Transcend ESD200 Manuel utilisateur

User‟s Manual

USB 3.0 Portable Solid State Drive

ESD200

(Version 1.0)

Table of Contents

Introduction︱......................................................................................1

Package Contents︱............................................................................1

Features︱............................................................................................2

System Requirements︱.....................................................................2

Safety Precautions︱...........................................................................4

General Use ....................................................................................................................... 4

Backing up Data................................................................................................................ 4

Transporting...................................................................................................................... 4

Power ................................................................................................................................. 4

Reminders.......................................................................................................................... 5

Product Overview︱.............................................................................5

Connecting to a Computer︱..............................................................6

Disconnecting from a Computer︱....................................................8

Windows........................................................................................................................... 8

Mac®OS ............................................................................................................................. 9

Linux®................................................................................................................................. 9

Formatting the Solid State Drive︱..................................................10

Windows®

XP/Vista/7/8.................................................................................................... 10

Mac®OS ........................................................................................................................... 11

Linux®............................................................................................................................... 13

Troubleshooting︱.............................................................................14

Specifications︱.................................................................................16

Transcend Limited Warranty︱........................................................17

Introduction︱

Congratulations on purchasing Transcend’sESD200.This ultra-fast SuperSpeed USB 3.0

portable storage device is the perfect data management system for storing and transferring your

data. With its shock-resistant design, huge storage capacity and real-world transfer speeds up to

10X faster than USB 2.0 (in USB 3.0 mode), the compact ESD200 is ideal for carrying your files,

folders, documents, photos, music and videos. In addition, the ESD200 comes with very useful

software* that can increase your mobile productivity. This User’s Manual is designed to help you

get the most from your new device. Please read it in detail before using the ESD200.

*Note: Transcend Elite software only works in Windows and Mac OS —please see the Software User's Manual for

details.

Package Contents︱

USB 3.0 Portable Solid State Drive

USB 3.0 Cable

Travel Pouch

Quick Start Guide

Warranty Card

Features︱

SuperSpeed USB 3.0 compliant and backwards compatible with USB 2.0

Connection bandwidth up to 5Gbits per second

Extra-large storage capacity

Sleek ultra portable design

Easy Plug and Play operation –no drivers required

USB powered –no external adapter necessary

One Touch Auto-Backup button

Includes Transcend Elite backup and security software

Multicolor LED indicator (power, data transfer, & USB 2.0/3.0 connection type)

System Requirements︱

Desktop or notebook computer with a working USB port.

One of following Operating Systems:

WindowsXP

WindowsVista

Windows7 / 8

LinuxKernel 2.6.31 or later

MacOS X 10.4 or later

Safety Precautions︱

These usage and safety guidelines are IMPORTANT! Please follow them carefully.

General Use

Carefully unpack the contents of the ESD200 package.

During operation, avoid exposing your ESD200 to extreme temperatures above 70℃, or

below 0℃.

Do not drop your ESD200.

Do not allow your ESD200 to come in contact with water or any other liquids.

Do not use a damp/wet cloth to wipe or clean the ESD200 exterior case.

Do not store your ESD200 in any of the following environments:

oDirect sunlight

oNext to an air conditioner, electric heater or other heat sources

oIn a closed car that is in direct sunlight

oIn an area with strong magnetic fields or excessive vibration

If your Windows computer will not boot while the ESD200 is connected, please

disconnect the ESD200 from your computer first and reconnect the ESD200 after

booting Windows. Otherwise, refer to your computer's manual and change the BIOS

settings to instruct the computer to boot from a different device.

Backing up Data

Transcend does NOT take any responsibility for data loss, or damage during

operation. If you decide to store data on your ESD200 we strongly advise that you

regularly backup the data to a computer, or other storage medium.

To ensure SuperSpeed USB 3.0 data transfer rates when using your ESD200, please

make sure that your computer has the relevant drivers and hardware to support USB 3.0.

If you are unsure about how to check this, please consult the user’s manual of your

computer, motherboard, or USB 3.0 interface card for USB 3.0 driver information.

Transporting

Do not pack the ESD200 into luggage without proper padded support. Other items in

your luggage may damage the SSD during travel if it does not have proper protection.

Avoid squeezing or compressing the ESD200.

Do not place objects on top of your ESD200.

Power

The ESD200 is powered directly via a computer USB port. However, the power supplied

by the USB port on some older computers is below the 5V DC required to power the

ESD200.

Use only the USB 3.0 cable that came with the ESD200 to connect it to a computer, and

always ensure that the cable you are using is in good condition. NEVER use a cable that

is frayed or damaged.

Ensure nothing is resting on the USB cable and that the cable is not located where it can

be tripped over or stepped on.

Reminders

Always follow the procedures in the ―Disconnecting from a Computer‖ section to remove the

ESD200 from your computer.

Product Overview︱

Micro USB 3.0 Port

One Touch Auto-Backup Button

LED Indicator

Connecting to a Computer︱

The ESD200 can be connected to your computer using either USB 2.0 or USB 3.0. To get the best

performance results from your SSD, we recommend using the USB 3.0 interface.

1. Plug the micro USB end (1) of the USB cable into the ESD200.

2. Plug the rectangular end (2) of the USB cable into an available USB 2.0 or USB 3.0 port on

your desktop or notebook computer.

3. When the ESD200 is successfully connected to a computer, its LED will either light up green

(USB 2.0) or blue (USB 3.0) to indicate the USB connection type. In Windows, a new Local

Disk drive with a newly-assigned drive letter will appear, and a Removable Hardware icon

will appear in theWindows System Tray. The ESD200 comes pre-formatted with the FAT32 file

system, which is compatible with most computer systems, including Windows, Mac, Linux,

and more.

Micro USB 3.0

Connector (1)

USB 2.0 / 3.0

Connector (2)

USB 3.0 Cable

ESD200 Micro USB port

USB 2.0 Port

USB 3.0 Port

Computers running Windows and Mac OS will automatically detect and install the ESD200. To use USB

3.0, please ensure your computer has all necessary USB 3.0 drivers installed, and make sure you plug

the USB cable into the correct port on your computer (USB 3.0 ports are usually color-coded to

differentiate them from USB 2.0)

Linux users may have to configure the ESD200 manually. To do this, first create a directory for the

ESD200 (Example: mkdir /mnt/SSD). Then, mount the ESD200 (Example: mount –a –t msdos

/dev/sda1 /mnt/SSD)

Note: (D:) and (G:) above are example drive letters; the letter in your "My Computer" window may differ

Note: ―New Volume‖is an example drive. The drive name on your Mac computer may differ

4. Once connected, you can use the ESD200 as an external hard drive to transfer data to and

from your computer. Simply drag and drop files or folders onto the Local Disk,Volume,or

drive letter that represents the ESD200.

5. If you have installed the bundled Backup Manager software, you can press the ESD200’s One

Touch Auto-Backup Button to instantly backup your data (see the Backup Manager Software

User’s Manual for details).

One Touch Auto-Backup Button

Disconnecting from a Computer︱

NEVER disconnect the ESD200 from a Computer when its LED is flashing.

Windows

1. Left-click on the Hardware icon on the system tray.

2. The Safely Remove Hardware pop-up window will appear. Confirm the correct Drive letter is

displayed and select it to continue.
