras with the

included complimentary camera management software. Advanced

features include motion detection recording, email alerts, scheduled

recording sessions, auto-patrol pan/tilt and digital zoom. This camera's

brilliant image quality, pan and tilt functionality and recording capabilities

make it ideal for home, small office and business use.

TV-IP600W (v1.0R)

ProView Wireless Pan/Tilt/Zoom Internet Camera

internet

cameras

Features

•Wi-Fi compliant with IEEE 802.11b/g devices

•Compatible with IEEE 802.11n devices when set to wireless b/g/n Mixed Mode

•MJPEG video compression at up to 30 frames per second

•Resolution up to VGA: 640 x 480 pixels

•Pan: -156° ~ +156° and tilt: -45° ~ +70°

•Define up to 24 preset viewing points

•4x digital zoom

•Create up to 64 user accounts

•Full image color, saturation and contrast controls

•Exposure/white balance controls

•Flip-Image feature adjusts image when camera is mounted upside down

•Included wall and ceiling mounting hardware

•Supports TCP/IP networking, SMTP Email*, HTTP and other Internet protocols

•Record streaming video to your computer or network storage devices (after mapping)

•Motion detection email alerts, ftp uploads and recording from complimentary software

•Quick Universal Plug and Play (UPnP) installation

•Complimentary IPView Pro 2.0 software: manage up of up to 32 cameras **

•3-year limited warranty

!Does not support SSL

!** Monitoring multiple cameras may require a high performance CPU

LED

General

Pan/Tilt

Image & Video

Reset Button

• Sensor: 1/4” color CMOS SOC image sensor

Network

Camera

SPECIFICATIONS

Power Consumption

Power

Dimension

Weight

To Run Software

Temperature

IPView Pro 2.0

Certification

To View

Network Protocols

Hardware

Requirement

• Resolution: 640 x 480 pixels • Board Lens

• F/No: F1.9

• Focal Length: 4.57mm

• Minimum illumination: 1 Lux @ F1.9 • Focus depth: 20cm ~ infinity

• View angle: horizontal: 46 degree, vertical: 35 degree

• Compression: MJPEG • Exposure/white balance control: automatic

• Resolution: up to 15fps for VGA (640x480), 30fps for QVGA (320x240), 30fps for QQVGA (160x120)

• Pan: -156° ~ +156°

• IEEE 802.3u 10/100Mbps Fast Ethernet, Auto-MDIX

• Power, Link

• Reset settings

• 8 Watts

• 112 x 130 x 110mm (4.4 x 5.1 x 4.3 in.)

• 5V, 2.5A external power adapter

• 485g (1.1 lb)

• Internet Explorer 6.0 or above, Safari 2.0 or above, Firefox 2.0 or above, Opera, Netscape, and Google Chrome

• IP, ARP, TCP, UDP, ICMP

• CE, FCC

• Operating: 5ºC ~ 40ºC (41ºF ~ 104ºF)

• Windows XP, Vista

• Channel: supports up to 32 cameras

TV-IP600W

rev: 08.11.2009

• Tilt: -45° ~ +70° • Preset position: 24 positions

• Storage: -25ºC ~ 50ºC (13ºF ~ 122ºF)

• Record/Playback/Motion Detection

• HTTP Server • PPPoE

• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client

• UPnP

TV-IP600W (v1.0R)

ProView Wireless Pan/Tilt/Zoom Internet Camera

Wireless

• 2.412 ~ 2.4835GHz ISM band

• IEEE 802.11b, IEEE 802.11g

Standard

Frequency

• 1 x 2dBi dipole antenna (Reverse-SMA connector)

Antenna

• 802.11b: 11Mbps, 5.5Mbps, 2Mbps and 1Mbps

Data Rate (auto fallback)

• 802.11b: 16dBm (typical)

Output Power

• 64/128-bit WEP, WPA-PSK, WPA2-PSK

Security

• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

• 802.11g: 12dBm (typical)

• 802.11b: -82dBm at 11Mbps

Receiving Sensitivity • 802.11g: -66dBm at 54Mbps

Channel • 1~11 (FCC), 1~13 (ETSI)

Management

• Up to 64 user accounts*

Account

• Remote management supported

Remote

Backup / Restore • Save/retrieve configuration files

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

PACKAGE CONTENTS

TS-S402

TEW-639GR 300Mbps Wireless N Gigabit Router

• CD-ROM (Utility & User’s Guide)

2-Bay SATA I/II Network Storage Enclosure

• TV-IP600W

• Multi-Language Quick Installation Guide

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email:

1-888-326-6061

[email protected]

www.trendnet.com

TV-H400 Outdoor Camera Dome Enclosure with Heater and Fan

• Cat. 5 Ethernet cable (1.5m / 5ft.)

• Power adapter (5V, 2.5A)

• Wall mount kit

TV-IP600W (v1.0R)

ProView Wireless Pan/Tilt/Zoom Internet Camera

• Encoding type: MJPEG

• Brightness, contrast, noise reduction, saturation, sharpness, white balance, flip, mirror (horizontal/vertical), black/white mode


Video

Recording

• Resolution: 640 x 480, 320 x 240, 160 x 120

• Recording type: continuous, schedule or motion detection with software

Port Settings • HTTP port: 80 (default)

Setting

• Yes

• 4x

Digital Zoom

Dynamic DNS

Time • Synchronize with NTP server or set time/date manually

• Frame rate: 1, 5, 7, 15, 20, Auto

SMTP • Support SMTP mail

• Compression: 5 levels

* Up to 8~10 users is recommended to view the camera simultaneously

SPECIFICATIONS

300Mbps Wireless N

Gigabit Router

(TEW-639GR)

Internet

Pan/Tilt/Zoom Internet

Camera Server

(TV-IP600)

Wireless Pan/Tilt/Zoom Internet Camera Server

(TV-IP600W)

Pan/Tilt/Zoom Internet

Camera Server

(TV-IP600)

NETWORK SOLUTIONS
