TRENDnet TE-16PCTplus Manuel utilisateur

TRENDnet's ISAPlug-and-Play (PnP) Ethernet adapters built on the

technology of TRENDnet's best-selling Ethernet adapter. They

incorporate PnP technology to configure installed devices without

users' intervention automatically. This revolutionary feature

eliminates the guesswork involved in upgrading PCs. The PnP and

full-duplex functions increase the channel bandwidth from 10Mbps

to 20Mbps and avoid the performance-degrading problem. They

provide software configuration of the jumperless Ethernet through a

setup program.

TE-16PCTplus

16-bit ISA Plug-and-Play Ethernet Adapter

with BNC + RJ-45 Connectors

TE-16PCT plus

rev:01.04.2007

• Comply with IEEE 802.3 10Base-2 and 10Base-T (TE-16PCTplus) and IEEE 802.3 10Base-T (TE-16Ptplus) Ethernet standards

• Comply with Plug-and-Play (PnP) ISA specification version 1.0a

• On fully functional PnP systems, simply insert the card for automatic configuration

• Setup program provided for non-PnP system - no jumpers or switches on board

• 10Mbps (half-duplex)/20Mbps (full-duplex) data transfer rate

• Auto detection on 8-bit or 16-bit ISA bus and for media type

• 10Base-T port supports UTP/STP

• NE-2000 compatible, support Windows 95/98/ME/2000/XP

• On-board socket for remote boot ROM

• Easy-to-view LED indicators

• 5 Year Warranty

FEATURES

BENEFITS

Easy Configuration:

Plug-and-Play function simply lets you plug the adapter to the computer's ISA slot to connect to the network

Flexibility:

With the full-duplex mode, PCs connect to switch receiving and transmitting data at the same time on a

dedicated 20Mbps bandwidth

Performance:

Provide the performance that turns today's desktops into powerful workstations/servers

Cost-Effectiveness:

With its low cost of ownership and standard compliance, TRENDnet ISA PnP adapters are the perfect choice

for cost-effective workgroup networking.

Protocol

Boot ROM Address

Wiring Connector

Bus Network Media

Data Transfer Rate

Diagnostic LED

Operating Temperature

Humidity

Certifications

• IEEE 802.3

• 200H, 220H, 240H, 260H, 280H, 2A0H, 2C0H, 2E0H, 300H, 320H, 340H, 360H, 380H, 3A0H, 3C0H, 3E0H

• CSMA/CD

• C0000H, C4000H, C8000H, CC000H, D0000H, D4000H, D8000H, DC000H

• FCC, UL, CE, VCCI Class A

• BNC, RJ-45 Bus Interface: 16-Bit ISA

• UTP CAT 3, 4, 5 (100m), EIA/TIA-568 100-ohm screened twisted pair (STP) (100m), or thin coax

• 0° to 50°C (32° to 122°F)

• 10Mbps (Half-duplex), 20Mbps (Full-duplex)

• LINK

• 2 (9), 3, 4, 5, 10, 11, 12, 15

• 10% to 90% non-condensing

IRQ Support

I/O Base Address

Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

16-bit ISA Plug-and-Play Ethernet Adapter

with BNC + RJ-45 Connectors

TE-16PCTplus

RELATED PRODUCTS

TE100-PCIWN

TE100-PCIWA

TE100-PCIWS 32-bit PCI 10/100Mbps NWay Fast Ethernet Card

32-bit PCI 10/100Mbps N-way Fast Ethernet Card

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

TE-16PCTplus

TE-PCIWplus

TE-PCIWTplus

with ACPI Wake-on-LAN

16-bit ISA Plug-and-Play Ethernet Adapter

with BNC + RJ-45 Connectors

32-bit PCI Plug-and-Play Ethernet Adapter

with BNC + RJ-45 Connectors

32-bit PCI Plug-and-Play Ethernet Adapter

with RJ-45 Connectors

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com
