Transcend JetFlash 150 Series Manuel utilisateur

JetFlash™

User’s Manual

(Version 2.2)

Table of Contents

Introduction................................................................................................... 2

Package Contents.................................................................................................................... 2

Features.................................................................................................................................... 2

System Requirements............................................................................................................. 2

Driver Installation.......................................................................................... 3

Driver Installation for Windows® 98SE................................................................................... 3

Driver Installation for Windows®Me, 2000, XP and Vista™.................................................. 3

Driver Installation for Mac™OS 9.0, or Later......................................................................... 3

Driver Installation for Linux™Kernel 2.4.2, or Later ............................................................. 3

Formatting the JetFlash™............................................................................ 4

Safely Remove the JetFlash™ from a Computer....................................... 5

Remove the JetFlash™in Windows®98SE............................................................................. 5

Remove the JetFlash™in Windows®Me, 2000, XP and Vista™............................................ 5

Remove the JetFlash™in Mac®OS 9.0, or Later and Linux®Kernel 2.4.2, or Later........... 5

JetFlash™ 150 Series................................................................................... 6

JetFlash™ 120 Series................................................................................... 7

JetFlash™ 110 Series................................................................................... 8

JetFlash™ 2A Series..................................................................................... 9

JetFlash™ V20 Series................................................................................. 10

JetFlash™ V30 Series..................................................................................11

JetFlash™ V60 Series................................................................................. 12

JetFlash™ 130 Series................................................................................. 13

JetFlash™ 160 Series................................................................................. 14

JetFlash™ 168 Series................................................................................. 15

JetFlash™ 210 Series................................................................................. 16

JetFlash™ V10 Series................................................................................. 17

JetFlash™ V90 Series................................................................................. 18

JetFlash™ T2 Series................................................................................... 19

JetFlash™ 185 Series................................................................................. 20

Introduction

Congratulations on purchasing Transcend’s JetFlash™. This tiny device allows you to exchange

huge amounts of data and information between it and any desktop or notebook computer with a

USB port. The JetFlash™plugs directly into your desktop or notebook computer, has a large

storage capacity and much faster data transfer rates, making it perfect for storing and transferring

your files, folders, documents, photos and other personal digital content. In addition, the

JetFlash™’s small convenient size, superior data retention and impressive appearance will provide

you with a brand-new data storage experience.

Package Contents

The JetFlash™package includes the following items:

 JetFlash™

 Quick Instruction Guide

Features

 Hi-Speed USB 2.0 compliant and USB 1.1 backwards compatible

 Easy Plug and Play installation

 Driverless (Only Windows®98SE needs driver)

 Powered via the USB port. No external power or battery needed

 Additional bundled software (helps you manage your data)

System Requirements

Desktop or notebook computer with a USB port and one of following operating systems:

 Windows® 98SE

 Windows® Me

 Windows® 2000

 Windows® XP

 Windows Vista™

 Mac™OS 9.0, or later

 Linux™Kernel 2.4.2, or later

Driver Installation

Driver Installation for Windows® 98SE

Put the Driver CD into the CD-ROM (Auto-Run supported). Click the Win98SE Driver button. If the

product does not attach CD, you can download the Windows 98SE driver from Transcend’s website,

http://www.transcendusa.com/Support/DLCenter/Driver/JF_win98driver.zip.

Driver Installation for Windows®Me, 2000, XP and Vista™

No drivers are required. These Windows operating systems have built-in drivers to support the

JetFlash™. Simply plug the JetFlash™into an available USB port and Windows will install the files

needed to use your device. A new Removable Disk drive with a newly assigned drive letter will

appear in the My Computer window.

Driver Installation for Mac™OS 9.0, or Later

No drivers are required. Just plug the JetFlash™into an available USB port and your computer will

automatically detect it.

Driver Installation for Linux™Kernel 2.4.2, or Later

No drivers are required. Just plug the JetFlash™into the USB port and mount it.

Example: 1. First create a directory for the JetFlash™

mkdir /mnt/jetflash

2. Mount the JetFlash™

mount –a –t msdos /dev/sda1 /mnt/jetflashU

Formatting the JetFlash™

1. Plug the JetFlash™into a USB port and right-click on the removable disk.

2. Select “Format” in the drop down menu to format the JetFlash™.

WARNING! Formatting the Disk will erase all of the data on your JetFlash™

3. Click on the “Start” button to begin formatting the JetFlash™and follow the on-screen

instructions.

Safely Remove the JetFlash™ from a Computer

Remove the JetFlash™in Windows®98SE

Disconnect the JetFlash™from your system directly when data is not transferring.

Remove the JetFlash™in Windows®Me, 2000, XP and Vista™

1. Select the icon on the system tray.

2. The “Safely Remove Hardware” pop-up menu will appear. Select it to continue.

3. A message box will appear stating: “The ‘USB Mass Storage Device’ device can now be

safely removed from the system.”

Remove the JetFlash™in Mac®OS 9.0, or Later and Linux®Kernel 2.4.2,

or Later

Drag and drop the Disk icon corresponding to your JetFlash™into the trashcan. Then unplug your

JetFlash™from the USB port.

JetFlash™ 150 Series

Specifications

 Size: 59mm x 19mm x 10mm

 Weight: 10 g

 Certificates: CE, FCC, BSMI

Ordering Information

Transcend P/N Memory Size Color

TS256MJF150 256MB Green

TS512MJF150 512MB Blue

TS1GJF150 1GB Red

TS2GJF150 2GB Silver

TS4GJF150 4GB Orange

JetFlash™ 120 Series

Specifications

 Size: 75mm x 25mm x 11mm

 Weight: 15 g

 Certificates: CE, FCC, BSMI

Ordering Information

Transcend P/N Memory Size Color

TS128MJF120 128MB Amber

TS256MJF120 256MB Orange

TS512MJF120 512MB Red

TS1GJF120 1GB Blue

TS2GJF120 2GB Light Blue

TS4GJF120 4GB Turquoise

JetFlash™ 110 Series

Specifications

 Size: 64mm x 21mm x 10mm

 Weight: 11 g

 Certificates: CE, FCC, BSMI

Ordering Information

Transcend P/N Memory Size Color

TS128MJF110 128MB Gold

TS256MJF110 256MB Green

TS512MJF110 512MB Blue

TS1GJF110 1GB Red

TS2GJF110 2GB Gray

TS4GJF110 4GB Amber

JetFlash™ 2A Series

Specifications

 Size: 75mm x 25mm x 11mm (Mini Size)

88mm x 33mm x 15mm (Normal Size)

 Weight: 15 g (Mini Size)

24 g (Normal Size)

 Certificates: CE, FCC, BSMI

Ordering Information

Transcend P/N Memory Size Color

TS128MJF2A 128MB Silver, Mini Size

TS256MJF2A 256MB Silver, Mini Size

TS512MJF2A 512MB Silver, Mini Size

TS1GJF2A 1GB Silver, Mini Size

TS2GJF2A 2GB Silver, Mini Size

TS4GJF2A 4GB Silver, Mini Size

TS8GJF2A 8GB Silver, Normal Size

TS16GJF2A 16GB Silver, Normal Size
